S 2401 Dauphine Sconce
Product Information:
| Product Name | Dauphine Sconce |
|---|---|
| Item Number | S 2401 |
| Manufacturer | Unknown |
| Care Instructions | Clean only with a soft dry cloth or feather duster. Do not use abrasive or chemical agents. |
Product Usage Instructions:
- Inspect the item and contents carefully. If any damage or
defect is found, do not install. Retain all packaging material
until installation is complete and approved. - Carefully remove all parts from the box.
- Remove the mounting plate (B) from the backplate (E) by
loosening the side screws (C). - Affix the mounting plate (B) onto the outlet box and secure it
with mounting screws (D). - Connect the hot wire (BLACK) from the fixture to the hot wire
from the outlet box. Ensure proper electrical connections. - Follow all applicable, local installation codes and guidelines
while installing the light fixture. - The installation should be done by a person familiar with the
construction and operation of the light fixture, as well as the
hazards involved.
ASSEMBLY INSTRUCTIONS
F Outlet box
GND
E
A
BC
D
Dauphine Sconce
Item # S 2401
NOTICE:
This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.
1. Carefully remove all parts from the box. 2. Remove the mounting plate (B) from the backplate (E) by loosening the
side screws (C). 3. Affix mounting plate (B) onto the outlet box and secure with mounting
screws (D). 4. Connect the hot wire (BLACK) from the fixture to the hot wire from the
outlet box (usually BLACK). Fasten them together with a plastic wire connector (A) provided and wrap the connection with electrical tape. 5. Connect the neutral wire (WHITE) from the fixture to the wire from the outlet box(usually WHITE). DO NOT REVERSE THE HOT AND NEUTRAL CONNECTIONS OR SAFETY WILL BE COMPROMISED. 6. Connect ground wire from the fixture (bare copper) to ground wire from the outlet box (usually green or copper in color). IT IS IMPERATIVE THAT THIS FIXTURE BE GROUNDED. 7. Attach the backplate (E) onto the mounting plate (B) and secure with side screws (C). 8. Place the shade (F) onto the socket cup. 9. Insert bulb (not included) into the socket. 10. Installation is complete, turn on power at fuse or circuit breaker.
Care Instructions: Clean only with a soft dry cloth or feather duster. Do not use abrasive or chemical agents.
M
LI ST ED
US
