Uixe Ssl-17261bk 1-light Black Outdoor Barn Light Wall Mount Sconce Instruction Manual

SSL-17261BK 1-Light Black Outdoor Barn Light Wall Mount Sconce

Product Information

This product is a light fixture that requires assembly and
installation. The package includes a mounting unit, fixture, shade,
rubber rings, ball nuts, mounting screws, wire nuts, and a green
ground screw. The product requires a ladder, safety glasses,
electrical Phillips screwdriver, flat blade screwdriver, pliers,
wire strippers, and tape for assembly and installation. The product
may differ slightly from the parts shown in the manual.

Product Usage Instructions

Assembly Instructions

Before assembly, ensure that you have all the required tools and
hardware.

1. Remove the rubber rings and ball nuts from the mounting unit
   using pliers.
2. Use the mounting screws to attach the mounting unit to the
   junction box.
3. Connect the ground wire to the mounting unit using the
   preinstalled green ground screw. Then, connect the positive,
   negative, and ground wires from the junction box to the fixture
   using the supplied wire nuts. Secure with electrical tape.
4. Attach the fixture to the mounting unit through screw holes as
   shown and secure it with rubber rings and ball nuts. Use caulk in
   the backplate and wall mounting surface to prevent water from
   entering.
5. Lock tight the arm.
6. Remove the socket ring from the socket. Use the socket ring to
   attach the shade to the fixture.
7. Install a bulb (not included).

Please follow these instructions carefully to ensure proper
assembly and installation of the product.

ASSEMBLY INSTRUCTIONS

CAUTION

³Inspect the wire insulation for any cuts, abrasions, or exposed copper that may have resulted during shipping. If there is a defect in the wire, do not attempt installation.

TOOLS REQUIRED

³Before starting installation of this fixture or removal of a previous fixture, disconnect the power by turning off the circuit breaker or by
removing the fuse at the fuse box.

Ladder

Safety glasses

Electrical Phillips

tape

screwdriver

Flat blade screwdriver

Pliers

Wire strippers

HARDWARE INCLUDED

Fixture
EXPLODED PARTS

Shade

Mounting Unit

Rubber Rings

Ball Nuts

Mounting Screws Wire Nuts

*PARTS SHOWN MAY DIFFER SLIGHTLY PER LIGHT FIXTURE

INSTALLATION

Wire Nuts

Rubber Rings Ball Nuts

STEP 1
Unscrew the rubber rings and ball nuts from the mounting unit. Use the mounting screws to attach the mounting unit to the junction box(not included).

Mounting Unit Mounting Screws

Fixture

Shade Socket Ring

Bulbs (not included)
STEP 2
Make the electrical connection from the junction box to the fixture. Connect the ground wire to the mounting unit using the preinstalled green ground screw. Then, connect the positive, negative and ground wires with the supplied wire nuts. Secure with electrical tape.

Black or Red wire (hot) from the junction box
White wire (neutral) from the junction box
Bare or Green ground wire from the junction box
*Sealing tape (not included)

Black wire from the fixture
White wire from the fixture
Ground wire from the Fixture
*Green Ground Screw

ASSEMBLY INSTRUCTIONS INSTALLATION
STEP 3
Attach the fixture to the mounting unit through screw holes as show,and secure it with rubber rings and ball nuts.
NOTICE: Please use caulk in the back plate and wall mounting surface to prevent water from entering.

STEP 4
Lock tight the arm.

STEP 5
Remove the socket ring from the socket. Use the socket ring to attach the shade to the fixture.

STEP 6
Install bulb (not included)
