DA4-M 4 Channel Constant Voltage DALI LED Dimmer

Product Information

The 4 Channel Constant Voltage DALI LED Dimmer, Model No. DA4-M,
is a DALI (Digital Addressable Lighting Interface) compatible
dimmer designed for LED lighting applications. It supports 1 DALI
address and offers 4 channels of output. The dimmer is compatible
with various dimming modes, including DT6 dimming, DT8-TC color
temperature control, DT8-RGB color control, and DT8-RGBW color
control. It follows the DALI standard protocol IEC 62386-102, IEC
62386-207, and IEC 62386-209, ensuring interoperability with DALI
products from different manufacturers. The dimmer features
automatic DALI address assignment, PWM digital dimming with a
standard DALI logarithmic dimming curve, and built-in over-load and
short circuit protection.

Technical Parameters

  • Input voltage: 12-48VDC
  • Input current: 20.5A
  • Output voltage: 12-48VDC
  • Output current: 4x5A@12/24V, 4x3A@36/48V
  • Output power: 4 x 60W @12V, 4x120W@24V, 4 x 108W@36V,
    4x144W@48V
  • Output type: Constant voltage

Warranty and Protection

  • Warranty: 5 years
  • Protection: Reverse polarity, Over-load, Short circuit

Product Usage Instructions

Mechanical Structures and Installations:

The DA4-M dimmer has an LED indicator and is designed for
installation on an installation rack. It features two groups of
DALI signal inputs, and the DALI bus does not require
distinguishing plus-minus polarity. It also has a DIP switch for
selecting the light type.

Wiring Diagram:

The wiring diagram varies depending on the type of LED strip
being used.

1. DA4-M for single color:

  • Connect the DALI signal inputs (DA1 and DA2) to the DALI
    Master.
  • Connect the power input (12-48VDC) to the AC power source.
  • Connect each output channel to a single color LED strip.

2. DA4-M for dual color:

  • Connect the DALI signal inputs (DA1 and DA2) to the DALI
    Master.
  • Connect the power input (12-48VDC) to the AC power source.
  • Connect the first two output channels to a dual color LED strip
    (CW and WW).

3. DA4-M for RGB:

  • Connect the DALI signal inputs (DA1 and DA2) to the DALI
    Master.
  • Connect the power input (12-48VDC) to the AC power source.
  • Connect the first three output channels to an RGB LED strip (R,
    G, and B).

4. DA4-M for RGBW:

  • Connect the DALI signal inputs (DA1 and DA2) to the DALI
    Master.
  • Connect the power input (12-48VDC) to the AC power source.
  • Connect the first four output channels to an RGBW LED strip (R,
    G, B, and W).

DALI Control:

The DA4-M dimmer supports DALI control. The DALI address is
automatically assigned by the DALI Master controller. Please refer
to the user manuals of compatible DALI Masters for specific
operations.

Safety & Warnings:

Refer to the User Manual Ver 2.0.1 for safety instructions and
warnings related to the DA4-M dimmer.

4 Channel Constant Voltage DALI LED Dimmer
Model No.: DA4-M
1 Address/4 Channel/DT8/Constant voltage/PWM dimming

Features
4 channel constant voltage DALI LED Dimmer. 1 DALI address, DT6 dimming or DT8-TC color temperature or DT8-RGB or DT8-RGBW selectable. In accordance with DALI standard protocol IEC 62386-102, IEC 62386-207, IEC 62386-209
and in compliance with DALI products from other international incorporation. DALI address will be automatically assigned by DALI master. PWM digital dimming, standard DALI logarithmic dimming curve. Over-load / Short circuit protection, recover automatically.

Technical Parameters

Input and Output Input voltage Input current Output voltage Output current
Output power Output type

12-48VDC
20.5A 12-48VDC 4x5A@12/24V 4x3A@36/48V
4 x 60W @12V 4x120W@24V 4 x 108W@36V 4x144W@48V Constant voltage

Warranty and Protection

Warranty

5 years

Protection

Reverse polarity Over-load Short circuit

Dimming data Input signal Dimming range Dimming curve PWM Frequency
Environment Operation temperature Case temperature (Max.) IP rating

DALI 0 -100% Logarithmic 2000Hz (default)
Ta: -30 OC ~ +55 OC T c: +85OC IP20

User Manual Ver 2.0.1

Mechanical Structures and Installations

DA4-M 4 Channel Constant Voltage DALI LED Dimmer

LED indicator Installation rack Two groups of DALI signal input DALI bus no need distinguish plus-minus polarity
DIP switch for light type

SIGNAL INPUT
ON 1 2

DA1 DA2 DA1 DA2

Light Type DIM
ON 12

CCT 12

RGB RGBW

12

12

LED OUTPUT

POWER IN PUT 12-48VDC

Output White LED Output Blue LED Output Green LED Output Red LED Installation rack Output LED+ Power input +
Power input –

175mm

45mm
160mm
Wiring Diagram
ON
DA4-M for single color ( ) 1 2
DA1 DA2 DA1 DA2

SIGNAL INPUT
ON 1 2

LED OUTPUT

27mm
Single color LED strip
+
Single color LED strip
+
Single color LED strip
+
Single color LED strip
+

POWER IN PUT 12-48VDC

DALI Master

AC Power 50/60Hz

Note: The four output LED channels output is same.

ON
DA4-M for dual color ( ) 1 2

DA1 DA2 DA1 DA2

Power Supply 12-48VDC Constant Voltage

LED OUTPUT

CW WW

Dual color LED strip

CW
WW Dual color LED strip

++

SIGNAL INPUT
ON 1 2

POWER IN PUT 12-48VDC

DALI Master
AC Power 50/60Hz
Note: The 3/4 LED channel output is same as 1/2 LED channel.

Power Supply 12-48VDC Constant Voltage

Page 1

ON
DA4-M for RGB ( ) 1 2
DA1 DA2 DA1 DA2

DALI Master
AC Power 50/60Hz
Note: The 4th LED channel no output.
ON
DA4-M for RGBW ( ) 1 2
DA1 DA2 DA1 DA2

DALI Master

AC Power 50/60Hz

SIGNAL INPUT
ON 1 2

SIGNAL INPUT
ON 1 2

LED OUTPUT

B

G

RGB LED strip

R

+

POWER IN PUT 12-48VDC

Power Supply 12-48VDC Constant Voltage

LED OUTPUT

POWER IN PUT 12-48VDC

Power Supply 12-48VDC Constant Voltage

+

W

B G

RGBW LED strip

R

DALI control
This product is designed with 1 DALI address input and 4 channel output, DALI address is assigned by DALI Master controller automatically, please refer to user manuals of compatible DALI Masters for specific operations.
Safety & Warnings
· DO NOT install with power applied to device. · DO NOT expose the device to moisture.

User Manual Ver 2.0.1

DA4-M 4 Channel Constant Voltage DALI LED Dimmer
Page 2

DALI4LED
:DA4-M
1/4/DT8//PMW

DALI4LED 1DALIDT6DT8-TCDT8-RGBDT8-RGBW. DALIIEC62386-102IEC62386-207DALI DALIDALI PWMDALI /

12-48VDC 20.5A 12-48VDC 4x5A@12/24V 4x3A@36/48V 4x60W@12V4x120W@24V 4x108W@36V4x144W@48V
5

2.0.1

PWM
IP

DALI 0 -100% 2000Hz
Ta:-30 OC~+55 OC Tc:+85 OC IP20

LED DALI
45mm

SIGNAL INPUT
ON 1 2

DA1 DA2 DA1 DA2

Light Type DIM
ON 12

CCT 12

RGB RGBW

12

12

175mm

160mm

LED OUTPUT

POWER IN PUT 12-48VDC

LEDLEDLEDLED LED+ + –
27mm

ON
DA4-M ( ) 1 2
DA1 DA2 DA1 DA2

DALI

AC Power 50/60Hz

4
ON
DA4-M ( ) 1 2

DA1 DA2 DA1 DA2

SIGNAL INPUT
ON 1 2

LED OUTPUT

POWER IN PUT 12-48VDC

12-48VDC

+ LED + LED
+ LED + LED

LED OUTPUT

CW WW

LED

CW WW

LED

++

SIGNAL INPUT
ON 1 2

POWER IN PUT 12-48VDC

DALI

AC Power 50/60Hz

3/4LED1/2LED

12-48VDC

1

ON
DA4-MRGB ( ) 1 2
DA1 DA2 DA1 DA2

DALI

AC Power 50/60Hz

4

ON
DA4-MRGBW( ) 1 2

DA1 DA2 DA1 DA2

DALI

AC Power 50/60Hz

SIGNAL INPUT
ON 1 2

SIGNAL INPUT
ON 1 2

LED OUTPUT

POWER IN PUT 12-48VDC

12-48VDC

+

B

G R

RGBLED

LED OUTPUT

POWER IN PUT 12-48VDC

12-48VDC

+

W
B
G RGBWLED
R

DALI
1DALI4 DALIDALIDALI

2.0.1

2
