AA503F Exit Device General Strike
Product Information
This product comes with door silencers that can be used on the
door frame. If the door silencers are used, the dimension for
strikes needs to be decreased accordingly. The package also
includes shakeproof lockwashers that need to be placed between the
strike and frame or mullion. The product model number is
AA503F.
Product Usage Instructions
- If you plan to use the door silencers, decrease the dimension
for strikes accordingly. - Place the shakeproof lockwasher between the strike and frame or
mullion. - Use the provided mounting screws to attach the strike to the
frame or mullion.
INSTALLATION INSTRUCTION IF DOOR SILENCERS ARE USED ON THE DOOR FRAME,
FOR STRIKES
DECREASE THIS DIMENSION ACCORDINGLY.
9/16″
Place shakeproof
lockwasher between strike
and frame or mullion
STRIKE Mounting Screws
FRAME OR MULLION
AA503F
