ARN 2202 Fontaine Double Sconce
Product Information:
The Fontaine Double Sconce, item # ARN 2202, is a light fixture
that requires assembly and installation. It does not come with a
bulb included. This product should be installed in accordance with
all applicable local installation codes by a person who is familiar
with its construction and operation, as well as the associated
hazards. Please inspect the item and its contents carefully upon
receipt, and if any damage or defect is found, do not proceed with
installation. Retain all packaging material until installation is
complete and approved.
Tools Required (Not Included):
- Phillips Screwdriver
- Slotted Screwdriver
Usage Instructions:
- Carefully remove all parts from the box and place them on a
clean, soft surface. - Using a Phillips screwdriver, remove the screws (C) to detach
the mounting plate (A) from the fixture body (D). - Install the mounting plate (A) to the junction box and secure
it with the included mounting screws (B). - Wrap the fixture ground wire (bare copper) around the green
grounding terminal in the junction box. - Connect the fixture wires to the corresponding wires in the
junction box, following proper electrical wiring practices. - Tighten all wire connectors securely.
- Attach the fixture body (D) to the mounting plate (A) using the
screws (C). - Insert a compatible bulb into the fixture socket, ensuring it
is securely in place. - Turn on the power and test the fixture to ensure it is
functioning properly.
Care Instructions:
To clean the Fontaine Double Sconce, use only a soft dry cloth
or a feather duster. Do not use abrasive or chemical agents, as
they may damage the fixture.
ASSEMBLY INSTRUCTIONS
F
Bulb not included
Diagram 1
E
D CGB
A
Fontaine Double Sconce
Item # ARN 2202
NOTICE:
This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.
TOOLS REQUIRED (NOT INCLUDED):
Phillips Screwdriver
Slotted Screwdriver
1. Carefully remove all parts from the box. Place on a clean, soft surface. 2. Remove mounting plate (A) from fixture body (D) by removing
screws (C). 3. Install mounting plate (A) to the junction box and secure with the
mounting screws (B). 4. Wrap fixture ground wire (bare copper) around the green grounding
screw (see diagram 1). Tighten. Continue fixture ground wire and connect to supply ground wire (usually green or bare copper) using wire nut (G). NOTE: It is imperative that the fixture is grounded. 5. Connect fixture neutral wire (white) to the supply neutral wire (usually white) using wire nut (G). 6. Connect fixture hot wire (black) to the supply hot wire (usually black) using wire nut (G). CAUTION: Do not reverse the hot and neutral connections. 7. Make sure all wire connections are tight, then carefully tuck into the junction box. 8. Install fixture body (D) to mounting plate (A) and secure with screws (C). 9. Install light bulbs into the sockets. 10. Install shade (F) to shade holder (E).
Care Instructions: Clean only with a soft dry cloth or feather duster. Do not use abrasive or chemical agents.
