KT-BPLED35PS-14C-8CSA-VDIM Backlit LED Panel Light

Product Information

Product Usage Instructions

Power and Color Selection

The KT-BPLED35PS-14C-8CSA-VDIM BACKLIT LED PANEL LIGHT allows
you to select the power and color settings. Follow the steps below
to make your selection:

1. Power Selection:
   • Choose between 35W, 30W, or 20W by using the power select
     feature.
2. Color Selection:
   • Choose between 3500K, 4000K, or 5000K by using the color select
     feature.

Product Specifications

Accessories

Sensors

Cord Sets

POWER SELECT COLOR SELECT
KT-BPLED35PS-14C-8CSA-VDIM
BACKLIT LED PANEL LIGHT
DESCRIPTION 1’x 4′ LED Panel | 35/30/20W | 3500/4000/5000K 120-277V input | 0-10V dimming | Contractor Prime

Page 1 of 5

PRODUCT FEATURES

· Features Keystone Color Select technology. Adjust CCT between 3500/4000/5000K

· Compatible with Keystone SmartSafe

· Features Keystone Power Select technology. Adjust power between 35/30/20W

LED emergency backup

· Extruded aluminum frame with precision laser welded corners and satin white powder coating · Over 50% energy savings compared to

· Suitable for recessed or surface mount (with optional accessories)

traditional fluorescent troffers

· Construction features precise optical lenses over each individual LED, offering optimal light · Operating temp range -20ºC/-4ºF to

diffusion and consistent surface illumination, with no risk of yellowing over product lifetime

40ºC/104ºF

· UL Certified for Dry/Damp locations

· IC Rated

· Powered by Keystone 0-10V dimmable LED driver with built-in junction box

PERFORMANCE SPECIFICATIONS

Catalog Number KT-BPLED35PS-14C-8CSA-VDIM

Nominal Size Selectable Wattage 35

1′ x 4′

30

20

Selectable CCT 3500K 4000K 5000K 3500K 4000K 5000K 3500K 4000K 5000K

* Preset to (5000K) * Color Uniformity: CCT (Correlated Color Temperature) range as per guidelines outlined in ANSI C78.377-2017.

Lumens 3950 4200 4000 3450 3700 3500 2400 2600 2450

Efficacy 113 lm/W 120 lm/W 114 lm/W 115 lm/W 123 lm/W 117 lm/W 120 lm/W 130 lm/W 123 lm/W

Input Voltage Dimmable DLC CRI

120-277V

0-10V

Yes >80

Keystone Technologies · Philadelphia, PA · Phone (800) 464-2680 · www.keystonetech.com Specifications subject to change. Last revised on 05.30.23

POWER SELECT COLOR SELECT
KT-BPLED35PS-14C-8CSA-VDIM
BACKLIT LED PANEL LIGHT

Page 2 of 5

PHOTOMETRIC SPECIFICATIONS
POLAR CANDELA DISTRIBUTION

-165° 180° 165°

-150°

150°

-135°

135°

-120°

120°

-105°

105°

-90°

90°

300

-75°

600

75°

-60°

900

60°

-45°

1200

45°

-30°

1500

30°

-15° 0° 15°

Average beam angle (50%) :115.9° 1 Violet C0/180, 115.5

Unit: cd

2 Green C90/270, 116.3

FLUX CHART
Flux Out: 2940 lm

1.219 m 245.9/892.2 lx 2 m 91.36/331.6 lx 3 m 40.61/147.4 lx 4 m 22.84/82.89 lx 5 m 14.62/53.05 lx 6 m 10.15/36.84 lx 7 m 7.458/27.07 lx 8 m 5.710/20.72 lx 9 m 4.512/16.37 lx 10 m 3.655/13.26 lx

386.75 cm 634.44 cm 951.66 cm 1268.88 cm 1586.09 cm 1903.31 cm 2220.53 cm 2537.75 cm 2854.97 cm 3172.19 cm

47.80″

ISOCANDELA PLOT
90°

80°

70°

60°

50°

40°

30°

20°

10°

0°

-10°

-20°

-30°

-40°

-50°

-60°

-70°

-80°

-90° -90° -80° -70° -60° -50° -40° -30° -20° -10° 0° 10° 20° 30° 40° 50° 60° 70° 80° 90°

cd: 132.6(10%) cd: 265.3 (20%) cd: 397.9 (30%) cd: 530.5 (40%)

cd: 663.2 (50%) cd: 795.8 (60%) cd: 928.4 (70%) cd: 1061 (80%)

Imax: 1326 (H0.5, V-1.0) (At: C=100.0, Gamma=1.0)

PHYSICAL SPECIFICATIONS

Top View

Side View

11.81″

1.47″

Back View

Height Eavg/Emax

Angle: 115.54°

Diameter

Keystone Technologies · Philadelphia, PA · Phone (800) 464-2680 · www.keystonetech.com Specifications subject to change. Last revised on 05.30.23

POWER SELECT COLOR SELECT
KT-BPLED35PS-14C-8CSA-VDIM
BACKLIT LED PANEL LIGHT

Page 3 of 5

ACCESSORIES

SENSORS

Factory-Installable OR Field-Installable (field-installable purchased separately)

P SUFFIX* CATALOG NUMBER

DESCRIPTION

/FC1-PIR

KTSL-FC1-UV-KO-PIR

Bluetooth Mesh Wireless Fixture Controller for SmartLoop System with remote mountable daylight and PIR motion sensor. 120-277V. 3A Max Load with 0-10V Dimming

UPC

EASY CODE

843654129259 MGZ-59

Smart Loop PIR Sensor KTSL-FC1-UV-KO-PIR
Note: Keystone SmartLoop is a DLC Qualified Network Lighting Control solution, offering advanced functions such as complete wireless control, zoning, high-end trim, occupancy/vacancy sensing, scene setting, and scheduling. To learn more about SmartLoop, please visit http://www.keystonetech.com/smartloop.

CORD SETS

Factory-Installable OR Field-Installable (field-installable purchased separately)

P SUFFIX*

CATALOG NUMBER

DESCRIPTION

/515P6

KT-CS-515P-6-18/3

Cord set for high bay; 125V NEMA 5-15P; straight blade plug; 6′ SJTOW cable; 18/3 wire

/L715P10

KT-CS-L715P-10-16/3

Cord set for high bays; 277V NEMA L7-15P; twist lock plug; 10′ SJTOW cable; 16/3 wire

/L615P10

KT-CS-L615P-10-16/3

Cord set for high bays; 250V NEMA L6-15P; twist lock plug; 10′ SJTOW cable; 16/3 wire

/L515P10

KT-CS-L515P-10-16/3

Cord set for high bays; 250V NEMA L5-15P; twist lock plug; 10′ SJTOW cable; 16/3 wire

/L715P6

KT-CS-L715P-6-16/3

Cord set for high bays; 277V NEMA L7-15P; twist lock plug; 6′ SJTOW cable; 16/3 wire

/L615P6

KT-CS-L615P-6-16/3

Cord set for high bays; 250V NEMA L6-15P; twist lock plug; 6′ SJTOW cable; 16/3 wire

/L515P6

KT-CS-L515P-6-16/3

Cord set for high bays; 250V NEMA L5-15P; twist lock plug; 6′ SJTOW cable; 16/3 wire

/MC-63

KT-MC-NP-6-18/3

MC cable whip for high bays; no plug; inners 1/2″ strip on both ends; 6′ metal-clad cable; 18/3 wire

/MC-65

KT-MC-NP-6-18/5

MC cable whip for high bays; no plug; inners 1/2″ strip on both ends; 6′ metal-clad cable; 18/5 wire (dimming wires included)

/NP10

KT-CS-NP-10-16/3

Cord for high bays; no plug; inners 1/2″ strip on both ends; 10′ SJTOW cable; 16/3 wire

/NP6

KT-CS-NP-6-16/3

Cord for high bays; no plug; inners 1/2″ strip on both ends; 6′ SJTOW cable; 16/3 wire

/NP15

KT-CS-NP-15-16/3

Cord for high bays; no plug; inners 1/2″ strip on both ends; 15′ SJTOW cable; 16/3 wire

UPC

EASY CODE

843654140124

UKH-26

843654140131

SFV-88

843654140148

ZQS-05

843654140155

GVH-22

843654140162

DVU-44

843654140179

LCW-66

843654140186

POC-82

843654134505

EYP-82

843654134512

CBU-56

843654140193

YOH-90

843654140216

HUB-73

843654140209

EYD-18

Cord Sets

* For factory installation of accessory, add suffix to fixture part number (see ordering examples and instructions on last page of spec sheet). Note: For cord sets not listed here, please contact your Keystone sales rep.

(Accessories continued on next page)

Keystone Technologies · Philadelphia, PA · Phone (800) 464-2680 · www.keystonetech.com Specifications subject to change. Last revised on 05.30.23

POWER SELECT COLOR SELECT
KT-BPLED35PS-14C-8CSA-VDIM
BACKLIT LED PANEL LIGHT

Page 4 of 5

ACCESSORIES (continued)

EMERGENCY BACKUP

Factory-Installable OR Field-Installable (field-installable purchased separately)

P SUFFIX*

CATALOG NUMBER

DESCRIPTION

/EM5

KT-EMRG-LED-5C-500-EN /DF 5W, 500 lumen Smart Safe emergency backup with dual flex cables

/EM12 KT-EMRG-LED-12C-1200-EN /DF 12W, 1200 lumen Smart Safe emergency backup with dual flex cables

UPC 843654132433 890949019900

EASY CODE RAR-74 YCV-23

5W, 500 lumen Battery Backup KT-EMRG-LED-5C-500-EN /DF

12W, 1200 lumen Battery Backup KT-EMRG-LED-12C-1200-EN /DF

* For factory installation of accessory, add suffix to fixture part number (see ordering examples and instructions on last page of spec sheet). Factory installation of emergency backup units will automatically include any relevant mounting bracket.

Field-Installable / Field-Use ONLY (purchased separately)

CATALOG NUMBER

DESCRIPTION

KT-BPLED-EM-14C-KIT

Emergency LED backup mounting bracket kit for backlit panel fixtures

KT-BPLED-SM-14-KIT /G2

Surface Mount Kit 2×4 Backlit panels

KT-BPLED-CABLE-KIT

Aircraft cable hanging kit for LED high bay fixtures

UPC 843654157009 843654134529 843654133423

EASY CODE XYK-35 JYK-35 JLB-77

Emergency Backup Mounting Bracket KT-BPLED-EM-14C-KIT

Surface Mount Kit KT-BPLED-SM-14-KIT /G2

Cable Mount Kit KT-BPLED-CABLE-KIT

Keystone Technologies · Philadelphia, PA · Phone (800) 464-2680 · www.keystonetech.com Specifications subject to change. Last revised on 05.30.23

POWER SELECT COLOR SELECT
KT-BPLED35PS-14C-8CSA-VDIM
BACKLIT LED PANEL LIGHT

Page 5 of 5

ORDERING INFORMATION
CATALOG NUMBER KT-BPLED35PS-14C-8CSA-VDIM

CARTON QTY. 2

EASY CODE ROC-45

UPC 843654156972

DLC PRODUCT ID TBD

CATALOG NUMBER BREAKDOWN
KT-BPLED35PS-14C-8CSA-VDIM

1

2

3

4

56 7 8 9

10

1 Keystone Technologies 2 Backlit Panel Light LED Fixture 3 Wattage 4 Power Select 5 1′ x 4′ Nominal Size 6 Contractor Series 7 80 CRI 8 Color Select 9 Color Select Designation 10 0-10V Dimming

9 Color Select

A

3500/4000/5000K

ORDERING EXAMPLES FIXTURE WITH MULTIPLE FACTORY-INSTALLED ACCESSORIES*
KT-BPLED35PS-14C-8CSA-VDIM /PIR/L715P6/EM5
FIXTURE WITH TWO FACTORY-INSTALLED ACCESSORIES*
KT-BPLED35PS-14C-8CSA-VDIM /PIR/EM5
FIXTURE WITH SINGLE FACTORY-INSTALLED ACCESSORY
KT-BPLED35PS-14C-8CSA-VDIM /L715P6
FIXTURE WITH NO FACTORY-INSTALLED ACCESSORIES
KT-BPLED35PS-14C-8CSA-VDIM

KEYSTONE FIXTURE
CATALOG NUMBER KT-BPLED35PS-14C-8CSA-VDIM

SENSORS
P SUFFIX P /FC1-PIR

CATALOG NUMBER KTSL-FC1-UV-KO-PIR

CORD SETS
P SUFFIX P /L715P6

CATALOG NUMBER KT-CS-L715P-6-16/3

EMERGENCY BACKUP

P SUFFIX

CATALOG NUMBER

P /EM5 KT-EMRG-LED-5C-500-EN /DF

* When ordering more then one factory-installed accessory, use multiple suffixes as shown in the ordering examples above. Note: All accessories can also be ordered separately for field installation using just their regular Catalog Number, UPC, or Easy Code.

Keystone Technologies · Philadelphia, PA · Phone (800) 464-2680 · www.keystonetech.com Specifications subject to change. Last revised on 05.30.23
