5490-729 Majestic Splendor 1-Light Sand Coal and Polished Nickel Cage Pendant Light
Product Information
Item#: 5490-729 (NEW. 05/24/2022)
This product is a light fixture that requires assembly and
installation. It includes a fixture body, stem, rods, canopy,
crossbar, acrylic disk, and mounting hardware. It is designed to
accommodate three candelabra base bulbs up to 60 watts each or CFL
or LED equivalent (not included).
Product Usage Instructions
- Shut off power at the fuse box or circuit breaker box and
remove the old fixture including the mounting hardware. - Carefully unpack your new fixture and lay out all the parts in
a clean area. Take care not to misplace any small parts necessary
for installation. - Secure stem (L) onto all thread (M) on fixture body (O).
- Determine the desired hanging height and thread rods (J1, J2,
J3, and K) to all thread on stem (L). Screw loop (I) onto rod (J1).
Carefully feed wire through each rod as you assemble. - Thread all thread (C) into canopy loop (F). Secure with lock
washer (Y2) and hex nut (Y1). - Thread the other end of all thread (C) into crossbar (A).
Secure with lock washer (Y2) and hex nut (Y1). Note: The length of
the all thread into the crossbar may be adjusted if necessary. - Attach crossbar (A) to the junction box (not included) with
mounting screws (B) (Size: #8-32N*L1). The side of the mounting
plate (A) marked GND and two convex points must face out. - Attached quick link (H) to loop (I). Slide lock collar (G),
acrylic disk (E) and canopy (D) over quick link (H), then attach
quick link (H) to canopy loop (F). Carefully feed wire through loop
(I), quick link (H), lock collar (G), acrylic disk (E), canopy (D),
canopy loop (F) and all thread (C). - Connect the electrical wires as shown in fig 2, making sure
that all wire connectors are secured. If your junction box has a
ground wire (green or bare copper), connect the fixture’s ground
wire to it. Otherwise, connect the fixture’s ground wire directly
to the crossbar (A) using the green screw provided. - Tuck wire connectors neatly into the junction box.
- Raise the canopy (D) and acrylic disk (E) to the ceiling and
secure with lock collar (G). Note: Adjust the canopy to be centered
if necessary. - Install three candelabra base bulbs (N) up to 60 watts each or
CFL or LED equivalent (not included) in accordance with the fixture
specification. DO NOT EXCEED THE MAXIMUM WATTAGE RATING! - Return power to the junction box and test the fixture.
Note: This product should be installed by a qualified
electrician to ensure proper wiring and installation.
INSTALLATION INSTRUCTIONS
Item#5490-729 (NEW. 05/24/2022) READ AND SAVE THESE INSTRUCTIONS
W AR NI N G ! SHUT P O WE R O FF AT F US E O R CI RC UI T BRE AKE R.
AVERTISSEMENT! COUPER LE COURANT AU NIVEAU DES FUSIBLES OU DU DISJONCTEUR.
ASSEMBLING THE FIXTURE (Fig.1) 1. Shut off power at the fuse box or circuit breaker box and remove
the old fixture including the mounting hardware.
2. Carefully unpack your new fixture and lay out all the parts in a
clean area. Take care not to misplace any small parts necessary for installation.
3. Secure stem (L) onto all thread (M) on fixture body (O). 4. Determine the desired hanging height and thread rods (J1, J2, J3
and (Kto all thread on stem (L). Screw loop (I) onto rod (J1). Carefully feed wire through each rod as you assemble.
5. Thread all thread (C) into canopy loop (F). Secure with lock
washer (Y2) and hex nut (Y1).
6. Thread the other end of all thread (C) into crossbar (A). Secure
with lock washer (Y2) and hex nut (Y1). Note: The length of the
all thread into the crossbar may be adjusted if necessary.
7. Attach crossbar (A) to the junction box (not included) with
mounting screws (B) (Size: #8-32N*L1″). The side of the
mounting plate (A) marked “GND” and two convex points must
face out.
8. Attached quick link (H) to loop (I). Slide lock collar (G), acrylic
disk (E) and canopy (D) over quick link (H), then attach quick link
(H) to canopy loop (F). Carefully feed wire through loop (I), quick
link (H), lock collar (G), acrylic disk (E), canopy (D), canopy loop
(F) and all thread (C). CONNECTING THE WIRES (Fig. 2)
9. Connect the electrical wires as shown in fig 2, making sure that
all wire connectors are secured. If your junction box has a ground wire (green or bare copper), connect the fixture’s ground wire to it. Otherwise, connect the fixture’s ground wire directly to the crossbar (A) using the green screw provided.
10. Tuck wire connectors neatly into the junction box. COMPLETING THE INSTALLATION (Fig. 1) 11. Raise the canopy (D) and acrylic disk (E) to the ceiling and
secure with lock collar (G). Note: Adjust the canopy to be centered if necessary.
12. Install (3) three candelabra base bulbs (N) up to 60 watts each or
CFL or LED equivalent (not included) in accordance with the fixture specification. –DO NOT EXCEED THE MAXIMUM WATTAGE RATING! (NE PAS DEPASSER LA PUISSANCE NOMINALE MAXIMALE!)
Fig.1
Set#A-010 -Crossbar -Ground screw -Mounting screw*2
Rod# -W39-3H-66*1(K) -W39-3-66*3(J1&J2&J3)
Acrylic # -GP5490-1*1 -GP5490-2*8
Your installation is now complete. Return power to the
junction box and test the fixture.
Note: Illustration (Fig. 1) on this manual is for installation purposes only. It may or may not be identical to the fixture purchased.
IMPORTANT: FIXTURE SHOULD BE INSTALLED BY A QUALIFIED ELECTRICIAN TO ENSURE PROPER WIRING AND INSTALLATION.
Fig. 2
Page: 1/1
LA-3473E
