2462-691 Waverly Plaza Vanity Light
Product Information
Product: Item#2462-691
Date of Manual: New. 07/27/2021
Manufacturer: Not mentioned
Installation Instructions
MOUNTING THE FIXTURE (Fig.1)
- Shut off power at the fuse box or circuit breaker box and
remove the old fixture including the mounting hardware. - Carefully unpack your new fixture and lay out all the parts in
a clear area. Take care not to misplace any small parts necessary
for installation. - Attach the mounting plate (A) to the junction box (not
included) using the mounting screws (B) (SIZE: #8-32N, L0.5). The
side of the mounting plate marked GND must face out.
CONNECTING THE WIRES (Fig. 2)
- Connect the electrical wires as shown in Fig. 2, making sure
that all wire connectors are secured. If your junction box has a
ground wire (green or bare copper), connect the fixture’s ground
wire to it. Otherwise, connect the fixture’s ground wire directly
to the mounting plate (A) using the green screw provided. After the
wires are connected, tuck them carefully inside the junction
box.
FINISHING THE INSTALLATION (Fig.1)
- Place fixture body (C) over mounting plate (A) and secure with
screws (D). - Place decorative holder (F) and glass shade (G) over socket (E)
and secure with socket ring (H). - Install two medium base bulbs (I) up to 60 watts each or CFL or
LED equivalent (not included) in accordance with the fixture
specification. DO NOT EXCEED THE MAXIMUM WATTAGE RATING!
Your installation is now complete. Return power and test the
fixture.
Note: Illustration (Fig.1) on this manual is for installation
purposes only. It may or may not be identical to the fixture
purchased.
INSTALLATION INSTRUCTIONS
Item#2462-691 (New. 07/27/2021) READ AND SAVE THESE INSTRUCTIONS
W AR N I N G ! S HU T P O WE R O F F AT F U S E O R CI R C UI T B R E AK E R .
AVERTISSEMENT! COUPER LE COURANT AU NIVEAU DES FUSIBLES OU DU DISJONCTEUR.
MOUNTING THE FIXTURE (Fig.1)
Fig. 1
1. Shut off power at the fuse box or circuit breaker box and remove the old fixture including the mounting hardware.
2. Carefully unpack your new fixture and lay out all the
Set#A-021-115123A -Mounting plate -Ground screw – Mounting screw*2
parts in a clear area. Take care not to misplace any
I
small parts necessary for installation.
3. Attach the mounting plate (A) to the junction boxnot included using the mounting screws (B) (SIZE:
H
#8-32N, L0.5″). The side of the mounting plate
marked “GND”must face out.
G
CONNECTING THE WIRES (Fig. 2)
4. Connect the electrical wires as shown in Fig. 2, making sure that all wire connectors are secured. If your junction box has a ground wire (green or bare copper), connect the fixture’s ground wire to it.
A
B
F
D
Otherwise, connect the fixture’s ground wire directly
C
E
to the mounting plate (A) using the green screw
provided. After the wires are connected, tuck them
carefully inside the junction box.
FINISHING THE INSTALLATION (Fig.1)
5. Place fixture body (C) over mounting plate (A) and
secure with screws (D).
6. Place decorative holder (F) and glass shade (G) over socket (E) and secure with socket ring (H).
7. Install (2) two medium base bulbs (I) up to 60 watts
each or CFL or LED equivalent (not included) in
Fig. 2
FIXTURE WIRES Black or Smooth
FIXTURE WIRES White or Ribbed
FIXTURE WIRES Green or Bare Copper (Ground)
accordance with the fixture specification–DO NOT
EXCEED THE MAXIMUM WATTAGE RATING! (NE PAS DEPASSER LA PUISSANCE NOMINALE MAXIMALE!)
Your installation is now complete. Return power and test the fixture.
HOUSE WIRES Black (Hot)
HOUSE WIRES White (Neutral)
HOUSE WIRES Green (Ground)
Note: Illustration (Fig.1) on this manual is for installation purposes only. It may or may not be identical to the fixture purchased.
LA-3441E
