TDE-1000 Series Exit Device
Product Information:
The Trudoor TDE-1000 Series Exit Device is a Grade 1 exit device
designed for installation on single doors. It features a roller
strike for secure latching and is suitable for both metal and wood
doors. The exit device comes with various mounting brackets,
screws, and tools required for installation.
Product Usage Instructions:
Install Roller Strike:
- With the door in the closed position, mark the centerline of
the latchbolt on the door jamb. - Place the roller strike on the door jamb, aligning the center
of the roller strike with the latchbolt centerline. Mark the jamb
and align the outside edge of the roller strike with the outside
edge of the door jamb. - Mark the center of the two adjustable slotted holes and drill
7/32 pilot holes. Tap the pilot holes with 1/4-20 threads and
install machine screws. Alternatively, drill 3/16 pilot holes for
installing self-tapping machine screws or wood screws in pilot
holes. Close the door to check if the latchbolt extends properly
and adjust the roller strike if necessary. - With the roller strike in its final position, drill a 7/32
pilot hole for the center mounting hole. Tap the pilot hole with
1/4-20 threads and install a machine screw. Alternatively, drill a
3/16 pilot hole for installing a self-tapping machine screw or wood
screw in the pilot hole. - Note: Install the strike shim unless the exit device head cover
rubs against the roller strike. In that case, remove the strike
shim to gain additional clearance.
Operation Test:
After installation is complete, press down the actuating bar to
ensure that the door opens and closes/latches correctly. Make any
necessary adjustments.
Locking and Unlocking:
To unlock, hold the actuating bar down and turn the dogging
device clockwise with the dogging wrench.
To lock, hold the actuating bar down and turn the dogging device
counterclockwise with the dogging wrench.
Door Backset Adjustment:
If the door has a backset of less than 36 inches, remove the end
cover and cut section A to the desired length.
A stock door backset of 2 3/4 can be used, but it will decrease
the backset by 3/16. This can be offset by not using the 1/8 strike
shim to gain 1/8 extra clearance. This will bring the backset
within 1/16, which is within acceptable tolerances to operate
correctly.
G INSTALL ROLLER STRIKE
1.With the door in the closed position, mark the centerline of latchbolt on door jamb.
2.Place roller strike on door jamb. Align center of roller strike with the latchbolt centerline. Mark on the jamb. Then align the outside edge of the roller strike with the outside edge of the door jamb.
3.Mark the center of the 2 adjustable slotted holes and drill 7/32″ pilot holes. Tap pilot holes with 1/4″-20 threads and install machine screws. Or, drill 3/16″ pilot holes for installing self tapping machine screws or wood screws in pilot holes. Close door to check if latchbolt extends properly. Adjust roller strike if necessary.
4.With roller strike in final position, drill a 7/32″ pilot hole for the center mounting hole, tap pilot hole with 1/4″-20 threads and install machine screw. Or, drill 3/16″ pilot hole for installing self tapping machine screw or wood screw in pilot hole.
1.JAMB
2.ADJUSTABLE SLOT
3.DRILL 7/32″ HOLE,TAP 1/4″-20P THREAD
Note:Install strike shim unless the exit device head cover rubs the roller strike. Then remove the strike shim to gain additional clearance.
H OPERATION TEST
4. 1/4″-20P FLAT HEAD SCREW
After installation is complete, press down the actuating bar to make sure the door opens and closes/latches correctly. Make any adjustments as needed.
Notice:
To extend the life of this exit device, lock the latch in the retracted position when door is in continuous use.
ACTUATING BAR
DOGGING DEVICE
Installation Instructions For Trudoor TDE-1000 Series Exit Device
To unlock
Hold actuating bar down. Turn dogging device clockwise with dogging wrench.
To lock
Hold actuating bar down. Turn dogging device counter clockwise with dogging wrench.
DOGGING WRENCH
1000R Rim Exit Device
Installation Instructions Grade 1
A IDENTIFICATION OF PARTS
If door is less than 36 “, remove end cover and cut section ” A” to desired length.
A
DOOR HANDING
OUTSIDE OF DOOR
HEAD COVER
ACTUATING BAR
DOGGING DEVICE
END COVER
DOGGING WRENCH
RHR
LHR
INSIDE OF DOOR
ROLLER STRIKE
END COVER MOUNTING BRACKET
STRIKE SHIM
ASA FILLER PLATE
LATCHBOLT FILLER PLATE
1/4″-20P x 3/4″ (3 PCS) FLAT HEAD
MACHINE SCREWS
1/4″-20P x 3/4″ (6 PCS) ROUND HEAD
MACHINE SCREWS
14# x1 1/2″ (9 PCS) SELF TAPPING
MACHINE SCREWS
TOOLS REQUIRED
1/4″x 1 1/4″ (3 PCS) FLAT HEAD
WOOD SCREWS
1/4″x 1 1/4″ (6 PCS) ROUND HEAD
WOOD SCREWS
DOUBLE DOOR STRIKE
(Not included,must be ordered separately. For use on rim x vertical rod applications.)
METAL
WOOD
1/4″-20
3/16″ #7
B TYPE OF INSTALLATION
A. Rim Device on Single Door
CL
B. Rim x Rim x Mullion on Pair of Doors
CL
CL
3 5/16″ 3 5/16″
2 15/16″
EXTERIOR
DOOR
DOOR
DOOR
C. Rim w/ DDS x Surface Vertical Rod on a Pair of Doors
CL
CL
DOOR
DOOR
FRAME
2 7/16″
INTERIOR
A stock door backset of 2 3/4″ can be used but will decrease the backset by 3/16″, this can be offset by not using the 1/8″ strike shim to gain 1/8″ extra clearance. This will bring the backset within 1/16″ which is within acceptable tolerances to operate correctly.
MULLION
2″
2 7/16″ 2 7/16″
If KRM Mullion is being used,install KRM mullion first, then outside trim adjusting backset according to KRM Mullion backset drawing and then install exit device.
DOUBLE DOOR STRIKE
2 5/8″ 3 9/32″
When installing Rim device x SVR device on a pair of doors a Double Door Strike (DDS) is required. For complete template information, please refer to the DDS template.
C DRILL HOLES
1. Determine if outside trim is being used.
2. If outside trim is being used mark and drill holes on outside door face according to trim template first and install trim, then mark and drill holes for exit device according to enclosed exit device template and install.
3. If no outside trim is being used mark and drill holes according to enclosed exit device template and install.
4. A stock door backset of 2 3/4″ can be used but will decrease
the backset by 3/16″, this can be offset by not using the 1/8″
strike shim to gain 1/8″ extra clearance. This will bring the
backset within 1/16″ which is within acceptable tolerances to
operate correctly.
(OUTSIDE) 2 15/16″
DOOR
JAMB
For 1000: Important Notes: 1. If KRM Mullion is being used, install KRM mullion first, then outside trim adjusting backset according to KRM Mullion backset drawing # KRM-1000 and then install exit device. 2. If installing rim type and surface vertical rod exit devices on a pair of doors a Double Door Strike (DDS) is required. (available by special order) For revised backset dimension required for DDS use please refer to the DDS backset drawing # DDS-1000.
ROLLER STRIKE
4 13/32″ 1/4″
1 19/32
CENTER LINE
1 11/32 ”
1 19/32″
Note: Hole must be drilled per trim template, refer to trim template.
40″ Above floor
2 7/16
For mounting end cover.
B
Inside face of the door
(For complete template information and details, please refer to enclosed template.)
2 7/16″ (INSIDE)
D INSTALL CYLINDER
(Or, install other trims. See installation instructions of these outside trims.)
Outside face of the door
CYLINDER
ESCUTCHEON
E INSTALL BODY
1.Remove the head cover from the device body and end cover from the mounting bracket by removing the screws that hold them on.
2.Align tailpiece receiver of exit device and trim/cylinder tailpiece so it slides onto trim/cylinder tailpiece. Also, align screw holes on exit device head with mounting holes on the door.
3.Install and tighten the mounting screws for the head of the exit device and end cover mounting bracket.
LINER
INSTALLATION SCREW
1.Insert the cylinder into the hole on the door.
2.Keep the tailpiece horizontal.
3.Tighten the screws. 9/32″~15/32″
Tailpiece projection
Inside face of the door
F PUT ON BOTH HEAD AND END COVER
1.Install the head cover and end cover. 2.Install and tighten the mounting screws
on the head cover and end cover.
TEMPLATE FOR INSTALLING RIM EXIT DEVICE
CL
2 15/16″
EXTERIOR
DOOR
2 7/16″
INTERIOR
FRAME
CL
CL
3 5/16″ 3 5/16″
DOOR
DOOR
2″ 2 7/16″ 2 7/16″
MULLION
Rim Device on Single Door A stock door backset of 2 3/4″ can be used but will decrease the backset by 3/16″, this can be offset by not using the 1/8″ strike shim to gain 1/8″ extra clearance. This will bring the backset within 1/16″ which is within acceptable tolerances to operate correctly.
ROLLER STRIKE
Rim x Rim x Mullion on Pair of Doors If KRM Mullion is being used,install KRM mullion first, then outside trim adjusting backset according to KRM Mullion backset drawing and then install exit device.
CL
DOOR
CL
DOOR
Rim w/ DDS x Surface Vertical Rod on a Pair of Doors
When installing Rim device x SVR device on a pair of doors a Double Door Strike (DDS) is required. For complete template information, please refer to the DDS template.
DOUBLE DOOR STRIKE
2 5/8″ 3 9/32″
FOLD HERE FROM JAMB
A
A
1 19/32″
1 1/4″ drilled 1/4″ above centerline for rim cylinder for Pull Trim
3/4″ for TDE-E08 , TDE-E14 2 1/8″ for KIL/PAS Trims.
CENTER LINE
1 11/32″
4 13/32″ 1/4″
Note: Hole must be drilled per trim template, refer to trim template.
1 19/32″
Note: Refer to Door Preparation notes before drilling these holes
A
A
2 7/16″
For mounting end cover.
B
Inside face of the door
Door Preparation for Outside Trim installations: (A) Mark and drill holes on outside door face according to trim template. (B) Mark and drill holes for End cap mounting bracket and roller strike per
door preparations listed below.
Door Preparation for Exit Only installations: (A) For 1000R series (UL Listed) Drill & tap for (6) 1/4″x20 machine screws for exit device and
drill and tap for (3) 1/4″x20 machine screws for roller strike Optional fasteners:
Drill (6) 3/16″ pilot holes for self tapping machine screws or wood screws & drill (3) 3/16″ pilot holes for self tapping machine screws or wood screws for roller strike
(B) For F1000R series (UL Fire Rated) Drill 9/32″ holes inside and 3/8″ holes outside for the (6) thru bolts and drill & tap for (3) 1/4″x20 machine screws for roller strike
40″ Above floor
