JP122-BN 1 Light mini Pendant
Product Information
This product is a light fixture that comes with hardware
including a fixture, mounting unit, ball nuts, mounting screws, and
wire nuts. The product also comes with exploded parts and requires
a junction box (not included) for installation. The product
requires tools such as a ladder, safety glasses, electrical
Phillips screwdriver, flat blade screwdriver, pliers, and wire
strippers.
Product Usage Instructions
Step 1: Mounting Unit Installation
- Unscrew the ball nuts from the mounting unit.
- Use the mounting screws to attach the mounting unit to the
junction box (not included).
Step 2: Electrical Connection
- Make the electrical connection from the junction box (not
included) to the fixture. - Connect the ground wire to the mounting unit using the
preinstalled green ground screw. - Next, connect the positive, negative, and ground wires with the
supplied wire nuts. - Secure with electrical tape.
Step 3: Fixture Attachment
- Attach the fixture to the mounting unit through screw holes as
shown, and secure it with ball nuts.
Step 4: Bulb Installation
- Install bulb (not included).
Note: If you need further assistance, please
contact us by Email: [email protected].
Caution: Make sure to remove the fuse at the
fuse box before starting the installation process.
ASSEMBLY INSTRUCTIONS
CAUTION
³Inspect the wire insulation for any cuts, abrasions, or exposed copper that may have resulted during shipping. If there is a defect in the wire, do not attempt installation.
³Before starting installation of this fixture or removal of a previous fixture, disconnect the power by turning off the circuit breaker or by
removing the fuse at the fuse box.
@ If you need further assistance, please contact us by Email: [email protected] TOOLS REQUIRED
Ladder
Safety glasses
Electrical
Phillips
tape
screwdriver
Flat blade screwdriver
Pliers
Wire strippers
HARDWARE INCLUDED
Fixture
Mounting Unit
Ball Nuts
Mounting Screws
Wire Nuts
*PARTS SHOWN MAY DIFFER SLIGHTLY PER LIGHT FIXTURE
EXPLODED PARTS
INSTALLATION
Junction Box (not included)
Wire Nuts Mounting Unit
STEP 1
Unscrew the ball nuts from the mounting unit. Use the mounting screws to attach the mounting unit to the junction box (not included).
Mounting Screws
Ball Nuts
STEP 2
Make the electrical connection from the junction box (not included) to the fixture. Connect the ground wire to the mounting unit using the preinstalled green ground screw. Next, connect the positive, negative and ground wires with the supplied wire nuts. Secure with electrical tape.
Fixture
Bulbs (not included)
Black or Red wire (hot) from the junction box
White wire (neutral) from the junction box
Bare or Green ground wire from the junction box
*Sealing tape (not included)
Black wire from the fixture
White wire from the fixture
Ground wire from the Fixture
*Green Ground Screw
ASSEMBLY INSTRUCTIONS INSTALLATION
STEP 3
Attach the fixture to the moungting unit through screw holes as shown, and secure it with ball nuts.
*junction box (not included)
STEP 4
Install bulb (not included)
