Puig 20795 New Generation Sport Wind Shield Triumph Speed Triple
MOUNTING INSTRUCTIONS
WINDSHIELD NG SPORT
DESCRIPTION
| ID. | PIEZA/PART | DESCRIPCIÓN | DESCRIPTION | QTY. | REF.: |
| 1 |  | Cúpula sport | Sport screen | 1 | 20795W/H/N/FM3 |
| 2 |  | Metal suport | 1 | SOP1P6—— 20795 | |
| 3 |  | M5x11 Ø11 ISO 7380 allen screw | 2 | TORNI-AI—– 520 | |
| 4 |  | Ø12xØ6×9 silentblock | 4 | AROPASACABLES-3 | |
| 5 |  | Ø12xØ6,8×7,3 bush with flange | 4 | CASQUI-1A—750 | |
| 6 |  | M5x16 Ø11 ISO 7380 allen screw | 4 | TORNI-I7380-493 | |
| 7 |  | M5 ISO 7380 screw cap | 4 | TAPON——- 85 | |
| V0.11/21 Pg. 1/2 Created by: www.rrdisseny.cat | |||||
