JRT2000R JRT VersaTemp Heat Chill Pump
Product Information
The Jandy VersaTemp is a high-performance heat pump designed to
efficiently heat your pool and spa. It features an easy-to-access
digital LCD controller for touch-button operation and
self-diagnostic notifications in your preferred language. The heat
pump comes in three models: JRT2000R, JRT2500R, and JRT3000R, each
with different specifications and dimensions.
Specifications:
- Output (BTU): JRT2000R – 103,000, JRT2500R –
116,000, JRT3000R – 130,000 - Input (kWH): JRT2000R – 4.72, JRT2500R – 5.23,
JRT3000R – 6.57 - COP Output (BTU): JRT2000R – 96,000, JRT2500R
– 109,000, JRT3000R – 124,000 - COP Output (BTU): JRT2000R – 6.1, JRT2500R –
6.1, JRT3000R – 5.6 - COP Output (BTU): JRT2000R – 62,000, JRT2500R
– 70,000, JRT3000R – 82,000 - Voltage: 208/230V/60Hz
- Minimum Circuit Ampacity: JRT2000R – 38,
JRT2500R – 39, JRT3000R – 40 - Max Over Current Protection: JRT2000R – 40,
JRT2500R – 50, JRT3000R – 50 - LRA: JRT2000R – 178, JRT2500R – 145, JRT3000R
– 148 - RLA: JRT2000R – 28.3, JRT2500R – 29, JRT3000R
– 32.5 - Compressor: Scroll Titanium
- Heat Exchanger: JRT2000R – 48, JRT2500R – 48,
JRT3000R – 57 - Optimal Water Flow (GPM): JRT2000R – 20,
JRT2500R – 20, JRT3000R – 30 - Minimum Water Flow (GPM): 42
- Maximum Water Flow (GPM): JRT2000R – 232,
JRT2500R – 242, JRT3000R – 252 - Weight: JRT2000R – 232 lbs, JRT2500R – 242
lbs, JRT3000R – 252 lbs
Dimensions:
- JRT2000R: 11-1/2″ H x 10″ W x 42″ D
- JRT2500R: 11-1/2″ H x 10″ W x 42″ D
- JRT3000R: 11-1/2″ H x 10″ W x 45″ D
Product Usage Instructions
To operate the Jandy VersaTemp heat pump, follow these
steps:
- Ensure the heat pump is properly installed and connected to a
power source. - Press the power button on the digital LCD controller to turn on
the heat pump. - Use the touch buttons on the controller to adjust the desired
temperature for your pool and spa. - The heat pump will start heating the water and maintain the set
temperature. - If any self-diagnostic notifications appear on the LCD display,
refer to the user manual for troubleshooting steps. - To control the heat pump remotely, download and install the
iAquaLink app on your mobile device. Connect the app to the heat
pump and enjoy on-the-go operation.
Note: It is important to ensure proper water flow within the
specified range (minimum and maximum GPM) for optimal performance
of the heat pump. Refer to the user manual for additional
maintenance and safety instructions.
Easy to Operate
An easy-to-access digital LCD controller enables touch-button operation and displays self-diagnostic notifications written in wording that makes sense to you, in the language of your choice.
SPECIFICATIONS
Output (BTU) Input (kWH) COP Output (BTU) COP Output (BTU) COP Voltage Minimum Circuit Ampacity Max Over Current Protection LRA RLA Compressor Heat Exchanger Optimal Water Flow (GPM) Minimum Water Flow (GPM) Maximum Water Flow (GPM) Weight
DIMENSIONS
JRT2000R 103,000 4.72 6.4 96,000 6.1 62,000 4.1 208/230V/60Hz 38 40 178 28.3
42 20
232
JRT2500R 116,000 5.23 6.5 109,000 6.1 70,000 4.1 208/230V/60Hz 39 50 145 29
Scroll Titanium 48 20
70 242
JRT3000R 130,000 6.57 5.8 124,000 5.6 82,000 4.0 208/230V/60Hz 40 50 148 32.5
57 30
252
B
Dual Thermostats
Have your pool heated and your spa too! Dual thermostats allow you to enjoy your pool/spa combo as you like with water that’s warm enough for you to swim in and a spa that’s perfectly heated for a relaxing soak.
82°
Pool
102°
Spa
A
C
MODEL
A
JRT2000R
42″
JRT2500R
42″
JRT3000R
45″
Jandy.com | 1.800.822.7933
©2022 Zodiac Pool Systems LLC. All rights reserved. ZODIAC® is a registered trademark of Zodiac International, S.A.S.U., used under license. Apple and the Apple logo are trademarks of Apple, Inc., registered in the U.S. and other countries. App Store is a service mark of Apple, Inc., registered in the U.S. and other countries. Google Play and Google Play logo are trademarks of Google LLC. All other trademarks are the property of their respective owners. 9697_SL
11-1/2″ 10″
DIMENSIONS B 32″ 32″ 32″
3″
C 32″ 32″ 32″
HIGH PERFORMANCE. LESS NOISE.
WHY SETTLE FOR JUST WARM WHEN YOU CAN HAVE IT ANY WAY YOU LIKE…
The Jandy® VersaTempTM Heat / Chill pump with SoundShieldTM Technology regulates your pool and spa’s temperature for the utmost comfort while significantly reducing operational noise. Designed for energy-efficient, eco-friendly performance and dual thermostats for pool/spa combinations, the VersaTemp offers intuitive operation with a built-in LCD panel and compatibility with AquaLink® automation systems for anytime, anywhere iAquaLink® app control.
Anytime, Anywhere Control
Enjoy the convenience of on-the-go operation with the iAquaLink app.
Performance that Saves
Bring on the heat with more BTU’s! The VersaTemp takes performance to the next level with increased heat output for more efficient and faster heating.
SoundShieldTM Technology
Not a fan of loud noises? Heat your pool and/or spa with significantly less noise. Specially designed SoundShield Technology consists of a swept-wing blade design to decrease turbulence and a decibel dampening acoustic blanket to help muffle compressor reverberation for even quieter operation–because you should feel the heat, not hear the heat pump.
Perfect Pool Temperature Year-Round
Why settle for just warm when you can have it any way you like… No matter what your preference, Jandy VersaTempTM features innovative thermo control technology that can make your pool watBeyrpatshseMopdeerfect temperature by either Hderaat Mwoidneg heat from the air to warm the water or removing the heat from your pool to cool it down.
Smaller Footprint
The VersaTemp features a smaller footprint* for more compact pool pad setups.
*Versus previous models
VersaTemp
32″
Previous Models
35.81″
32″
41.43″
