Product Information: 200lbs. 3pt Spreader

Model Number: FTF-200S3PT
Capacity: 200lbs
Application: Designed for planting larger gardens, food plots
or hobby farm.
Function: Cat 1 3pt Hitch With Potentiometer for easy
control

General Safety Rules:

The product comes with a warning to carefully read and
understand all ASSEMBLY AND OPERATION INSTRUCTIONS before
operating. Failure to follow the safety rules and other basic
safety precautions may result in serious personal injury.

Intended Use:

The planter is designed for planting larger gardens, food plots
or hobby farm.

Technical Specifications:

Item	Capacity	Application	Function
Description	200LBS	CAT 1 3pt Hitch	Potentiometer for easy control

Product Usage Instructions:

Read and understand all instructions listed in the owner’s
manual before operating the spreader.
Ensure that the spreader is used for its intended purpose only,
which is for planting larger gardens, food plots or hobby
farm.
Do not modify the product and/or use it for any application
other than that for which it was designed. If you have any
questions relative to a particular application, DO NOT use the
product until you have first contacted the manufacturer to
determine if it can, or should, be performed on the product.
Wear appropriate personal protective equipment such as
non-skid, safety shoes, hard hats, heavy-duty gloves, dust
collection systems, and hearing protection when appropriate.
Do not use the spreader while you are tired or under the
influence of drugs, alcohol, or medication as a moment of
inattention while operating the spreader may result in serious
personal injury.
Keep visitors at a safe distance from the work area to avoid
accidents.
Inspect the spreader for good working condition prior to use
and replace or repair damaged or worn parts immediately to avoid
injury to the operator or others.
Avoid using the spreader on a slanted or uneven surface as it
may result in loss of control.
Store the spreader out of reach of children and inspect it for
good working condition prior to storage and before re-use.

For technical questions, please call 1-218-943-6296.

View Fullscreen

200lbs. 3pt SPREADER
OWNER’S MANUAL

WARNING:
Carefully read and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury.

07132022

Model # FTF-200S3PT

Thank you very much for choosing this product! For future reference, please complete the owner’s record below:

Model: FTF-200S3PT

Purchase Date: _______________

Save the receipt, the warranty, and these instructions. It is important that you read the entire manual

to become familiar with this product before you begin using it.

This product is designed for certain applications only. The manufacturer cannot be responsible for issues arising from modification. We strongly recommend that this product not be modified and/or used for any application other than that for which it was designed. If you have any questions relative to a particular application, DO NOT use the product until you have first contacted us to determine if it can, or should, be performed on the product.

For technical questions, please call 1-218-943-6296.

INTENDED USE
Planter is designed for planting larger gardens, food plots or hobby farm.
TECHNICAL SPECIFICATIONS

Item Capacity Application Function

Description 200LBS CAT 1 3pt Hitch With Potentiometer for easy control

GENERAL SAFETY RULES
WARNING: Read and understand all instructions. Failure to follow all instructions listed
below may result in serious injury.
CAUTION: Do not allow persons to operate or assemble this Spreader until they
have read this manual and have developed a thorough understanding of how the spreader works.
WARNING: The warnings, cautions, and instructions discussed in this instruction
manual cannot cover all possible conditions or situations that could occur. It must be understood by the operator that common sense and caution are factors that cannot be built into this product, but must be supplied by the operator.

SAVE THESE INSTRUCTIONS

Page2 of 8

WORK AREA
· Keep work area clean, free of clutter, and well lit. Cluttered and dark work areas can cause
accidents.
· Keep children and bystanders away while operating a spreader. Distractions can cause you to
lose control, so visitors should remain at a safe distance from the work area.
· Be alert of your surroundings. Using a spreader in confined work areas may put you
dangerously close to sharp tools and rotating parts.
PERSONAL SAFETY
· Stay alert, watch what you are doing, and use common sense when using a spreader. Do not
use a spreader while you are tired or under the influence of drugs, alcohol, or medication. A moment of inattention while operating a spreader may result in serious personal injury.
· Dress properly. Do not wear loose clothing, dangling objects, or jewelry. Keep your hair,
clothing, and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving parts.
· Use safety apparel and equipment. Use safety goggles or safety glasses with side shields that
comply with current national standards or, when needed, a face shield. Use a dust mask if working in dusty work conditions. This applies to all persons in the work area. Also use non-skid, safety shoes, hard hats, heavy-duty gloves, dust collection systems, and hearing protection when appropriate.
SPREADER USE AND CARE
· Do not modify the Spreader in any way. Unauthorized modification may impair the function
and/or safety and could affect the life of the equipment. There are specific applications for which the spreader was designed.
· Always check for damaged or worn-out parts before using the Spreader. Broken parts will
affect the spreader operation. Replace or repair damaged or worn parts immediately.
· Do not exceed the spreader load capacity. · Distribute the load evenly. Uneven loads may cause the spreader to tip, resulting in personal
injury to the operator or others.
· Use the spreader on flat and level surfaces capable of supporting the spreader and its
maximum load. Pulling or pushing a load on a slanted or uneven surface can result in loss of control.
· Store idle spreader. When the spreader is not in use, store it in a secure place out of the reach
of children. Inspect it for good working condition prior to storage and before re-use.
· Clean spreader after each use.
Page3 of 8

ASSEMBLY INSTRUCTIONS
Thread #13 stainless steel hex bolt M6x60 through hopper, then through #11 intermediate spacer B, and control handle assembly, and finally preassemble with #32 stainless steel hex lock nut M6. Insert the #38 stainless steel hex bolt M6x16 through the #60 stainless steel large washer, then through the hopper, and the control handle assembly, and finally pre-tighten the #32 stainless steel hex lock nut M6, adjust the position and then tighten the nuts.
Page4 of 8

OPERATION
WARNING: Operator must read and understand all safety and warning information, operating instructions, maintenance and storage instructions before operating this equipment. Failure to properly operate and maintain the spreader could result in serious injury to the operator or bystanders.
DO NOT at any time carry passengers sitting or standing on the spreader. DO NOT allow children to play on, stand upon or climb on the spreader. DO NOT exceed rated capacity of 200lb. Replace or repair damaged or worn parts immediately. To avoid personal injury and/or equipment damage DO NOT EXCEED 5 MPH. ONLY tow with recommended tractor. ALWAYS inspect the spreader before using to assure it is in good working condition. ALWAYS keep hands and feet clear from moving parts while operating the equipment. DO NOT use if the spreader is damaged or worn as this may cause injury to the operator or
bystanders. ALWAYS make sure the spreader is secure and locked to the hitch of the approved tractor
before operating. NEVER add material to the spreader unless it is attached to the tractor.
MAINTENANCE
· Maintain your spreader. It is recommended that the general condition of any spreader be
examined before it is used. Keep your spreader in good repair by adopting a program of conscientious repair and maintenance. If any abnormal vibrations or noise occurs, have the problem corrected before further use. Have necessary repairs made by qualified service personnel.
· After each use clean material out of hopper. · Rinse/dry inside and outside of the spreader after each use. · Periodically check all fasteners for tightness. · Annually clean and lightly lubricate parts. · Use a glossy enamel spray paint to touch up scratched or worn painted metal surfaces. · Never exceed load capacity rating of 200lbs it will damage the spreader.
IMPORTANT: If a part needs replacement, only use parts that meet the manufacturer’s specifications. Replacement parts that do not meet specifications may result in a safety hazard or poor operations.
Page5 of 8

DIAGRAM & PARTS LIST
Page6 of 8

Part#

Description

Qty.

1 200LB Hopper

2 M6x40 Hex Bolt

3 M6 Hex Lock Nut

4 M6x45 Hex Bolt

5 Ø5 Lock Washer

6 M6x40 Hex Bolt

7 R Pin

8 M6x16 Hex Bolt
