SSL-12151L Uixe 1 Light Matte Black Hardwired Large Outdoor Wall Lantern Sconce
Product Information:
The product is a light fixture that includes a mounting unit,
screws, rubber rings, wire nuts, and bulbs are not included in the
package. It requires a junction box, which is not included in the
package. The package includes all the necessary hardware required
for installation of the light fixture. The product requires the use
of tools such as a ladder, safety glasses, electrical Phillips,
tape, screwdriver, flat blade screwdriver, pliers, and wire
strippers.
Product Usage Instructions:
- STEP 1: Start by unscrewing the rubber rings and screws from
the mounting unit. Use the mounting screws to attach the mounting
unit to the junction box (not included). - STEP 2: Next, make the electrical connection from the junction
box (not included) to the fixture. Connect the ground wire to the
mounting unit using the preinstalled green ground screw. Then,
connect the positive, negative, and ground wires with the supplied
wire nuts. Secure the connections with electrical tape. - STEP 3: Attach the fixture to the mounting unit through screw
holes as shown and secure it with rubber rings and screws. It is
important to use caulk in the backplate and wall mounting surface
to prevent water from entering. - STEP 4: Finally, install bulbs (not included) in the
fixture.
Note: The product requires a junction box (not included), which
should be purchased separately before installation. Also, it is
important to use all the necessary tools required for installation
and follow all safety precautions while installing the light
fixture.
ASSEMBLY INSTRUCTIONS
CAUTION
³Inspect the wire insulation for any cuts, abrasions, or exposed copper that may have resulted during shipping. If there is a defect in the wire, do not attempt installation.
TOOLS REQUIRED
³Before starting installation of this fixture or removal of a previous fixture, disconnect the power by turning off the circuit breaker or by
removing the fuse at the fuse box.
Ladder
Safety glasses
Electrical Phillips
tape
screwdriver
Flat blade screwdriver
Pliers
Wire strippers
HARDWARE INCLUDED
Fixture
Mounting Unit
Screws
Rubber Rings
Mounting Screws
*PARTS SHOWN MAY DIFFER SLIGHTLY PER LIGHT FIXTURE
Wire Nuts
EXPLODED PARTS
Mounting Screws
INSTALLATION
Junction Box (not included)
STEP 1
Unscrew the rubber rings and screws from the mounting unit. Use the mounting screws to attach the mounting unit to the junction box(not included).
Wire Nuts Mounting Unit
Screws Rubber Rings
Fixture
Bulbs (not included)
STEP 2
Make the electrical connection from the junction box (not included) to the fixture. Connect the ground wire to the mounting unit using the preinstalled green ground screw. Then, connect the positive, negative and ground wires with the supplied wire nuts. Secure with electrical tape.
Black or Red wire (hot) from the junction box
White wire (neutral) from the junction box
Bare or Green ground wire from the junction box
*Sealing tape (not included)
Black wire from the fixture
White wire from the fixture
Ground wire from the Fixture
*Green Ground Screw
ASSEMBLY INSTRUCTIONS INSTALLATION
*junction box (not included)
STEP 3
Attach the fixture to the mounting unit through screw holes as shown, and secure it with rubber rings and screws. NOTICE: Please use caulk in the back plate and wall mounting surface to prevent water from entering.
STEP 4
Install bulbs (not included).
