Painesdale N7545-729 6-light Sand Coal And Polished Nickel Cage Instruction Manual

N7545-729 6-Light Sand Coal and Polished Nickel Cage

Product Information

Item Number: N7545-729

Date: 04/20/2022

This product is a light fixture that can hold up to six
candelabra base bulbs with a maximum wattage of 60 watts each. The
fixture includes a mounting plate, a ground screw, two mounting
screws, and a canopy. It also comes with a set of rods and loops
that need to be threaded through the fixture body for installation.
A safety cable is included for additional stability.

Product Usage Instructions

WARNING: Before installation, shut off power at
the fuse or circuit breaker.

Preparing the Fixture

1. Carefully unpack the fixture and lay out all the parts on a
   clear area.
2. Determine the desired hanging height and thread rods (C) into
   the top nipple of the fixture body.
3. Pass the fixture wires through each rod and loop (D) as you
   assemble. Then thread the loop (D) onto the top of rods.
4. Connect loop (D) to canopy with key link (E).

Mounting the Fixture

5. Attach mounting plate to outlet box using box screws (Size:
   #8-32*1.25L) provided with outlet box. For additional stability on
   fixtures, install mounting screws into appropriate fasteners.
6. Lace safety cable through the side of the hickey. Tie off the
   set screw assembly as shown. Run the cable through the top of the
   outlet box and secure to a structural member.

Connecting the Wires

7. Connect the electrical wires as shown in Fig. 3, making sure
   that all wire connectors are secured.
8. If your outlet box has a ground wire (green or bare copper),
   connect the fixture’s ground wire to it. Otherwise, connect the
   fixture’s ground wire directly to the mounting strap using the
   green screw provided.
9. After the wires are connected, tuck them carefully inside the
   outlet box.

Finishing the Installation

8. Place fixture canopy (F) over two fixture screws (or nipple)
   and secure with decorative nuts.
9. Install glass (A) to the arm and secure with screws.
10. Place candle cover (B) on the socket.
11. Install up to six candelabra base bulbs up to 60 watts each or
    CFL or LED equivalent (not included) in accordance with the fixture
    specification–DO NOT EXCEED THE MAXIMUM WATTAGE
    RATING!

IMPORTANT: For a safe and secure installation,
these fixtures must be installed by means of supports that are
independent of the outlet box.

Note: Do not clean your light fixture or parts
with water or cleanser.

INSTALLATION INSTRUCTIONS
Item #N7545-729 (04/20/2022) READ AND SAVE THESE INSTRUCTIONS
WARNING! SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER.
AVERTISSEMENT! COUPER LE COURANT AU NIVEAU DES FUSIBLES OU DU DISJONCTEUR.

PREPARING THE FIXTURE (Fig.2) 1.Carefully unpack the new fixture and lay out all the parts on a clear area. Take care not to lose any parts necessary for installation. 2.By measuring, determine the desired hanging height and thread rods (C) into the top nipple of the fixture body. 3.Carefully pass the fixture wires through each rod and loop (D) as you assemble. Then thread the loop (D) onto the top of rods. 4.Connect loop (D) to canopy with key link (E).
MOUNTING THE FIXTURE (Fig.1) 5.Attach mounting plate to outlet box using box screws (Size: #8-32*1.25L) provided with outlet box. For additional stability on fixtures, install mounting screws into appropriate fasteners. 6.Lace safety cable through the side of the hickey. Tie off the set screw assembly as shown. Run the cable through the top of the outlet box and secure to a structural member.
CONNECTING THE WIRES (Fig. 3) 7.At this point, connect the electrical wires as shown in Fig. 3, making sure that all wire connectors are secured. If your outlet box has a ground wire (green or bare copper), connect the fixture’s ground wire to it. Otherwise, connect the fixture’s ground wire directly to the mounting strap using the green screw provided. After the wires are connected, tuck them carefully inside the outlet box.
FINISHING THE INSTALLATION (Fig.1 & 2) 8.Place fixture canopy (F) over two fixture screws (or nipple) and secure with decorative nuts. 9.Install glass (A) to the arm and secure with screws. 10. Place candle cover (B) on the socket. 11. Install (6) six candelabra base bulbs up to 60 watts each or CFL or LED equivalent (not included) in accordance with the fixture specification–DO NOT EXCEED THE MAXIMUM WATTAGE RATING! (NE PAS DEPASSER LA PUISSANCE NOMINALE MAXIMALE!).
Your installation is now complete. Return power to the outlet box and test the fixture.
IMPORTANT: For a safe and secure installation, these fixtures must be installed by means of supports that are independent of the outlet box.
Note: Illustration on this manual is for installation purposes only. It may or may not be identical to the fixture purchased. Do not clean your light fixture or parts with water or cleanser.

Fig.1

Outlet Box Fastener

Lock

Mounting Strap
Self-taping screws Box Screw
Fixture screws Canopy
Set -Mounting plate -Ground screw -Mounting screws (2)

Fig.2

Rod#

F

W35-1-66*3

W35-H-66*1 Candle Cover#

E

CCV21050P-66

D

C

Fig.3
FIXTURE WIRES Black or Smooth

FIXTURE WIRES White or Ribbed

Supply Wire Fixture Wire Ground Screw Decorative Nut
A (36PCS)
B
FIXTURE WIRES Bare Copper (Ground)

HOUSE WIRES Black (Hot)

HOUSE WIRES White (Neutral)

HOUSE WIRES Green (Ground)
