Schneider Electric ATV12 Single Phase Variable Speed Drive
Short-Circuit Current Ratings (SCCR) and Branch Circuit Protection
The combinations in the table below have been tested per UL61800-5-1 (Reference UL file E116875). These ratings allow proper coordination of short circuit protection. The product would exceed a 100 kA interrupt rating on the output.
ATV12 drives are provided with integral overload and over-speed monitoring after activation of the function [Motor thermal state memo] MtM. and can provide motor overload protection at 100% of the full load motor current. The motor thermal current [Motor Th Current] ith must be set to the rated current indicated on the motor nameplate. For more information refer to the ATV12 User manual (BBV28581).
The opening of the branch circuit protective device may be an indication that a fault current has been interrupted.
DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH
- Current-carrying parts and other components of the controller should be examined and replaced if damaged.
- If burnout of the current element of an overload relay occurs, the complete overload relay must be replaced.
Failure to follow these instructions will result in death or serious injury.
75°C (167°F) copper conductor with the AWG wire size shown on nameplate for all sizes.
Suitable for use on a circuit capable of delivering not more than __X__ rms symmetrical kiloAmperes, __Y__ Volts maximum, when protected by __Z1__ with a maximum rating of __Z2__.
| Altivar 12 Short Circuit Current Ratings 1 2 With Enclosure, Without Line Reactor |
Minimum Enclosure Volume | With Circuit Breaker | With QO Circuit Breaker | With GV●P | Fuses |
Line Reactor Min Value 8 | |||||||||||||
|
Input Voltage 50/60 Hz (Y) |
Power Ratings |
Catalog Number 7 |
PowerPact 3 Catalog Number (Z1, Z2) |
SCCR (X) |
QO QOB |
QOU |
Rating |
SCCR (X) |
GV●P (Z1, Z2) |
SCCR (X) | 600 V Class J 5 (Z1, Z2) |
SCCR (X) | |||||||
| Type E 4 | Voltage Rating | Power 6 | |||||||||||||||||
| (kW) | (HP) | (L) | (in3) | (kA) | (A) | (kA) | – | (V) | (HP) | (kA) | (A) | (kA) | (mH ) | (A) | |||||
| 120 Vac Single- phase | 0.18 | 1/4 | ATV12H018F1 | 15.7 | 960 | H●L36015 | 5 9 | yes | yes | 10 | 5 12 | GV2P10 | 120 | 1/4 | 5 9 | 15 | 5 9 | – | – |
| 0.37 | 1/2 | ATV12●037F1 | 15.7 | 960 | H●L36020 | 5 9 | yes | yes | 20 | 5 12 | GV2P14 | 120 | 1/2 | 5 9 | 25 | 5 9 | – | – | |
| 0.75 | 1 | ATV12H075F1 | 15.7 | 960 | H●L36025 | 5 10 | yes | yes | 25 | 5 13 | GV2P20 | 120 | 1 | 5 10 | 40 | 5 10 | – | – | |
|
240 Vac Single- phase | 0.18 | 1/4 | ATV12H018M2 | 15.7 | 960 | H●L36015 | 5 9 | yes | yes | 10 | 5 12 | GV2P08 | 240 | 1/3 | 5 9 | 7 | 5 9 | – | – |
| 0.37 | 1/2 | ATV12●037M2 | 15.7 | 960 | H●L36015 | 5 9 | yes | yes | 10 | 5 12 | GV2P10 | 240 | 1/2 | 5 9 | 15 | 5 9 | – | – | |
| 0.55 | 3/4 | ATV12●055M2 | 15.7 | 960 | H●L36015 | 5 9 | yes | yes | 15 | 5 12 | GV2P14 | 240 | 1 1/2 | 5 9 | 25 | 5 9 | – | – | |
| 0.75 | 1 | ATV12●075M2 | 15.7 | 960 | H●L36020 | 5 9 | yes | yes | 20 | 5 12 | GV2P14 | 240 | 1 1/2 | 5 9 | 25 | 5 9 | – | – | |
| 1.5 | 2 | ATV12HU15M2 | 15.7 | 960 | H●L36025 | 5 10 | no | yes | 25 | 5 10 | GV2P20 | 240 | 3 | 5 10 | 40 | 5 10 | – | – | |
| 2.2 | 3 | ATV12HU22M2 | 15.7 | 960 | H●L36035 | 5 10 | no | yes | 35 | 5 10 | GV2P21 | 240 | 3 | 5 10 | 45 | 5 10 | – | – | |
|
240 Vac Three-phase | 0.18 | 1/4 | ATV12H018M3 | 15.7 | 960 | H●L36015 | 5 | yes | yes | 10 | 5 | GV2P07 | 240 | 1/2 | 5 | 5 | 5 | – | – |
| 0.37 | 1/2 | ATV12●037M3 | 15.7 | 960 | H●L36015 | 5 | yes | yes | 10 | 5 | GV2P08 | 240 | 3/4 | 5 | 7 | 5 | – | – | |
| 0.75 | 1 | ATV12●075M3 | 15.7 | 960 | H●L36015 | 5 | yes | yes | 15 | 5 | GV2P14 | 240 | 3 | 5 | 15 | 5 | – | – | |
| 1.5 | 2 | ATV12●U15M3 | 15.7 | 960 | H●L36015 | 5 | yes | yes | 15 | 5 | GV2P16 | 240 | 3 | 5 | 25 | 5 | – | – | |
| 2.2 | 3 | ATV12●U22M3 | 15.7 | 960 | H●L36025 | 5 | yes | yes | 25 | 5 | GV2P20 | 240 | 5 | 5 | 25 | 5 | – | – | |
| 3 | 3 | ATV12●U30M3 | 15.7 | 960 | H●L36030 | 5 | no | yes | 30 | 5 | GV2P21 | 240 | 7.5 | 5 | 40 | 5 | – | – | |
| 4 | 5 | ATV12●U40M3 | 15.7 | 960 | H●L36040 | 5 | no | yes | 40 | 5 | GV2P22 | 240 | 7.5 | 5 | 45 | 5 | – | – | |
| Altivar 12 Short Circuit Current Ratings 1 2 With Enclosure, With Line Reactor |
Minimum Enclosure Volume | With Circuit Breaker | With QO Circuit Breaker | With GV●P | Fuses | Line Reactor Min Value 8 | |||||||||||||
| Input Voltage 50/ 60 Hz (Y) |
Power Ratings |
Catalog Number 7 |
PowerPact 3 Catalog Number (Z1, Z2) |
SCCR (X) |
QO QOB |
QOU |
Rating |
SCCR (X) |
GV●P (Z1, Z2) |
SCCR (X) | 600 V Class J 5 (Z1, Z2) |
SCCR (X) | |||||||
| Type E 4 | Voltage Rating | Power 6 | |||||||||||||||||
| (kW) | (HP) | (L) | (in3) | (kA) | (A) | (kA) | – | (V) | (HP) | (kA) | (A) | (kA) | (mH) | (A) | |||||
| 120 Vac Single- phase | 0.18 | 1/4 | ATV12H018F1 | 15.7 | 960 | H●L36015 | 22 | yes | yes | 10 | 10 | GV2P10 | 120 | 1/4 | 22 | 15 | 22 | 1 | 4 |
| 0.37 | 1/2 | ATV12●037F1 | 15.7 | 960 | H●L36020 | 22 | yes | yes | 20 | 10 | GV2P14 | 120 | 1/2 | 22 | 25 | 22 | 1 | 7.3 | |
| 0.75 | 1 | ATV12H075F1 | 15.7 | 960 | H●L36025 | 22 | yes | yes | 25 | 10 | GV2P20 | 120 | 1 | 22 | 40 | 22 | 1 | 12.8 | |
|
240 Vac Single- phase | 0.18 | 1/4 | ATV12H018M2 | 15.7 | 960 | H●L36015 | 65 | yes | yes | 10 | 10 | GV2P08 | 240 | 1/3 | 65 | 7 | 65 | 2.3 | 2.2 |
| 0.37 | 1/2 | ATV12●037M2 | 15.7 | 960 | H●L36015 | 65 | yes | yes | 10 | 10 | GV2P10 | 240 | 1/2 | 65 | 15 | 65 | 2.3 | 4 | |
| 0.55 | 3/4 | ATV12●055M2 | 15.7 | 960 | H●L36015 | 65 | yes | yes | 15 | 10 | GV2P14 | 240 | 1 1/2 | 65 | 25 | 65 | 2.3 | 7 | |
| 0.75 | 1 | ATV12●075M2 | 15.7 | 960 | H●L36020 | 65 | yes | yes | 20 | 10 | GV2P14 | 240 | 1 1/2 | 65 | 25 | 65 | 2.3 | 10 | |
| 1.5 | 2 | ATV12HU15M2 | 15.7 | 960 | H●L36025 | 65 | no | yes | 25 | 10 | GV2P20 | 240 | 3 | 65 | 40 | 65 | 1 | 13.2 | |
| 2.2 | 3 | ATV12HU22M2 | 15.7 | 960 | H●L36035 | 65 | no | yes | 35 | 10 | GV2P21 | 240 | 3 | 65 | 45 | 65 | 1 | 18 | |
|
240 Vac Three- phase | 0.18 | 1/4 | ATV12H018M3 | 15.7 | 960 | H●L36015 | 65 | yes | yes | 10 | 10 | GV2P07 | 240 | 1/2 | 65 | 5 | 65 | 6.4 | 1 |
| 0.37 | 1/2 | ATV12●037M3 | 15.7 | 960 | H●L36015 | 65 | yes | yes | 10 | 10 | GV2P08 | 240 | 3/4 | 65 | 7 | 65 | 6.4 | 1.6 | |
| 0.75 | 1 | ATV12●075M3 | 15.7 | 960 | H●L36015 | 65 | yes | yes | 15 | 10 | GV2P14 | 240 | 3 | 65 | 15 | 65 | 6.4 | 3 | |
| 1.5 | 2 | ATV12●U15M3 | 15.7 | 960 | H●L36015 | 65 | yes | yes | 15 | 10 | GV2P16 | 240 | 3 | 65 | 25 | 65 | 1 | 6.5 | |
| 2.2 | 3 | ATV12●U22M3 | 15.7 | 960 | H●L36025 | 65 | yes | yes | 25 | 10 | GV2P20 | 240 | 5 | 65 | 25 | 65 | 1 | 8.6 | |
| 3 | 3 | ATV12●U30M3 | 15.7 | 960 | H●L36030 | 65 | no | yes | 30 | 10 | GV2P21 | 240 | 7.5 | 65 | 40 | 65 | 0.8 | 11.3 | |
| 4 | 5 | ATV12●U40M3 | 15.7 | 960 | H●L36040 | 65 | no | yes | 40 | 10 | GV2P22 | 240 | 7.5 | 65 | 45 | 65 | 0.8 | 14.1 | |
- The amp rating of the short circuit protection devices in the table are maximum values. Smaller amp sizes may be used. Branch circuit protection must be provided in accordance with the National Electrical Code and any additional local codes.
- Ratings apply to an Altivar 12 drive mounted in a T 1, 3R, 4(X) or 12 rated enclosure. Minimum enclosure volume allows for specified SCCR.
Thermal requirements may require a larger enclosure. - Circuit breaker part number designations: ● = short circuit current rating.
For 120V/240 V range, use ● = D for 25 kA, G for 65 kA, J for 65 kA, L for 65 kA, R for 65 kA. - For GV2P/3P use, 480 V and 600 V ratings are for Wye connected electrical distribution systems. GV2P●● self protected manual combination starter must be used with GV2GH7 insulating barrier to meet UL 508 Type E rating. GV3P●● self protected manual combination starter must be used with GV3G66 + GVAM11 insulating barrier and auxiliary contact to meet UL 508 Type E rating. The GVAM11 provides a visual indication if the GV3P has tripped.
- Use Class CC or J fast acting or time delay.
- UL61800-5-1 Par. 6.3.7DV.2.1.1 require publishing the standard Type E combination motor controller power rating since this is a basic identification marking of type E devices. However, when applied as an input overcurrent protective device for a drive, the rated current of the Type E combination motor controller, not the rated power, is the key parameter for dimensioning (reference UL61800-5-1Par. 5.2.3.6.2DV.4.1.11 & 5.2.3.6.2DV.4.1.12).
Schneider Electric GV●P Type E combination motor controllers are adjustable, their current range is shown on the adjustment dial and their selection is based on the input current and not the power rating of the drive. - Catalog Number designations: ● = H for drives with heatsink and = P for drives on a base plate.
- Reactor from Altivar catalog or MTE series: RLW, do not substitute.
- Despite a 5kA SCCR, the thermal design is for 1kA as indicated in the catalog. For an operating at 5kA, do not exceed 35 °C (113 °F) ambient temperature at nominal load, or reduce slightly the load not to operate over the input current given in the catalog.
- Despite a 5kA SCCR, the thermal design is for 1kA as indicated in the catalog. For an operating at 5kA, do not exceed 45 °C (113 °F) ambient temperature at nominal load, or reduce slightly the load not to operate over the input current given in the catalog.
Note:
- Integral solid state short circuit protection in the drive does not provide branch circuit protection. Branch circuit protection must be provided in accordance with the National Electrical Code and any local codes.
- The Altivar 12 drive has a 100 kA interrupt rating on the output of the drive. In addition to providing a rating based on shorting the output of the drive, these short circuit current ratings have been obtained by shorting components internal to the Altivar 12. These ratings allow proper coordination of short circuit protection.
Wiring
With Single-Phase Power Supply, when using GV2P and GV3P manual self-protected combination starters for single-phase input applications, wire the drive as illustrated :
Characteristics of the Power Part Terminals
| ATV12H | Applicable wire size (1) mm² (AWG) | Recommended wire size (2) mm² (AWG) | Tightening torque (3) N·m (lb.in) |
| 018F1 037F1 0ppM2 0ppM3 | 2 to 3.5 (14 to 12) | 2 (14) | 0.8 to 1 (7.1 to 8.9) |
| 075F1 UppM2 | 3.5 to 5.5 (12 to 10) | 5.5 (10) | 1.2 to 1.4 (10.6 to 12.4) |
| U15M3 U22M3 | 2 to 5.5 (14 to 10) | 2 (14) for U15M3 3.5 (12) for U22M3 | |
| U30M3 U40M3 | 5.5 (10) | 5.5 (10) |
MANUFACTURER
Schneider Electric Industries SAS
35 rue Joseph Monier
Rueil Malmaison 92500
France
UK REPRESENTATIVE
Schneider Electric Limited
Stafford Park 5
Telford, TF3 3BL
United Kingdom
China RoHS Hazardous Substances Table
The data shown in this spreadsheet are related to the following version of the China RoHS 2.0:
“Administrative Measures for the Restriction of Hazardous Substances in Electric Appliances and Electronic Products” released January 21st 2016.
| Part Name | Hazardous Substances | |||||
| (Pb) | (Hg) | (Cd) | (Cr (VI)) | (PBB) | (PBDE) | |
| Metal Parts | X | O | O | O | O | O |
| Plastic Parts | O | O | O | O | O | O |
| Electronic | X | O | O | O | O | O |
| Contacts | O | O | O | O | O | O |
| Cables and cabling accessories | O | O | O | O | O | O |
This table is made according to SJ/T 11364.
O: indicates that the concentration of hazardous substance in all of the homogeneous materials for this part is below the limit as stipulated in GB/T 26572.
X: indicates that concentration of hazardous substance in at least one of the homogeneous materials used for this part is above the limit as stipulated in GB/T 26572
