Hukoro F51401-11i Mousse 1-light Cage Mini Pendant Light Instruction Manual

F51401-11i Mousse 1-Light Cage Mini Pendant Light

Product Information

The product is a light fixture that requires assembly and
installation. The package includes various hardware parts such as
fixture, stems, canopy, mounting unit, ball nuts, mounting screws,
wire nuts, and exploded parts. The product requires some tools for
assembly such as a ladder, safety glasses, electrical Phillips
screwdriver, flat blade screwdriver, pliers, and wire strippers.
The product does not include bulbs or sealing tape.

Product Usage Instructions

Follow the below instructions to assemble and install the light
fixture:

Step 1: Mounting Unit Installation

1. Unscrew the ball nuts from the mounting unit.
2. Use the mounting screws to attach the mounting unit to the
   junction box.

Step 2: Stems and Canopy Installation

1. Install stems based on the desired length of the item.
2. Add the canopy once finished.
3. Secure the canopy to the mounting unit with the ball nuts.

Step 3: Electrical Connection

1. Make the electrical connection from the junction box to the
   fixture.
2. Connect the ground wire to the mounting unit using the
   preinstalled green ground screw.
3. Connect the positive, negative, and ground wires with the
   supplied wire nuts.
4. Secure with electrical tape.

The following wires should be connected:

• Black or Red wire (hot) from the junction box
• White wire (neutral) from the junction box
• Bare or Green ground wire from the junction box
• Black wire from the fixture
• White wire from the fixture
• Ground wire from the Fixture

Note: Sealing tape is not included.

Step 4: Bulb Installation

1. Install bulb (not included).

After following the above steps, the light fixture should be
ready for use.

ASSEMBLY INSTRUCTIONS

CAUTION

³Inspect the wire insulation for any cuts, abrasions, or exposed copper that may have resulted during shipping. If there is a defect in the wire, do not attempt installation.

TOOLS REQUIRED

³Before starting installation of this fixture or removal of a previous fixture, disconnect the power by turning off the circuit breaker or by
removing the fuse at the fuse box.

Ladder

Safety glasses

Electrical Phillips

tape

screwdriver

Flat blade screwdriver

Pliers

Wire strippers

HARDWARE INCLUDED

Fixture

Stems (AjE)

Canopy

Mounting Unit

Ball Nuts Mounting Screws

*PARTS SHOWN MAY DIFFER SLIGHTLY PER LIGHT FIXTURE

Wire Nuts

EXPLODED PARTS
Wire Nuts Mounting Unit

INSTALLATION
STEP 1
Unscrew the ball nuts from the mounting unit. Use the mounting screws to attach the mounting unit to the junction box.

STEP 2
Install stems based on the desired length of the item, adding canopy once finished.

Mounting Screws

Canopy Ball nuts Stem A

Stem B

Stem C

Stem D

Stem E

Fixture
Bulbs (not included)

ASSEMBLY INSTRUCTIONS INSTALLATION

STEP 3
Make the electrical connection from the junction box to the fixture. Connect the ground wire to the mounting unit using the preinstalled green ground screw. Then, connect the positive, negative and ground wires with the supplied wire nuts. Secure with electrical tape.

Black or Red wire (hot) from the junction box
White wire (neutral) from the junction box
Bare or Green ground wire from the junction box
*Sealing tape (not included)

Black wire from the fixture
White wire from the fixture
Ground wire from the Fixture
*Green Ground Screw

STEP 4
Secure the canopy to the mounting unit with the ball nuts.

STEP 5
Install bulb (not included)
