4 121 71 Connected Contactor
Product Information:
Product Name: Connected Contactor 4 121 71 – 1 991 22
Required Installation: Gateway module
Compatible with: Connected Starter Pack with Netatmo or any kind
of gateway with Netatmo
Dimensions: 84.5 mm (LE12070AE)
Composition: Control wiring
Standards: EN 60669-2-1
Self-protected: L
MCB: C1, C2
Line OUT: ON/OFF AUTO
Connected Contactor dimensions: 17.8 mm
Product Usage Instructions:
- Ensure the installation of a gateway module before using the
Connected Contactor. - If using the Connected Starter Pack, make sure it is compatible
with Netatmo. Alternatively, any kind of gateway with Netatmo can
be used. - Connect the control wiring according to the provided
composition. - Make sure the product meets the EN 60669-2-1 standards.
- The Connected Contactor is self-protected and has MCBs
(Miniature Circuit Breakers) labeled as C1 and C2. - Connect the line OUT to the desired power source using the
ON/OFF AUTO switch. - The dimensions of the Connected Contactor are 17.8 mm.
- For any further information or assistance, visit
www.legrand.fr/reference/412171 or refer to the provided UE
declaration of conformity at www.legrandoc.com.
Connected Contactor 4 121 71 – 1 991 22
Requires the installation of a:
Gateway module
Connected Starter Pack “… with Netatmo”
OR
OR
Any kind of “with Netatmo”
gateway
84.5 mm LE12070AE
Composition
Control wiring
EN 60669-2-1
authorized
L
Self-protected
C1
C2
MCB
line OUT
ON/OFF AUTO
17.8 mm Connected Contactor
F
11 2
oooooooooooooooo
3 oooooooooooooooo
4ooo5ooo6ooooooooooooooooooo
1 1 2 oooooooooooooooo
2
3 oooooooooooooooo
3
4oo5ooooooooo
4
ooo6ooooooooooo
5
oooo7ooooooo
8
6
ooooooo9oooooooo
7
oooooooo10
8
ooooooooo1o1ooo 12
9
oooooo
13
10
ooooooooooooo1o4
11
ooooooooooo
15 16
12
oooooooooooooooo17
13
oooooooooooooo 18
14 ooooooooooo
19 20
15
oooooooooooooo
16
oooooooooooo
17
ooooooooooooooo
21 22 23 24
oooooooo7ooo8ooo9oooooooooooo 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30
18
oooooooooooooo
19 ooooooooooo
20
oooooooooooooooo
25 26 27 28
21
oooooooooooooo
29
22 ooooooooooo
30
23
oooooooooooooo
24
oooooooooooooooo
25 ooooooooooo
26
oooooooooooooooo
27
oooooooooooooo
28 ooooooooooo
29
oooooooooooooo
30
oooooooooooo
Mar
Feb
Jan
kWh
C1
C2
C1
C2
Load
N
L
LED FLUO
2,4 à 2,4835Ghz <100 mW
Silent < 10dB
Planning Measure 4800W
2400VA
EV plug remote
3840W
650W
3000W
Shedding
U
I
kWh
-5°C +45°C
100-240V~ 50/60Hz
20A MAX
Connected shedding compatible
Imperative security precaution
The instructions for installation and use must be strictly observed in order to avoid the risk of electric shock or fire.
1 Preparation, connection
OFF
Turn off the power at general
circuit breaker
PZ1 4 mm
C1, C2: MAX
9mm 2x 1.5mm² 2.5mm²
N, L, Load:
MAX 2x 2.5mm²
6mm²
C1,C2, N, L, Load:
MIN : 0.8Nm MAX : 1.4Nm
Wiring examples
Thanks to its control circuit with integrated power and protection, you no longer need to install a circuit breaker 2A to protect the control circuit if you wire a contact between C1 and C2.
For the protection of the Connected Contactor, it is recommended to use a circuit breaker or a gG fuse with current rating 20A.
controled by the energy supplier electric meter
Swimming pool pump and anothers motors
EV plug remote
2A
C1
C2
20AX
: I ON
: AUTO
: O OFF
Load
N
L
2A
C1
C2
20AX
: I ON
: AUTO
: O OFF
Load
N
L
2A
C1
C2
20AX
: I ON
: AUTO
: O OFF
Load
N
L
4 121 71 4 121 71 4 121 71
Control of heaters through an installed central remote
Control of a power single line contactor by a connected contactor *
Control of a power three lines contactor by a connected contactor *
2A
C1
C2
20AX
: I ON
: AUTO
: O OFF
Load
N
L
L
C1
C2
20AX
: I ON
: AUTO
: O OFF
Load
N
L
C1
C2
20AX
: I ON
: AUTO
: O OFF
Load
N
L
4 121 71 4 121 71 4 121 71
*: Non-functional consumption measurement when controlling a single line or a three lines power contactor by a connected contactor.
N (neutral) = blue
L (Line) = Everything but blue and green/yellow
Line after contact = usually purple, orange…
2
2 Add the Contactor in a connected installation
OFF
ON
Turn off the power at general circuit breaker
Turn on the power at the general circuit breaker*
once the installation
completed and controlled**
* In order to restart all connected products at the same time.
**: After wiring the installation, refit the front plate so that no active live part is accessible.
3 Finalize the installation in the Legrand Home + Control app
Download the Home + Control App and follow the instructions for adding the connected product in your setup.
You also have the option of controlling your installation via a voice assistant. and can customize your scenarios via the Home + Control App.
Use by manual control and status LED
Automatic Mode
OFF
AUTO OFF
AUTO ON
ON
ON/OFF Mode
OFF
ON
3
Reset a Connected Contactor to remove it from a connected installation
Press the configuration button of the Connected Contactor
(> 5 seconds) until the configuration indicator lights up
in fixed red. It is no longer associated with the gateway
present in the installation.
>5s
www.legrand.fr/reference/412171
LEGRAND – Pro and Consumer Service – BP 30076 87002 LIMOGES CEDEX FRANCE · www.legrand.com
UE SIMPLIFIED DECLARATION OF CONFORMITY
The undersigned,
Legrand
declares that the radio equipment listed on this instruction sheet are compliant to the directive 2014/53/UE.
The full text of the UE declaration of conformity is available at the following website:
www.legrandoc.com
4
