Power-lite Blp16w-30-60 Led Backlit Panel Light Installation Guide

BLP16W-30-60 LED Backlit Panel Light

Product Information

The LED Backlit Panel is a modern and energy-efficient lighting
solution suitable for a variety of settings, including homes,
offices, and commercial spaces. It is available in three different
types: BLP16W-30/60, BLP36W-120/30, and BLP45W-120/60. The panel is
designed to be installed using different methods, including
recessed mounting, suspended mounting, surface mounting, and
recessed mounting with a frame. The product comes with an
installation manual that provides detailed instructions for each
method.

The panel is made of high-quality materials, including a
diffused material LGP that can be constructed from either PS or
PMMA material. The warranty does not cover discolouration of the
diffused material, which can occur if it is exposed to sunlight/UV.
Therefore, it is recommended to use LED panels made of PMMA
material in areas with sunlight/UV exposure.

Product Usage Instructions

Recessed Mounting:

1. Open the ceiling with a needed hole.
2. Assemble the spring on the panel.
3. Make the springs in a vertical direction with the panel and
   make it fit the cut hole.
4. Make the springs in a horizontal direction with the panel and
   make sure they match well.
5. Fix LED panel light into the recessed frame.
6. Installation complete, turn on the power.

Suspended Mounting:

1. Fix the anchor into target place on the ceiling.
2. Fix the installation mount on the ceiling with plastic
   anchor.
3. Make sure the LED panel light is firmly fixed, turn on the
   power.

Surface Mounted:

1. Assemble the surface mounted frame and fix it by screws.
2. Knock the plastic anchor into the ceiling, fix the surface
   mounted frame on the ceiling by screws.
3. Fix the side frame back by screw.
4. Unscrew the side frame then take out, connect the panel light
   to power supply, insert the panel light into the frame.
5. Make sure the frame and panel light are firmly fixed, turn on
   the power.

Recessed Mounting with Frame:

1. Open a hole on the ceiling according to cutout size of recessed
   frame.
2. Fix 2pcs of clips to one side of frame by screw, then insert
   the frame into ceiling.
3. Fasten the frame into ceiling by screwing another 2 pcs clips
   on the other side of frame.
4. Feed the main AC wire in terminal block respectively.
5. Fix LED panel light into plaster ceiling.
6. Installation complete, turn on the power.

General Instructions:

• Switch off before installation.
• Switch on only after complete installation and examination of
  the circuit.
• Make sure that the mounting surface or structural member used
  for installation can support the weight of LED Panel.

If you encounter any issues during installation or usage, please
contact Nedlands Group at 1800 909 306 or
[email protected] for assistance.

Fix led panel light into the recessed frame.
Installation complete, turn on the power.
Installation for Plaster Ceilings
Open the ceiling with a needed hole.
Assemble the spring on the panel.
Make the springs in a vertical direction with the panel and make it fit the cut hole.
Make the springs in a horizontal direction with the panel and make
sure they match well.
Recessed Mounting(Clips)

Type PL3030 PL3060 PL6060

Cut Out Sizes A(mm) B(mm) Type A(mm) B(mm)
270 270 PL6262 590 590 270 570 PL30120 270 1170 570 570 PL60120 570 1170

Clips should be purchased separately as an accesory

Warning:
Input wire diameter 0.75mm²; Product modification and improper installation are not valid for warranty!
Note: If the diffused material LGP is constructed from quality PS material, while discolouration of LED panel is easily generated with exposure to sunlight/UV. In general installation area, places without sunlight/UV, PS is strong enough to support. However, sunlight/UV can cause discolouration, under this circumstance, we would recommend the use of LED panel made of PMMA material. Please note warranty does not cover discolouration of diffused material.

1800 909 306

nedlandsgroup.com.au [email protected]

Certainty at The Speed of Light
INSTALLATION MANUAL
LED BACKLIT
PANEL
BLP16W-30/60 BLP36W-120/30 BLP45W-120/60

Safety Instructions Basic safety precautions should always be followed when installing, including the following: 1. Read instructions carefully before installing. 2. This LED Panel requires professional installation and maintenance. 3. The power supply of the LED Panel should be powered by a dedicated external LED driver. 4. Disconnect the power supply before installing or maintenance. 5. Make sure the wires have been properly connected before powering on the device. 6. Ensure the product has enough space for heat dissipation. 7. Ensure the luminaries are never covered by any heat insulation mat or slim layer material at anytime. 8. Dimmable version could be compatible with a wide range of recommended TRIAC dimmers. 9. IP40 for indoor use only, not for damp loaction; IP54 for indoor damp location. 10. Ambient Temperature: -10°C to + 45°C, Avoid direct sunlight. 11. Storage Conditions: Cool & dry conditions.
Installation Procedure
WARNING:
1.Switch off before installation. 2.Switch on only after complete installation and examination of the circuit.
CAUTION:
Make sure that the mounting surface or structural member used for installation can support the weight of LED Panel.
Recessed
AC~
Remove the ceiling plaster slab.
Feed the main AC wire in driver terminal block respectively, connect the panel light and driver.
Fix the panel light into plaster ceiling.

Suspended

Make sure the led panel light is firmly fixed, turn on the power.
Fix the anchor into target place on the ceiling.
Fix the installation mount on the ceiling with plastic anchor.

Surface Mounted

B A

A B

Hang the panel to ceiling with suspended installation kits,adjust the length of steel wires.
Feed the main AC wire in driver terminal block respectively,
turn on the power.

Assemble the surface mounted frame and fix by screws.

knock the plastic anchor into ceiling, fix the surface mounted frame on
the ceiling by screws.

Fix the side frame back by screw.

Unscrew the side frame then take out, connect the panel light to power supply, insert the panel light into the frame.

Make sure the frame and

B

panel light are firmly fixed, turn

on the power.

Recessed with Frame
Open a hole on ceiling according to cutout size of recessed frame.
Fix 2pcs of clips to one side of frame by screw, then insert the frame into ceiling.
Fasten the frame into ceiling by screwing another 2 pcs clips on the other side of frame.
Feed the main AC wire in terminal block respectively.

AC~
