JYL9925A Bee 13.5 Inch 3-Light Modern Bohemian Iron Glass LED Pendant
Product Information
This is a lighting fixture that requires installation by a
licensed electrician. It comes with a lifting loop, lamp body, lamp
shade, nut, chain, hanging loop, loop with closable link, canopy,
mounting plate, mounting screw, and 3 x 4W LED bulbs. The fixture
can be used with Type B bulbs with a maximum wattage of 40W, CFL
bulbs with a maximum wattage of 13W, or LED bulbs with a maximum
wattage of 9W.
Product Usage Instructions
- Switch off the main electrical supply from the fuse box/circuit
breaker before installation. - Inspect the item carefully before attempting to install. Do not
install if there is any damage or obvious defect. - Fix the lifting loop to the lamp body by turning it
clockwise. - Insert the bulbs into the sockets. Make sure to use light bulbs
with a wattage no greater than specified on the fixture. Always
turn off the electrical current before changing bulbs. - Place the lamp body into the lamp shade and secure it by
turning the nut clockwise. - Screw the chain to the hanging loop and the loop of the loop
with closable link. - Insert wires through the chain, hanging loop, canopy, and
mounting plate. - Separate the mounting plate from the canopy by unscrewing the
canopy nut anti-clockwise. - Fix the mounting plate to the junction box with the mounting
screw. - Connect the hot, black or red outlet supply wire to black
parallel cord (round & smooth) clear, brown, gold or black
without tracer (colored insulated wire (not green) with a copper
metal conductor). - Connect the neutral, white outlet supply wire to white parallel
cord (square & ridged) clear, brown, gold or black with tracer
(colored stripes) insulated wire (not green) with silver metal
conductor. - Wrap the ground wire from the outlet box around the green
ground screw on the mounting bracket and tighten the ground screw.
If the fixture is supplied with a ground wire, connect it to the
outlet ground wire with a wire connector. - Attach the canopy to the junction box and fix it by turning the
canopy nut clockwise. - Enjoy your lamp!
WARNING WE RECOMMEND INSTALLATION OF THIS LIGHTING FIXTURE BE DONE BY A LICENSED ELECTRICIAN. WARNING *** SWITCH OFF THE MAIN ELECTRICAL SUPPLY FROM THE MAIN FUSE BOX/CIRCUIT BREAKER BEFORE INSTALLATION. INSPECT ITEM CAREFULLY BEFORE ATTEMPTING TO INSTALL. IF THERE IS ANY DAMAGE OR OBVIOUS DEFECT, DO NOT INSTALL. ITEM MAY NOT BE RETURNED ONCE IT HAS BEEN INSTALLED.
CARE AND MAINTENANCE To clean the outside of the fixture, use a dry or slightly dampened clean cloth (use clean water, never a solvent) to wipe the surface of the fixture. To clean the inside of the fixture, first disconnect power to the fixture by turning off the circuit breaker or by removing the fuse at the fuse box. Next, use a dry or slighly damperned clean clorth (use clean water, never a solvent) to wipe the interior surface of the fixture. Do not use any cleaners with chemical, solvents or harsh abrasives. Use only a dry soft cloth to dust or wipe carefully.
NOTICE& IMPORTANT SAFETY INSTRUCTIONS * Please make sure that you have all parts indicated before you begin assembly of this item * This item should be assembled on a soft surface to prevent scratching the finish during assembly * To reduce the risk of fire, electrical shock or injury to persons or property, please follow the guideline below for safe use and installation *The external flexible cable or cord of this luminaire cannot be replaced If the cord is damaged, the luminaire shall be destroyed
Part List and Hardware List
Model#: JYL9925 Product Dimensions: Ø13.5″X17.576.5″H
PREPARATION 1/2
Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. Estimated Assembly Time: 20 minutes.
1. Turn clockwise to fix the lifting Loop (K) to the Lamp Body (J)
2. Insert the bulbs (M) into the Sockets. Be sure to use light bulb(M) with wattage no greater than specified on this fixture. Always make sure that electrical current is turned off before changing bulbs.
3. Carefully place the Lamp Body (J) into the Lamp Shade (L) and turn the Nut (G) clockwise to secure it
4. Screw the Chain(E) to the Hanging Loop(C) and the loop of the Loop with Closable Link(F) 5. Insert wires through the Chain(E), Hanging Loop(C),Canopy(B) and Mounting Plate(A).
6. Separate the Mounting Plate(A) from the Canopy (B) by unscrewing the Canopy Nut(D)anti-clockwise.
7. Fix the Mounting Plate(A) to the junction box with Mounting Screw (H).
Connect, Hot, Black or Red Outlet Supply Wire to: Black
* Parallel Cord (round & smooth)
Clear, Brown, Gold or Black without Tracer
(colored
Insulated Wire (not greesnt)riwpeitsh)copper metal conductor
Connect, Neutral, White Outlet Supply Wire to: White
* Parallel Cord (square & ridged)
Clear, Brown, Gold or Black with Tracer (colored stripes)
Insulated Wire (not green) with Silver metal conductor.
*Note: When parallel wire ( SPT I & SPT II ) is used. The neutral wire is square shaped and ridged and the hot wire will be round in shape and smooth. ( See Illustration on left. )
Grounding Instructions: a) For installation in the United States: Wrap ground wire from outlet box around green ground screw on mounting bracket, no less than 2″ from wire end. Tighten ground screw. If fixture is supplied with a ground wire, connect to outlet ground wire with a wire connector. b) For installation in Canada: If fixture is supplied with ground wire, wrap ground wire around green grounding screw on mounting bracket. Tighten ground screw.
8. Attach the Canopy(B) to the junction box and fix it by turning the Canopy Nut (D) clockwise.
PLEASUE USE TYPE”B” BULB MAX 40-WATT OR CFL BULB MAX 13-WATT OR LED MAX 9-WATT THERE ARE 3 X 4W LED BULBS IN THE BOX.
ENJOY YOUR LAMP
2/2
