Univex 8713m 13-inch Manual Gravity Feed Heavy Duty Meat Slicer User Manual

univex 8713M 13-Inch Manual Gravity Feed Heavy Duty Meat Slicer

Features

• Medium to heavy duty, high volume slicer
• Maximum duty 8 hours a day
• Capable of slicing unlimited amounts of cheese
• Unique drip tray fence redirects liquids away from controls and operator towards distinctive concave base casting for easy cleaning
• Ergonomic comfort design operation
• Powerful 1⁄2 hp motor standard
• Adjustable slice thickness from 0 to 7⁄8″
• Easily removable sharpener for cleaning
• Quick and simple disassembly of carriage and feed grip for easy and thorough cleaning
• Sanitary polished and anodized aluminum construction
• Permanently mounted protective edge guard for operator safety
• Heavy duty 3-1⁄2 lb gravity fed grip
• 3 inch legs make cleaning under the slicer simpler for the user

Optional Accessories

• Serrated steel blade
• Heavy duty clear plastic cover
• tainless steel vegetable chute
• Sturdy stainless steel stand
• Security reinforced prison package

Warranty

• One year, on-site parts and labor

Univex Slicers are not intended for semi-froze or frozen product except for Model 8713M with frozen blade package.

Premium Series Slicer

• Controls: Manual slice thickness knob, push button on/off, attached blade sharpener
• Drive Assembly: Gear driven
• Blade diameter: 13″ (33cm) razor sharp blade
• Blade RPM: 300 RPM
• Maximum slice thickness: .875″ (2.2cm)
• Maximum product size: Rectangular: 10″ x 6.5″ (25.4cm x 16.5cm)
• Square: 6.5″ x 6.5″ (16.5cm x 16.5cm)
• Round: 9″ (22.9cm)
• Construction: Anodized, cast aluminum body for durability and stunning looks

Univex Corporation: www.Univexcorp.com

3 Old Rockingham Rd Salem, NH 03079 United States of America

• TEL: (800)258-6358
• INTL TEL: (603)893-6191
• FAX: (800)356-5614
• INTL FAX: (603)893-1249
