Minka Lavery 2453-695 Bishop Crossing 24.5 Inch 3 Light Soft Brass Vanity Light Instruction Manual

2453-695 Bishop Crossing 24.5 Inch 3 Light Soft Brass Vanity Light

Product Information

The product being installed is item #2453-695, manufactured on
August 13, 2021. The product is a light fixture that requires
installation onto a wall junction box. The fixture includes a
mounting plate, drywall anchors, mounting screws, wood screws, and
a shade assembly. The fixture is designed to hold three medium base
bulbs of up to 60 watts each or CFL or LED equivalent bulbs (not
included).

Product Usage Instructions

  1. Shut off power at the fuse box or circuit breaker box.
  2. Remove the old fixture, including the mounting hardware.
  3. Unpack the new fixture and lay out all the parts in a clear
    area.
  4. Loosen screws (E) to remove mounting plate (A) from fixture
    body (F).
  5. Position mounting plate (A) on the wall and mark the location
    of two drywall anchors (B). Pre-drill the holes for the drywall
    anchors (B). Insert drywall anchors (B) into the wall.
  6. Attach mounting plate (A) to the junction box using the
    mounting screws (D). The side of mounting plate (A) marked GND must
    face out.
  7. Connect the electrical wires as shown in Fig. 2, making sure
    that all wire connectors are secured. If your junction box has a
    ground wire (green or bare copper), connect the fixture’s ground
    wire to it. Otherwise, connect the fixture’s ground wire directly
    to mounting plate (A) using the green screw provided. After the
    wires are connected, tuck them carefully inside the junction
    box.
  8. Place fixture body (F) over mounting plate (A) and secure with
    screws (E).
  9. Place shade assembly (J) onto socket stand (G) and secure with
    screws (I).
  10. Install three medium base bulbs (H) up to 60 watts each or CFL
    or LED equivalent (not included) in accordance with the fixture
    specification. DO NOT EXCEED THE MAXIMUM WATTAGE
    RATING!
  11. Turn on power at the fuse box or circuit breaker box and test
    the fixture.

INSTALLATION INSTRUCTIONS

Item#2453-695 (New. 2021/8/13) READ AND SAVE THESE INSTRUCTIONS
W AR N I N G ! S HU T P O WE R O F F AT F U S E O R CI R C UI T B R E AK E R .
AVERTISSEMENT! COUPER LE COURANT AU NIVEAU DES FUSIBLES OU DU DISJONCTEUR.

MOUNTING THE FIXTURE (Fig.1)

Fig. 1

1. Shut off power at the fuse box or circuit breaker box

and remove the old fixture including the mounting hardware. 2. Carefully unpack your new fixture and lay out all the parts in a clear area. Take care not to misplace any small parts necessary for installation. 3. Loosen screws (E) to remove mounting plate (A) from fixture body (F). 4. Position mounting plate (A) on the wall and mark the

Set#A-021-468112 -Mounting Screw*2
-Ground Screw -Mounting Plate

location of two drywall anchors (B). Pre-drill the holes

for the drywall anchors (B). Insert drywall anchors (B) into the wall. 5. Attach mounting plate (A) to the junction box (not included) using the mounting screws (D). The side of mounting plate (A) marked “GND” must face out. 6. Place woodscrews (C) through the holes into the drywall anchor (B) to secure mounting plate (A) as shown in Fig.1.

BA

I

CE

H

F

D

CONNECTING THE WIRES (Fig. 2) 7. Connect the electrical wires as shown in Fig. 2, making
sure that all wire connectors are secured. If your junction box has a ground wire (green or bare copper),

G

J

connect the fixture’s ground wire to it. Otherwise,

connect the fixture’s ground wire directly to mounting plate (A) using the green screw provided. After the wires are connected, tuck them carefully inside the junction box.

FINISHING THE INSTALLATION (Fig.1) 8. Place fixture body (F) over mounting plate (A) and
secure with screws (E).
9. Place shade assembly (J) onto socket stand (G) and
secure with screws (I).
10. Install (3) three medium base bulbs (H) up to 60
watts each or CFL or LED equivalent (not included) in accordance with the fixture specification. –DO NOT EXCEED THE MAXIMUM WATTAGE RATING! (NE PAS DEPASSER LA PUISSANCE NOMINALE MAXIMALE!)

Fig. 2
FIXTURE WIRES Black or Smooth

Your installation is now complete. Return power and test the fixture.

FIXTURE WIRES White or Ribbed HOUSE WIRES Black (Hot)

FIXTURE WIRES Green or Bare Copper (Ground) HOUSE WIRES White (Neutral)

HOUSE WIRES Green (Ground)

Note: Illustration (Fig.1) on this manual is for installation purposes only. It may or may not be identical to the fixture purchased.
