Product Information
Product Name: 4 Push Button DALI Dimmer
Model No.: DA-4S
Features:
- Standard DALI Master, control 4 DALI Addresses.
- Comply to Latest DALI standard protocol IEC62386 and in
compliance with DALI products from other international
incorporation. - Power is provided by DALI bus.
- 1-4 push button control.
- Enable to select 4 different addresses for controlling by
encoding switch. - Support scene, group, unicast, and broadcast mode.
- Easy to be placed in standard wall junction box behind a push
switch.
Technical Parameters:
- Input and Output: 4xpush switch signal, DALI signal, DALI
bus - Power supply: Static current of 4mA@16V
- Environment: Operation temperature of -20°C ~ +50°C, Case
temperature (Max.) of +55°C, IP rating of IP20 - Mechanical Structures and Installations: 10 level rotary
switch, 16 level rotary switch - Package Size: L60x W60 x H40mm
- Gross weight: 0.046kg
- Warranty: 5 years
Product Usage Instructions
DALI Address Setting
To set the DALI address, use the formula: Address value = X * 10
+ Y.
For example: X = 5, Y = 4, Address value = 5 x 10 + 4 = 54.
Unicast Mode
In unicast mode, X is 0-6 and Y is 0-9. Address value 0-63
correspond to DALI unicast address 00-63.
For example: Address value = 40, the unicast values of K1, K2,
K3, K4 push button are 40, 41, 42, 43.
Address value = 62, the unicast values of K1, K2, K3, K4 push
button are 62, 63, 0, 1.
Short press K1, K2, K3, K4 to turn on/off light. Long press K1,
K2, K3, K4 to increase or decrease brightness.
Group Mode
In group mode, X is 7 and Y is 0-F. Address value 70-7F
correspond to DALI group address 0-15.
For example: Address value = 5, the group address value of K1,
K2, K3, K4 push button are 5, 6, 7, 8.
Address value = E, the group address value of K1, K2, K3, K4
push button are 14, 15, 0, 1.
Short press K1, K2, K3, K4 to turn on/off light. Long press K1,
K2, K3, K4 to increase or decrease brightness.
Scene Mode
In scene mode, X is 8 and Y is 0-F. Address value 80-7F
correspond to DALI scene 0-15.
For example: Address value = 5, the scene value of K1, K2, K3,
K4 push button are 5, 6, 7, 8.
Address value = E, the scene value of K1, K2, K3, K4 push button
are 14, 15, 0, 1.
Short press K1, K2, K3, K4 to recall the scene. Long press K1,
K2, K3, K4 (2s) to turn off the scene light.
Broadcast Mode
In broadcast mode, X is 9 and Y is 0-F. Address value 90 – 9F
correspond to broadcast address.
Short press K1, K2, K3, K4 to turn on/off light. Long press K1,
K2, K3, K4 to increase or decrease brightness.
4 Push Button DALI Dimmer
Model No.: DA-4S
1-4 Push button input / Encoding switch select addresses
Features
Standard DALI Master, control 4 DALI Addresses. Comply to Latest DALI standard protocol IEC62386 and
in compliance with DALI products from other international incorporation. Power is provided by DALI bus. 1-4 push button control. Enable to select 4 different addresses for controlling by encoding switch. Support scene, group, unicast and broadcast mode. Easy to be placed in standard wall junction box behind a push switch.
Technical Parameters
Input and Output Input signal Output signal Power supply Static current
4xpush switch signal DALI signal DALI bus 4mA@16V
Environment Operation temperature Case temperature (Max.) IP rating
Mechanical Structures and Installations
10 level rotary switch
16 level rotary switch
Ta: -20 OC ~ +50 OC Ta: +55 OC IP20
Package Size Gross weight
Warranty Warranty
52.00 mm
LVD RED
L60x W60 x H40mm 0.046kg 5 years
27.00 mm
52.00 mm
DAIL signal
Wiring Diagram
Connect with 4xpush switch
DALI Master/ DALI Bus Power Supply
LED light
DALI LED Driver
LED light
DALI LED Driver
LED light
DALI LED Driver
LED light
DALI LED Driver
User Manual Ver 1.0.0
K1 K2 K3 K4
4 x Push button
1
DALI address setting
Address value = X * 10 + Y. For example: X = 5, Y = 4, Address value = 5 x 10 + 4 = 54.
Unicast mode
X is 0-6, Y is 0-9. Address value 0-63 correspond to DALI unicast address 00-63. For example: Address value = 40, the unicast values of K1,K2,K3,K4 push button are 40, 41, 42, 43. Address value = 62, the unicast values of K1,K2,K3,K4 push button are 62, 63, 0, 1. Short press K1,K2,K3,K4 to turn on/off light. Long press K1,K2,K3,K4 to increase or decrease brightness.
Group mode
X is 7, Y is 0-F. Address value 70-7F correspond to DALI group address 0-15. For example: Address value = 5, the group address value of K1,K2,K3,K4 push button are 5, 6, 7, 8. Address value = E, the group address value of K1,K2,K3,K4 push button are 14, 15, 0, 1. Short press K1,K2,K3,K4 to turn on/off light. Long press K1,K2,K3,K4 to increase or decrease brightness.
Scene mode
X is 8, Y is 0-F. Address value 80-7F correspond to DALI scene 0-15. For example: Address value = 5, the scene value of K1,K2,K3,K4 push button are 5, 6, 7, 8. Address value = E, the scene value of K1,K2,K3,K4 push button are 14, 15, 0, 1. Short press K1,K2,K3,K4 to recall the scene. Long press K1,K2,K3,K4(2s) to turn off the scene light.
Broadcast mode
X is 9, Y is 0-F. Address value 90 – 9F correspond to broadcast address. Short press K1,K2,K3,K4 to turn on/off light, long press K1,K2,K3,K4 to increase or decrease brightness.
User Manual Ver 1.0.0
2
