KW 2702 Avant Medium Linear Sconce
Product Information:
- Product Name: Avant Medium Linear Sconce
- Item Number: KW 2702
- Manufacturer: Unknown
- Certification: Intertek Listed
Product Usage Instructions:
- We highly recommend that the installation of this lighting
fixture be carried out by a licensed electrician. - Before starting the installation, switch off the main
electrical supply from the main fuse box or circuit breaker. - Inspect the item carefully before attempting to install. If
there is any damage or obvious defect, do not proceed with the
installation. - Note: The item may not be returned once it has been
installed. - Prior to removing, carefully unpack each piece in the top layer
of packing and retain all packing material until inspection and
installation are final. - Start the installation process by carefully removing all parts
from the box. - Loosen the side screws (I) to remove the shade (J) from the
fixture body (F). - Loosen the ball nuts (H) to remove the mounting plate (C) from
the fixture body (F). - Drill four holes on the wall, ensuring that the hole distance
matches the holes on the fixture body (F). - Knock the anchors (B) into the wall holes.
- Affix the mounting plate (C) onto the outlet box and secure it
with mounting screws (E). - Connect the hot wire (BLACK) from the fixture to the hot wire
from the outlet box (usually identified as the black wire). - Connect the neutral wire (WHITE) from the fixture to the
neutral wire from the outlet box (usually identified as the white
wire). - Securely fasten the ground wire (GREEN or BARE COPPER) from the
fixture to the ground wire from the outlet box (usually identified
as the green or bare copper wire). - Once all connections are made, carefully tuck the wires into
the outlet box and attach the fixture body (F) to the mounting
plate (C) using the ball nuts (H). - Tighten the side screws (I) to secure the shade (J) onto the
fixture body (F). - Switch on the main electrical supply from the main fuse box or
circuit breaker. - Test the installation by turning on the light switch.
CM
C
US
LIST ED
Intertek
DAMP
Avant Medium Linear Sconce Item # KW 2702
WE RECOMMEND INSTALLATION OF THIS LIGHTING FIXTURE BE DONE BY A LICENSED ELECTRICIAN. WARNING***SWITCH OFF THE MAIN ELECTRICAL SUPPLY FROM THE MAIN FUSE BOX/CIRCUIT BREAKER BEFORE INSTALLATION. INSPECT ITEM CAREFULLY BEFORE ATTEMPTING TO INSTALL. IF THERE IS ANY DAMAGE OR OBVIOUS DEFECT. DO NOT INSTALL. ITEM MAY NOT BE RETURNED ONCE IT HAS BEEN INSTALLED. NOTE: CAREFULLY UNPACK EACH PIECE IN TOP LAYER OF PACKING PRIOR TO
REMOVING. RETAIN ALL PACKING MATERIAL UNTIL INSPECTION AND
INSTALLATION ARE FINAL.
1. Carefully remove all parts from the box. 2. Remove the shade (J) from fixture body (F) by loosening side screws (I). 3. Remove the mounting plate (C) from fixture body (F) by loosening ball nuts (H). 4. Drill 4 holes on the wall and make sure the hole distance will match to the holes on the
fixture body (F). 5. Knock the anchors (B) into the wall holes. 6. Affix mounting plate (C) onto the outlet box and secure with mounting screws (E). 7. Connect the hot wire (BLACK) from the fixture to the hot wire from the outlet box (usually
BLACK). Fasten them together with a plastic wire connector (A) provided and wrap the connection with electrical tape. 8. Connect the neutral wire (WHITE) from the fixture to the wire from the outlet box (usually WHITE). DO NOT REVERSE THE HOT AND NEUTRAL CONNECTIONS OR SAFETY WILL BE COMPROMISED. 9. Connect ground wire from the fixture (bare copper) to ground wire from the outlet box (usually green or copper in color). IT IS IMPERATIVE THAT THIS FIXTURE BE GROUNDED. 10. Attach the fixture body (F) onto the mounting plate (C). Let screws (D) pass through the holes on the fixture body, then secure with ball nuts (H). 11. Secure the screws (G) to the anchors (B). 12. Insert bulbs (not included) into the sockets. 13. Attach the glass diffuser (K) to the shade (J) and secure by bending the metal tabs. 14. Attach the shade (J) to fixture body (F) and secure with side screws (I). 15. Installation is complete, turn on power at fuse or circuit breaker. ***Clean with a dry, soft cloth only. Use no harsh abrasives or chemical agents.
