ITC 69516 Pin Courtesy Light
PARTS/TOOLS NEEDED
INSTALLATION CONSIDERATIONS
- To avoid a hazard to children, account for all parts and destroy all packing materials.
- Disconnect power before installing, adding, or changing any component.
- Positive (+) outputs require a fuse if the attached wire leads are not rated to handle the max current.
- The brushed nickel bezel can be used in interior applications only.
- LEDs are polarity sensitive and will not light if not attached properly.
WITHOUT BEZEL
- Drill a 0.375” hole in mounting surface
- Attach wires to the power source. Red is positive and black neutral
- Slide light off the rubber grommet, install rubber into the hole, and then slide the light back into the grommet
WITH BEZEL
- Remove the rubber grommet and throw away
- Drill a 0.4375” hole in mounting surface
- Attach wires to the power source. Red is positive and black neutral
- Slide the bezel and light into the mounting surface
3030 Corporate Grove Dr. Hudsonville, MI 49426 Phone: 616.396.1355 itc-us.com
For warranty information please visit www.itc-us.com/warranty-return-policy Rev A • 05/24/21
