21516OT Outdoor Wall Lantern Sconce

Outdoor Wall Sconce Instruction Manual

Product Description

The Outdoor Wall Sconce package contains:

• Fixture (Part A) x 1
• Glass (Part B) x 4
• Decorative Part (Part C) x 1
• Long Mounting Screw (Part CC) x 2
• Crossbar (Part DD) x 1
• Wire Nut (Part BB) x 3

The Outdoor Wall Sconce is an outdoor light fixture that
requires assembly before use. The product is manufactured in
China.

Safety Information

Please read and understand the entire manual before attempting
to assemble, operate, or install the product. Do not attempt to
assemble the product if any part is missing or damaged. Estimated
assembly time is 25 minutes. Tools required for assembly (not
included) are: Flathead screwdriver, Phillips screwdriver, Pliers,
Electrical tape, Wire cutters, and Safety glasses. Helpful tools
(not included) are: Wire strippers and Step ladder.

Assembly Instructions

1. Attach bulbs, glass, and decorative part into the fixture body
   using hardware A, B, and C as shown in the figure on the
   right.
2. Attach the crossbar (DD) to the outlet box (not included) with
   the long mounting screws (CC).
3. Strip 3/4 in. of insulation from wire ends. Twist stripped ends
   together with pliers (not included), black to black (power), and
   white to white (neutral). Attach copper wire to ground wire.
   Helpful hint: If necessary, attach copper ground wire to grounded
   outlet box.
4. Attach wire nuts (BB). Tape wire nuts (BB) and wires
   together.
5. Align the 2 screws (AA) through the holes of the back plate and
   fix them with screw nuts.

Usage Instructions

After completing the assembly, install the light fixture onto
the desired location. To avoid any waterproofing problems, make
sure the light fixture fits the mounting surface perfectly. It is
recommended to use waterproof glue around the canopy for better
sealing after installation.

Customer Service

If you have any questions or concerns about the product, please
contact customer service at [email protected].

Instruction Manual

Outdoor Wall Sconce

HARDWARE CONTENTS(shown actual size)

ABA

BBB

CBC

DBD

Print in china

PACKAGE CONTENTS

PART A Fixture B Glass C Decorative part

DESCRIPTION

C
A
B
QUANTITY 1 4 1

Long monting x 2 screw

Wire nut x 3

Long monting x 2 screw

Crossbar (Not actual size) x 1

SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate or install the product.

WARNING
· TURN OFF ELECTRICITY at main fuse box (or circuit breaker box) before beginning installation by removing fuse (or switching off circuit breaker). · MINIMUM 90°C SUPPLY CONDUCTORS.
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. Estimated Assembly Times: 25 minnutes Tools Required for Assembly (not included): Flathead screwdriver , Phillips screwdriver, Pliers, Electrical tape, Wire cutters, Safety glasses. Helpful Tools (not included): Wire strippers, Step ladder.
Customer Service: [email protected]

ASSEMBLY INSTRUCTIONS

1. As shown in the figure on the right,

1

attach bulbs, glass and decorative part

into the fixture body.

Hardware Used

A Fixture

x1

B Glass

x4

C Decorative part

x1

2. Attach the crossbar (DD) to the outlet box 2 (not included) with the long mounting screws (CC).
Hardware Used

CC Long mounting screw

x2

DD Crossbar

x 1

3. Strip 3/4 in. of insulation from wire ends. 3 Twist stripped ends together with pliers (not included), black to black (power) and white to white (neutral). Attach copper wire to ground wire. Helpful hint: If necessary, attach copper ground wire to grounded outlet box.

C B
A
DD CC

ASSEMBLY INSTRUCTIONS

4. Attach wire nuts (BB).Tape wire nuts (BB) 4 and wires together.
Hardware Used

BB Wire nut

x3

BB

5. Align the 2 screws(AA) through the holes 5

of the back plate, and fix them with screw

DD

nuts

Hardware Used

AA Long mounting screw

x 2

DD Crossbar

AA
x 1

CAUTION: To avoid any waterproofing problems, please make sure the light fixture fits the mounting surface perfectly installation and use waterproof glue around the canopy for better sealing after installation.

Print in china
