How to Read a SoundTube Tap Switch

Product Information

The SoundTube Tap Switch is a feature available in various
series of SoundTube speakers, including RSi series, HPi series, CMi
series, SMi series, and XT series. This switch allows you to adjust
the impedance and tap settings of the speaker to match your audio
system requirements.

Product Usage Instructions

To read and set the SoundTube Tap Switch, follow these
steps:

1. Identify the desired mode you want to set the speaker to – low
   impedance/transformer-bypass mode, 70V mode, 100V mode, or 25V
   mode.
2. If you want to set the speaker to the low
   impedance/transformer-bypass mode, match up the symbol to both
   arrows as shown in the example above.
3. If you want to set the speaker to the 70V mode, line up the
   desired tap setting with the arrow next to the 70V symbol.
4. If you want to set the speaker to the 100V mode, line up the
   desired tap setting with the arrow next to the 100V symbol.
5. If you want to set the speaker to the 25V mode, use the smaller
   red text on the 70V side and line up the desired tap setting with
   the arrow next to the 70V symbol.

By following these instructions, you will be able to read and
adjust the SoundTube Tap Switch to optimize your speaker’s
performance according to your audio system requirements.

HOW TO READ A SOUNDTUBE TAP SWITCH
(Applies to RSi series, HPi series, CMi series, SMi series, XT series)
Example below is of RS600i, tapped to low impedance mode

70V, 25V side

6 9 3 .63 1.3
2

70V
33 17 5
25V .5
100V

X 3

3

6

9 17

Low impedance setting
100V side

Low impedance/transformer-bypass mode: Match up the symbol to both arrows (like shown above). 70V mode: Line up the desired tap setting with the arrow next to the 70V symbol 100V mode: Line up the desired tap setting with the arrow next to the 100V symbol 25V mode: Use the smaller red text on the 70V side and line up the desired tap setting with the
arrow next to the 70V symbol
