Hawk AL-02B-OP Gaming Case
User Manual
Hawk AL-02B-OP Gaming Case
- Elegant front panel in aluminum look
- Tempered glass side panel
- Preinstalled dust filters
- Cable management
The CHIEFTEC HAWK AL-02B-TG-OP is an elegant and rock-solid gaming device Housing with an aluminum front panel design. The side part is made of hardened glass enabling a direct view of the built-in components. the Dust filters in the front and in the bottom area are already pre-installed and take care of that a dust-free interior.
A modern gaming case that knows how to impress with its high quality. The HAWK is the right choice for all gamers who place high demands on design combined with valuable materials
Technical specifications
| Model | AL-02B-TG-OP |
| EAN code | 753263076281 |
| Color | Black |
| Material | 0,6mm SPCC |
| Motherboard support | Mini ITX, mATX, ATX |
| Dimension (DxWxH) | 435mm x 200mm x 450mm |
| Weight (without/with the package) | 5.85 kg / 6.85 kg |
| Drive bay external | lx 5.25″ |
| Drive bay internal | 2x 2.5″ and 2x 3,5″ |
| Power supply | ATX PSU (optional, 140mm – 200mm) |
| Front I/O | 2x USB3.0 (USB3.1Gen 1), lx USB2.0, Audio-out (AZALIA / HD-Audio) |
| Scope of delivery | Screw set, removable PSU dust filter |
| Expansion slots | 7 |
| Cooling Compatibility | Front: 3x 120mm or 2x140mm fans or up to 240mm radiator Rear: lx 120mm fan or up to 120mm radiator |
| CPU cooler height (max.) | I66mm |
| VGA card length (max.) | 349mm |
| Warranty | 24 Months |
* Specifications are subject to change without prior notice. No liability is assumed for typographical or content-related errors. Illustration similar.
** CHIEFTEC® is a registered trademark. All other trademarks and logos are the property of their respective owners.
