Ergolux Elestndskwa Electric Standing Desk User Guide

ELESTNDSKWA Electric Standing Desk

Product Information: Electric Standing Desk

The Electric Standing Desk is available in three different
models – ELESTNDSKNA, ELESTNDSKBA & ELESTNDSKWA. It comes with
a desktop, sync rod, two lifting columns, two side brackets, two
feet, two crossbars, a motor, an AC adapter, and a controller. The
desk can be adjusted to different heights using the controller and
has memory settings to save three different positions. The desk
also has collision avoidance technology to prevent any
accidents.

Product Usage Instructions: Electric Standing Desk

Safety & Warnings

Before assembling the desk, lay out all components on a clean
floor and ensure that all parts are included. If any pieces are
missing, check all packaging thoroughly and contact help.Kogan.com
for assistance.

Assembly

Refer to the instruction manual and use the hardware list
provided to assemble the desk. Use the 4mm Allen key (included) and
Phillips Head Screwdriver (not included) for assembly. Ensure that
the desk is assembled on a level surface.

Before First Use

When the desk is first powered on, the height will be displayed
on the controller. If this number does not match the actual height
of the desk, the system will need to be reset before use. Follow
the steps below to reset the system:

1. Use the “lower” button to place the desk in the lowest
   position.
2. Press and hold the “reset” button for 7 seconds until the
   display is alternately flashing RST and E-1.
3. Release the “reset” button.
4. Press and hold the “reset” button again. The desk will move
   downward slightly and then move upwards approximately 5mm.
5. The system has now successfully been reset.

Note: To reset a desk with a customized minimum height, press
and hold both the “lower” and “reset” buttons simultaneously.

Adjusting the Height

To adjust the height of the desk, press the “raise” or “lower”
buttons on the controller. The display will show the current
height.

Memory Setting

To save a position to one of the three memory buttons, first
adjust the desk to the desired height. Press the “S” button, and
then press either the 1, 2 or 3 button. The current height will be
stored to the respective button. To use one of the saved positions,
press either the 1, 2 or 3 button. The desk will move to the saved
position.

Switching Units (CM/INCH)

To switch between units of measurement, follow the steps
below:

1. Press and hold the “S” button until “SET” is displayed.
2. Press 1 to enter the unit menu. The display will alternately
   flash “unt” and the current height.
3. Press the “raise” or “lower” buttons to switch the unit of
   measurement.
4. Press the “S” button to save your selection.

Collision Avoidance

The desk has collision avoidance technology to prevent any
accidents. To adjust the sensitivity level, follow the steps
below:

1. Press and hold the “S” button until “SET” is displayed.
2. Press 2 to enter the collision avoidance menu. The display will
   alternately flash “cpt” and the current sensitivity level.
3. Press the “raise” or “lower” buttons to adjust the sensitivity
   level.
4. Press the “S” button to save your selection.

Controller Lock

To lock the controller, follow the steps below:

1. Press and hold the “S” button until “SET” is displayed.
2. Press 3 to lock the controller. The display will flash OFF.
   Note: In this current state any buttons pressed will have no
   effect.
3. Press and hold the “S” button for 3 seconds to unlock the
   controller.

Setting a Custom Minimum & Maximum Height Limit

To set a custom minimum and maximum height limit, follow the
steps below:

1. Press and hold the “S” button until “HLP” is displayed.
2. The display will alternately flash “HLP” and the current
   height.

ELECTRIC STANDING DESK
ELESTNDSKNA, ELESTNDSKBA & ELESTNDSKWA

SAFETY & WARNINGS
· Read all instructions before use and retain this user guide for future reference. · Read all following safety precautions carefully before use. · Your equipment is intended for use in cool, dry conditions. You should avoid storage in
extreme cold, hot or damp areas as this may lead to corrosion and other related problems. · This desk is rated at a maximum weight capacity of 70kg. · This desk is designed for indoor use only. · Do not modify the desk frame or any of the components that operate this desk in any way. · If the power cord is damaged, cease use immediately and contact help.Kogan.com for support. · If the control box emits any abnormal noises or strong odours, cease use immediately and contact help.Kogan.com for support. · Ensure any obstacles are removed from the area around the desk during assembly and operation. · Ensure that all cords and wires are arranged in a way where they are not a tripping hazard. · Unplug the power cord before cleaning. Wipe the dust from the surface using a slightly damp cloth. Ensure any water does not come in contact with any internal parts or connectors. · Do not disassemble or perform any maintenance without disconnecting the power first. · Do not use any corrosive or abrasive materials to clean the product. · The control box contains electronic components, metals, plastics, wires etc. ensure it is disposed of in accordance with your local environmental legislation. Do not dispose with general household waste. · Ensure this product is completely and correctly assembled before use. · Be familiar with all functions and program settings of the product before first use. · This product can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. · Children should not be allowed play with this product. · Cleaning and user maintenance should not be performed by children without supervision. · Retain the original packaging where possible, to use for any future transportation of this product.

COMPONENTS
Lay all components out on a clean floor and ensure all parts are included. If any pieces are missing, check all packaging thoroughly, then contact help.Kogan.com for assistance.

A Desktop

B Sync Rod

C Lifting Column

D Lifting Column

E Side Bracket (x2)

F Foot (x2)

G Crossbar (x2)

H Motor

I AC Adapter

J Controller

Hardware List

S-A M4x40 Phillips Head Screw (x4)

S-B M6x12 Hex Head Screw (x22)

S-C M6x30 Hex Head Screw (x10)

S-D ST4.0x12
Phillips Head Screw (x4)

Tools Required

4mm Allen key (included)

Spirit Level (not included)

Phillips Head Screwdriver (not included)

ASSEMBLY
Step 1: Installing the feet. · Attach the Feet (F) to the bottom of the Lifting Columns (C) (D) using x8 M6x30 Hex Head Screws (S-C).

S-C (x8)

4mm Allen key

Step 2: Attaching the Sync Rod · Insert the end of the Sync Rod (B) without the notch though the Motor (H). · Insert the Sync Rod (B) into the holes on the Lifting Columns (C)(D). · Secure the motor in place using x2 M4x40 Phillips Head Screws (S-A). S-A (x2)
Notch

Step 3: Attaching the Crossbars · Attach the Crossbars (G) to the Lifting Columns (C)(D) using x8 M6x12 Hex Head Screws (S-B). Note: Ensure the screws are inserted into the outer most holes on the crossbars and lifting columns.
S-B (x8)

Step 4: Attaching the Side Brackets · Attach the Side Brackets (E) to the Lifting Columns (C)(D) using x4 M6x12 Hex Head Screws (S-B). Note: Ensure the Side Brackets are attached to the two holes second from the top of the upper edge of the lifting columns.
S-B (x4)

Step 5: Attaching the Desktop
· Lay the Desktop (A) face down on a soft, flat surface (carpet, blanket etc.). · Attach desk frame assembly to the Desktop (A) using x8 M6x12 Hex Head Screws
(S-B).

S-B (x8)

Blanket

Step 6: Connecting the Controller
· Connect the AC Adapter (I) and the Motor (H) connectors to the mating connectors on the Controller (J). Note: Do not plug the AC Adapter into power until assembly is complete.

Step 7: Attaching the Controller · Attach the Controller (J) to the Desktop (A) using x2 ST4.0x12 Screws (S-D).
S-D (x2)

Step 8: Adjusting the Desk · Turn the Desk back over to the upright position. · Use a spirit level to ensure the desk is level and stable. Each foot has two adjustable pads that can be rotated to raise or lower the desk.
CAUTION: To avoid serious injuries, at least two people are required when turning the desk over.
Spirit level

OPERATION

Display

Raise Lower

Memory 1/2/3

Settings

Before First Use
When the desk is first powered on, the height will be displayed on the controller. If this number does not match the actual height of the desk, the system will need to be reset before use.

Resetting the System
1. Use the ” ” button to place the desk in the lowest position, then and press hold the ” ” button for 7 seconds until the display is alternately flashing “RST” and “E-1″. Release the ” ” button
2. Press and hold the ” ” button again, the desk will move downward slightly and then move upwards approximately 5mm.
3. The system has now successfully been reset.
Note: To reset a desk with a customised minimum height, you will need to press and hold both the ” ” and ” ” buttons simultaneously.

Adjusting the Height
Press the ” ” or ” ” or buttons to adjust the height of the desk. The display will show the current height.

Memory Setting
1. To save a position to one of the three memory buttons, first adjust the desk to the desired height.
2. Press the “S” button, the display will flash the current height then press either the “1”, “2” or “3” button. The current height will be stored to the respective button.
3. To use one of the saved positions, press either the “1”, “2” or “3” button. The desk will move to the saved position.
Switching Units (CM/INCH)
1. Press and hold the “S” button until “SET” is displayed. 2. Press “1” to enter the unit menu. The display will alternately flash “unt” and the
current height. 3. Press the ” ” or ” ” or buttons to switch the unit of measurement. 4. Press the “S” button to save your selection.
Collision Avoidance
1. Press and hold the “S” button until “SET” is displayed. 2. Press “2” to enter the collision avoidance menu. The display will alternately flash
“cpt” and the current sensitivity level. 3. Press the ” ” or ” ” or buttons to adjust the sensitivity level. 4. Press the “S” button to save your selection.
Controller Lock
1. Press and hold the “S” button until “SET” is displayed. 2. Press “3” to lock the controller. The display will flash “OFF”. Note: In this current
state any buttons pressed will have no effect. 3. Press and hold the “S” button for 3 seconds to unlock the controller.

Setting a Custom Minimum & Maximum Height Limit
1. Press and hold the “S” button until “HLP” is displayed. 2. The display will alternately flash “HLP” and the current height.
o Adjust the desk to your desired maximum height and press “1”. The display will flash “H-P”, press “S” to store the height.
o Adjust the desk to your desired minimum height and press “2”. The display will flash “L-P”, press “S” to store the height.
o Press “3” to remove the previously stored height settings.
Deleting Custom Settings
1. Press and hold the “S” button until “FAC” is displayed, then release the button. 2. Press the “S” button again to remove all custom settings.

TROUBLESHOOTING

The following tips will help you detected and eliminate some common faults and errors. If the problem cannot be fixed or the fault is not listed below, please contact help.Kogan.com for support.

Error Code Err E-1 E-2 E-3
E-5 ovr hot
voL

Solution
The control panel is disconnected. Check the connection. Disconnect the power then reconnect it.
Reset the system.
The weight rating has been exceeded. Remove all items from the desktop and reset the system.
The collision avoidance system has activated. Remove all items within the desk’s range of motion.
Check all connection and reset the system.
An overload has occurred. Remove all items from the desktop and reset the system.
The system has overheated. Cease operation and allow the desk to remain idle for approximately 10 minutes.
An electrical fault has occurred. Disconnect the power then reconnect it.

Disposal
This marking indicates that this appliance should not be disposed with other household wastes. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources.

NOTES

Need more information?
We hope that this user guide has given you the assistance needed for a simple set-up.
For the most up-to-date guide for your product, as well as any additional assistance you may require,
head online to help.kogan.com
