EX35 Handheld Fiber Fusion Splicer
Product Information
The EX35 is a handheld fiber fusion splicer designed to enable
fast and efficient splicing of fibers. It features a 3.5-inch TFT
screen with 200X magnification and can save up to 10,000 splicing
results and 100 images. The splicer has a battery capacity of
2600mAh, allowing for circular welding up to 100 times, including
heating. With its small volume and lightweight design, it is easily
portable. The product also includes special V-groove, 3 in 1
holders, removable SOC clamps, and durable ceramic fiber pressure
heads. It is suitable for various fiber types, including SM (G652
& G657), MM (G651), DS (G653), and NZDS (G655). The splicer has
a return loss of better than 60dB and an average splicing loss of
0.01dB.
Product Usage Instructions
- Prepare the fiber by cutting it to the appropriate length based
on the fiber diameter. - Place the fiber in the splicer’s fiber clamp, ensuring proper
alignment. - Select the appropriate splicing program using the display
interface. - Close the splicer’s windproof cover to protect against strong
winds. - Press the splicing button to initiate the splicing process. The
splicer will quickly splice the fibers in approximately 9
seconds. - If required, adjust the heating time and temperature using the
display interface. - Press the heating button to initiate the heating process. The
splicer will heat the fusion point in approximately 35
seconds. - Once the splicing and heating processes are complete, remove
the fused fiber from the splicer. - Repeat the above steps for additional splicing and heating as
needed. - After use, clean the splicer and store it in the provided
carrying bag for safekeeping.
Please refer to the product manual for more detailed
instructions and safety precautions.
EX35
Enabling today. Inspiring tomorrow.
Handheld Fiber Fusion Splicer
9S Quickly splicing
35S Heating
3.5Inch Screen
0.01dB Average 5000times splicing loss electrode life
Four motors
Features Description
Fast-splicing 9s Fast-heating 35s (time and temperature can be adjusted) 5000 times electrode life Return loss less than 60dB Average splicing loss is 0.01dB
2600mAh battery capacity,circular welding 100 times(including heating)
3.5 Inch TFT Screen 200X magnification Special 3 in 1 holders,support jumpers,pigtails, bare fibers and flat fibers Can save 10000 splicing results,100 images
Handheld fusion splicer,small volume,lightweight, and easily carrying
Products Features
Special V-groove
Fast-splicing 9S Fast-heating 35S
Dedicated 3 in 1 holders
Removable SOC Clamps
Durable Ceramic Fiber Pressure Heads
Deep recessed windproof cover 15m/s strong wind can splice
3 IN 1 holders
Suitable for bare fiber,3.0mm jumpers,pigtails and FTTH fiber
9S
35S
quickly splicing heating
Handheld and Compact
100 times Circular splicing and heating
2600mAh battery capacity
Specification
Fiber Type
SM (G652 & G657) / MM (G651) / DS (G653) / NZDS (G655)
Typical splicing loss
SM: 0.02dB
MM: 0.01dB DS / NZDS: 0.04dB
Return loss
better than 60dB
Typical heating time
9s(Standard SM)
Typical heating time
35s(heating time and heating temperature can be adjusted
Fiber Aligning Method Fiber Diameter Cutting Length
Meticulous; Core; Clad; Manual Clad Diameter is 80 ~ 150m; Coating250 ~ 1000m Coating layer250m: 8 ~ 16 mm; Coating 250 ~ 1000m: 16mm
Heat-shrinkable Sleeve
60mm / 40mm and a series of thermal sleeves
Tension Test
Fiber Clamp Fiber Image Magnification
Display
Standard 2N(can choose) Suitable for Bare fiber; Pigtail; Jumper wire; flat fiber, optional holder,splicing type fast connector which is qualified for standard FTTX
200X(X-axis or Y-axis); 125X(X-axis or Y-axis)
3.5Inch TFT color LCD
External Port
USB 2.0 interface, convenient for data download, using U disk upgrade software
Splicing Program
100(User Mode); 53(Factory Mode)
Heating programm
40(User Mode); 11(Factory Mode)
Fusion Splicing Record
Saved 10000 groups splicing results.100 sets of latest Images
Electrode life splicing times (including heating) Internal battery Power Supply
Working environment
High-brightness lights Dimension
5000 times
Splicing and heating continuously more than 100 times typically Lithium battery 12.5V power supply (10.8V storage), independent charger, charging time 3.5h Power supply connector, external adapter
(Import AC: AC100~240V, 50/60Hz, 0~1.5A, Export DC: DC13.5v/4.8A) Temp: -10~50; Hum: 0~95%RH
Elevation: 0~5000M; Resist the maximum wind speed: 15m/s
Convenient for placing the fiber at night
193 x 125 x 85mm
Weight
1.05kg (Without Battery); 1.2kg (With Battery)
Products Display
Products list
Fusion splicer
Fiber cleaver
Drop stripper
3 hole stripper
cleaning box
Power charger Manual+ Warranty card
