S 2121 Large Bristol Sconce
Product Information
Product: Large Bristol Sconce
Item Number: S 2121
Manufacturer: Not specified
Product Usage Instructions
- Carefully remove all parts from the box.
- Remove the mounting plate (B) from the fixture body (E) by
loosening side screws (C). - Affix the mounting plate (B) onto the outlet box and secure it
with mounting screws (D). - Connect the hot wire (BLACK) from the fixture to the hot wire
from the outlet box. - Connect the neutral wire (WHITE) from the fixture to the
neutral wire from the outlet box. - Securely tighten all wire connections using wire nuts or
appropriate connectors. - Attach the fixture body (E) onto the mounting plate (B) and
secure it with the side screws (C). - Install the light bulb according to the recommended wattage and
type for the fixture. - Turn on the power and test the fixture to ensure it is
functioning properly.
Care Instructions
Clean the fixture only with a soft dry cloth or feather duster.
Do not use abrasive or chemical agents.
IMPORTANT: This light fixture should be
installed in accordance with all applicable, local installation
codes, and by a person familiar with the construction and operation
of it, as well as the hazards involved. Inspect the item and
contents carefully. If any damage or defect is found, do not
install. Retain all packaging material until installation is
complete and approved.
SAFETY NOTICE: This product is listed by UL
(Underwriters Laboratories) for use in the United States.
ASSEMBLY INSTRUCTIONS
F
Outlet box
GND
A
B CD
E
Large Bristol Sconce
Item # S 2121
NOTICE:
This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.
1. Carefully remove all parts from the box. 2. Remove the mounting plate (B) from fixture body (E) by loosening side
screws (C). 3. Affix mounting plate (B) onto the outlet box and secure with mounting
screws (D). 4. Connect the hot wire (BLACK) from the fixture to the hot wire from
the outlet box(usually BLACK). Fasten them together with a plastic wire connector (A) provided and wrap the connection with electrical tape. 5. Connect the neutral wire (WHITE) from the fixture to the wire from the outlet box(usually WHITE). DO NOT REVERSE THE HOT AND NEUTRAL CONNECTIONS OR SAFETY WILL BE COMPROMISED. 6. Connect ground wire from the fixture (bare copper) to ground wire from the outlet box (usually green or copper in color). IT IS IMPERATIVE THAT THIS FIXTURE BE GROUNDED. 7. Attach the fixture body (E) onto the mounting plate (B) and secure with side screws (C). 8. Insert bulbs (not included) into the sockets. 9. Clip the shade (F) onto the bulb. 10. Installation is complete, turn on power at fuse or circuit breaker.
Care Instructions: Clean only with a soft dry cloth or feather duster. Do not use abrasive or chemical agents.
