P1677-084C-L LED Mini Pendant
Product Information: P1677-084C-L LED Mini Pendant
The P1677-084C-L is a LED mini pendant that requires
installation before use. It comes with installation instructions
that must be followed carefully to ensure correct installation and
usage of the product. The product is dimmable with ELV and/or LED
compatible wall dimmer switches. The LED module can be replaced by
a qualified electrician without cutting off wires and without
damaging any decorative element to which the fixture is attached.
The LED module should be provided by a specified supplier.
Product Usage Instructions:
Before using the P1677-084C-L LED mini pendant, follow the
installation instructions provided below:
Installation Instructions:
- Read and save the installation instructions.
- Turn off power at fuse or circuit breaker.
- Connect the electrical wires as shown in Fig.2, making sure
that all wire connectors are secured. If your junction box has a
ground wire (green or bare copper), connect fixture’s ground wire
to it. Otherwise, connect the fixture’s ground wire directly to the
mounting plate (A) using the green screw (B) provided. Tuck wire
connectors neatly into the junction box. - Align canopy (E) onto mounting plate (A) and secure with screws
(D). - Remove stainless steel protective film on fixture.
- Turn on power at the junction box and test the fixture.
When handling the fixture, do not apply pressure to LEDs. Hold
the fixture by the base only.
Replacing LED Module:
The LED module can be replaced by a qualified electrician
without cutting off wires and without damaging any decorative
element to which the fixture is attached. To replace the LED
module, follow the steps provided below:
- Turn off power at the circuit breaker before replacing LED
module. - Remove the screws (D) and remove the wire connectors and place
fixture body on a clean flat surface. - Loosen screws (Q), take out base R. Loosen screws (O) and
rubber washers (L) and remove curve glass (N). - To disconnect LED module: Loosen hex nuts (M), rubber washers
(L). Press button of quick connector P on LED module K with
screwdriver to disconnect wire and carefully remove LED module
(K). - Reverse steps a – d for installing new LED module K (Fig.3).
Note: The LED module should be provided by a specified
supplier.
IMPORTANT: Fixture should be installed by a qualified
electrician to ensure proper wiring and installation.
INSTALLATION INSTRUCTIONS FOR P1677-084C-L For LED Mini Pendant
READ AND SAVE THESE INSTRUCTIONS
WARNING! SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
AV ERT I SSEME NT !CO U PER LE C O UR ANT AU N IVE AU D ES F USIB LE S O U D O D I SJO NCT EU
ASSEMBLING THE FIXTURE (Fig.1) 1. Shut off power at the fuse box or circuit breaker box and remove the old fixture including the mounting hardware. 2. Carefully unpack your new fixture and lay out all the parts in a clear area. Take care not to misplace any small parts necessary for installation. 3. Attach mounting plate (A) to junction box (not included) using mounting screws (C) (Size: 8-32*1/2”L). The side of mounting plate (A) marked “GND” must face out. 4. Thread all thread (I) to hex joint of fixture (J). Place decorative coverHto all thread (I) and secure with washer (G). 5. Fixture includes three 12″ and one 6″ rods. Determine desired hanging height and thread rods (F1, F2) to all thread (I). Feed fixture wire carefully through each rod. If installing with one 6″ rod only the all thread must be removed. 6. Secure rod to swivel of canopy (E).
CONNECTING THE WIRES (Fig.2) 7. Connect the electrical wires as shown in Fig.2, making sure that all wire connectors are secured. If your junction box has a ground wire (green or bare copper), connect fixture’s ground wire to it. Otherwise, connect the fixture’s ground wire directly to the mounting plate (A) using the green screw (B) provided. 8. Tuck wire connectors neatly into the junction box.
COMPLETING THE INSTALLATION 9. Align canopy (E) onto mounting plate (A) and secure with screws (D).
10. Remove stainless steel protective film on fixture.
Your installation is now complete. Return power to the junction box and test the
fixture. CAUTION /ATTENTION: When handling fixture, do not apply pressure to LEDs. Hold the fixture by the base only.
Fig.1
Replacing LED module (Fig. 1, Fig. 3)
The LED module can be replaced by a qualified electrician without cutting of wire and without damage to any decorative element to which the fixture is attached. See installation steps for more details (Fig.3,)
Warning: Turn off power at the circuit breaker before replacing LED module. a. Shut off the power. b. Remove the screws (D) and remove the wire connectors and place fixture body
on a clean flat surface. c. Loosen screws (Q),Take out baseR. Loosen screws (O) and rubber
washers (L) and remove curve glass (N). d. To disconnect LED module: Loosen hex nuts (M), rubber washers (L). Press
button of quick connectorPon LED moduleKwith screw driver to disconnect wire and carefully remove LED module (K). e. Reverse steps a – d for installing new LED moduleK(Fig.3). Note: The LED module should be provided by a specified supplier.
IMPORTANT: Fixture should be installed by a qualified electrician to ensure proper wiring and installation. Dimmable with ELV and/or LED compatible wall dimmer switches.
Fig.2
Fig.3
Q R K L M
O
J
D
NP L
LA-3450E
