PRCDRX548BG 4 Inch Centerset 2 Handle Bathroom Faucet with Pop Up Drain
Bathroom Faucet
The bathroom faucet is a high-quality product designed for use
in bathrooms. It is available in multiple finishes including MB
(Matte Black), BN (Brushed Nickel), BG (Brushed Gold), CH (Chrome),
and ORB (Oil Rubbed Bronze). The faucet comes with installation
instructions, a product drawing, and care instructions.
Installation Instructions
- Before You Begin: Measure the fixed width of
the faucet, which is 3.94 inches. Also, measure the width from the
center of the first hole to the center of the second hole, which is
1.38 inches or 35mm. Ensure that the countertop thickness does not
exceed the maximum limit. - Handtighten: Attach the faucet to the
countertop by hand tightening it. - Water Supply Line: Connect the water supply
line to the faucet. - Turn On Water Supply: Turn on the water supply
and check for any leaks above and below the sink. - Confirm Proper Installation: Open the faucet
slowly and allow hot and cold water to run for at least 15 seconds
each to ensure proper installation.
Care Instructions
To maintain the quality and appearance of the bathroom faucet,
follow these care instructions:
- Rinse the product with clear water after each use.
- Dry the product with a soft cloth to prevent water spots.
- DO NOT: Use abrasive cleansers, cloths, or
paper towels. Use any cleaning agents containing acid, polish, wax,
alcohol, ammonia, bleach, solvent, or any other corrosive or harsh
chemical cleansers.
Recommended Tools
To assist with the installation, the following tools are
recommended:
- Plumber’s putty
- Thread seal tape (included)
BATHROOM FAUCET
Installation instruction
MB/BN/BG/CH/ORB
PRODUCT DRAWING
CARE INSTRUCTIONS
Rinse the product with clear water. Dry the product with a soft cloth.
DO NOT:
Use abrasive cleansers, cloths, or paper towels. Use any cleaning agents containing
acid, polish, wax, alcohol, ammonia, bleach, solvent or any other corrosive or
harsh cheminalc cleansers.
RECOMMENDED TOOLS
Plumber’s putty
Thread seal tape
Included
INSTALLATION STEPS
BEFORE YOU BEGIN
1
Fixed width is: 3.94″
Width from the center of the first hole to the center of the second hole.
1.38″/35mm
Max. countertop thickness
HANDTIGHTEN
2
WATERSUPPLYLINE
3
TURNONWATERSUPPLY
Check for leaks above and below the sink.
4
CONFIRMPROPERINSTALLATION
Open SlowlyAllow hot & cold water to run for at least 15 seconds each.
5
Open
