Mountup Mu0012 Tv Wall Mount Instruction Manual

• Identify the VESA mounting holes on the back of your TV.
• Select the correct bracket size from the included hardware
  based on your TV’s VESA specifications.
• Align the bracket with the VESA mounting holes and securely
  attach it to the TV using the provided screws.

• Carefully lift the TV with the attached bracket.
• Align the bracket hooks with the wall plate and carefully lower
  the TV onto the wall plate.
• Ensure that the TV is securely attached to the wall plate and
  properly leveled using the included bubble level.

Important Safety Precautions:

• Do not mount the TV on drywall alone; ensure the wall is
  capable of supporting five times the weight of the TV and mount
  combined.
• Follow the provided instructions carefully to avoid incorrect
  installation, assembly, or misuse that may lead to product damage
  or body injury.
• Keep small hardware items, such as screws, away from children
  as they can be a choking hazard if swallowed.
• Before starting assembly, verify that all parts are included
  and undamaged. Contact us if there are any parts shortages or
  damages.

Please consult this user manual for detailed installation
instructions. If you have any doubts or concerns about the safety
of the installation, assembly, or use of this product, please
contact us for assistance.

2 2

Safety Caution

Hardware Included

MU0012 INSTALLATION INSTRUCTION

Velcro cable ties X5

Bubble level X1

How to install your TV with an optimal viewing height? Experts agree that 42 inches from the center of the TV to
the floor is ideal.
Attention on the VESA (TV Mounting Holes) location.

3-Step installation ( DO NOT MOUNT ON DRYWALL ALONE!)

1 Install wall plate.

2 Attach bracket to TV back.

3 Hang TV onto wall plate.

Mounting template X1

Please read this instruction carefully before installation. If you do not understand these instructions or have doubts about the safety of the installation, assembly or use of this product, please contact us.
This product is designed for use in wood stud and solid concrete wall. – DO NOT install into drywall alone.
The wall must be capable of supporting five times the weight of the TV and mount combined. Do not apply this product to any purpose not indicated by MOUNTUP. Incorrect installation may result in product damage or body injury. MOUNTUP shall bear no responsibility
for any damage or injury resulted from incorrect installation, incorrect assembly or misuse.
WARNING: This product contains small items that could be a choking hazard if swallowed.
Before starting assembly, verify all parts are included and undamaged. For parts shortage or damage, please contact us.

Must Check Before Getting Started

MAX:600mm/24″
MAX: 400mm/16″

Max: 100LBS (45.5KG)

<16mm(5/8″)

Min. Wood Stud Size: nominal 4″(102mm) actual 3 1/2″(89mm)
Min. Wood Stud Size: nominal 2″(51mm) actual 1 1/2″(38mm)
16″(406mm)

Min. 8″ (203mm)

Drywall with wood studs

Solid concrete wall

CAUTION: DO NOT install into drywall alone.

Installation Tools (Not Included)

Wood Stud Installation Concrete Installation

Arm and Wall Plate

01 x1
Arm Extensions

03 x2

Hardware cWall /Product)

Lag Bolts 5/16 x 2½ in

Open-end wrench

x4

x1

A

B

TV Screws / Washers

Philips Screws M4 x 12mm M4 x 30mm

Philips Screws M6 x 15mm M6 x 30mm

Philips Screws M8 x 25mm M8 x 45mm

Spacers L10mm

Front Support
02 x1
Brackets
04 x2

Washers Ø6mm M4-5-6

Spacers L5mm

42″~70″

Max: 100LBS (45.5KG)

If you have any questions, please contact us.
Step 1-1 Select TV screw diameter

Max:600x400mm /24×16″ Min:200x100mm /8×4″
7

2M

1/2″

7/32″ (5.5mm)

3/8″ (10mm)

(13mm)

x4 x4

Band Pencil Electrodrill Socket Screwdriver

x4 x4 x4 x4

x8

x4

Stud Awl Wood

Masonry Hammer

Tape

Wrench

M-A

M-B

M-C

M-D

M-E

Finder

Drill Bit

Drill Bit

1

Step 1-3 Attach the bracket

Step 2A Wall plate installation (wood stud)

x8
M-F
2

Thread screws by hand into the threaded holes on the back of your TV to select which screw diameter fits your TV.
M4 M6 M8

CAUTION: Ensure bracket is securely fastened before moving on to the next step.

(a) For Flat Back
No!

04
Top of TV

M-A M-C M-B
Use the shorter screws
M-E Not for M8 screws

2A-1

Max 406mm (16″)

Locate your studs. Verify and mark the center of the studs by finding the stud edges using an awl, a thin nail, and an edge-to-edge stud finder.

Step 1-2 Select TV screw length

When attaching brackets to the flat screen, be careful not to over tighten screws and be sure that screws do not bottom out in the mounting holes.

(b) For Round Back / Extra Space

04

No!

Too Short

Too Long

Correct

Correct

3

M-A M-C M-B
Use the longer screws
M-E Not for M8 screws
M-D M-F

2A-2
HthoeEwfxloptooerritnisssaitdgaerlleayel.othuartT4V2 winicthheasnfroopmtimthaelcveinetweirnogf thheeigThVt?to Attention on the VESA (TV Mounting Holes) location.

Bubble Level

3-Step installation ( DO NOT MOUNT ON DRYWALL ALONE!)

1 Install wall plate.

2 Attach bracket to TV back.

3 Hang TV onto wall plate.

Mounting template
4

Position the mounting template at your desired height and line up the holes with your stud center line. Level the mounting template and mark the pilot hole locations.
5

2A-3
2.75in (70 mm)
Drill pilot holes using a 7/32 in. (5.5 mm) diameter drill bit.

7/32 in Ø5.5 mm

Step 2B Wall plate installation (concrete or brick)

Position the mounting template at your desired height , level the mounting template and mark the pilot hole locations x4.

Bubble Level

HthoeEwfxloptooerritnisssaitdgaerllaeyle.othuartT4V2

winicthheasnfroopmtimthaelcveinetweirnogf

height? the TV to

Attention on the VESA (TV Mounting Holes) location.

3-Step installation ( DO NOT MOUNT ON DRYWALL ALONE!)

1 Install wall plate.

2 Attach bracket to TV back.

3 Hang TV onto wall plate.

2B-3
No!

Concrete wall anchor 4pcs (NOT INCLUDED)

Ø10*61mm

Contact us to have these additional pieces shipped directly to you.

A

2
2

IMPORTANT: Pilot holes must be drilled to a depth
of 2 3/4 in (70 mm). Be sure to drill into the center of the stud.

Mounting template

2A-4

A

To prevent the TV falling down, the Arrow

Must Keep UP at this step!!

UP

01

2B-2

Ø 10 mm

No!
2.75in 70 mm

Install wall plate 01 using lag bolts A with Socket Wrench, NO Electrodrill. Tighten the lag bolts A until they are pulled firmly against the wall plate 01
6

Drill pilot holes

Step 3 Install front support and extensions

Step 4 Hang TV with bracketsonto the arm extensions

3-1 Install the extensions [03] to Front support [0022] with the pre-assembled screws.

4-1 04

4-2

4-3

1. Loosen a little

2. Remove the pre-assembled screws x4

3/8in Ø 10 mm

UP

01

To prevent the TV falling down, the Arrow Must Keep UP at this step!!

Install wall plate 01 using lag bolts A and anchor (not included). Tighten the lag bolts A until they are pulled firmly against the wall plate 01
Concrete Wall

Concrete Wall

7

8

Adjustments

TV leveling adjustment (-3°/+3°)

±3°

P3
Remove the pre-assembled screws [PP33] and save to use, then raise the safety locks.

03

02

Adjustments Tool-free Tilting Adjustment

3-2

Hang 02 onto 01 and using a screwdriver to secure with pre-assembled screws P1 and washer P2 .

-10° +5°

P3
Press the safety locks then fasten the removed screws [PP33].
If necessary
If TV keeps tilting down, pull TV to desired angle then fasten tilting nuts with open-end wrench.
Tighten

Loosen 2 leveling bolts on the rear of TV plate with the open- end wrench B , adjust to level, and retighten to secure.
Product dimensions:
MAX:676mm/26.6″ MAX:600mm/23.6″ MIN:200mm/8″
410mm/16″

Loosen
Tighten MAX:391mm/15.4″ MIN:68mm/2.7″ +5 /-10°

234mm/9.2″ MAX:400mm/8″ MIN:100mm/4″ 430mm/16.9″

P2 P1

Loosen B
-3/+3°

9

10

11
