JN 2086 Avery 20 Inch Sconce
Product Information
- Product Name: Avery 20 Sconce
- Item Number: JN 2086
- Features: This light fixture is designed for wall mounting and
requires a bulb (not included) for operation. - Installation Requirements: The light fixture should be
installed in accordance with all applicable local installation
codes. It should be installed by a person familiar with the
construction and operation of the fixture, as well as the hazards
involved. - Inspection: Before installation, carefully inspect the item and
its contents. If any damage or defect is found, do not install the
fixture.
Product Usage Instructions
- Carefully remove all parts from the box and place them on a
clean, soft surface. - Remove the mounting plate (A) from the fixture (E) by
unscrewing screws (D). - Install the mounting plate (A) to the junction box and secure
it with the provided mounting screws (B). - Wrap the fixture ground wire (bare copper) around the green
grounding screw on the mounting plate. - Connect the fixture’s wires to the corresponding wires in the
junction box using wire connectors or electrical tape. Ensure
proper insulation and secure connections. - Attach the fixture (E) to the mounting plate (A) using the
screws (D). - Install a bulb (not included) according to the manufacturer’s
instructions.
Care Instructions
Clean the light fixture only with a soft dry cloth or feather
duster. Do not use abrasive or chemical agents.
Safety Certification
This product is UL Listed for use in the United States.
ASSEMBLY INSTRUCTIONS
Diagram 1
AB C
DE
F (Packaged separately) Bulb not included
Avery 20″ Sconce
Item # JN 2086
NOTICE:
This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.
TOOLS REQUIRED (NOT INCLUDED):
Phillips Screwdriver
Slotted Screwdriver
Scissors
1. Carefully remove all parts from the box. Place on a clean, soft surface. 2. Remove mounting plate (A) from fixture (E) by removing screws (D). 3. Install mounting plate (A) to the junction box and secure with
mounting screws (B). 4. Wrap fixture ground wire (bare copper) around the green grounding
screw (see diagram 1). Tighten. Continue fixture ground wire and connect to supply ground wire (usually green or bare copper) using wire nut (C). NOTE: It is imperative that the fixture is grounded. 5. Connect fixture neutral wire (white) to the supply neutral wire (usually white) using wire nut (C). 6. Connect fixture hot wire (black) to the supply hot wire (usually black) using wire nut (C). CAUTION: Do not reverse the hot and neutral connections. 7. Make sure all wire connections are tight, then carefully tuck into the junction box. 8. Install fixture (E) to mounting plate (A) and secure with screws (D). 9. Install light bulb into the socket. 10. Remove shade (F) from packaging, then clip shade (F) onto the bulb. NOTE: If shade has additional packaging, carefully cut off from interior of shade to avoid damages.
Care Instructions: Clean only with a soft dry cloth or feather duster. Do not use abrasive or chemical agents.
M
LI ST ED
US
