TAU-BS-01 Taurus Sounder Base

Product Information: TAU-BS-01 HYFIRE Taurus Sounder Base

The TAU-BS-01 HYFIRE Taurus Sounder Base is a sounder base that
is available in black plastic as well. It has a programming switch,
mounting holes, fixing holes, and a battery compartment. The device
has an anti-tamper protection feature to ensure security. It also
has a DIP switch at the back of the sounder body to select tone and
volume.

Mounting Steps

1. Remove the mounting base from the sounder.
2. Place the mounting base on the ceiling or wall.
3. Fix the mounting base using the fixing holes.
4. Insert batteries in the battery compartment and ensure they are
   inserted correctly observing the polarity indications on the base
   of the sounder base.
5. Attach the sounder to the mounting base by aligning it with the
   mounting holes and turning it clockwise.

Tone and Volume Selection

Use the DIP switch on the back of the sounder body to select
tone and volume. Primary and secondary tone are selected according
to panel setting.

* EN 54-3 approved volume

Primary Tone Designation

The following are the primary tone designations:

• Silent
• Warble Tone
• Continuous tone
• Slow Whoop (Dutch)
• German DIN tone
• Alternate HF slow sweep
• Alternative warble
• Analogue sweep tone
• Australian Alert (intermittent tone)
• Australian Evac (slow whoop)
• FP1063.1-Telecom French tone
• AFNOR HF Back up interrupted tone
• HF Back up interrupted tone – fast
• HF Continuous Interrupted tone
• Interrupted tone medium
• ISO 8201 LF BS5839 Pt 1 1988
• ISO 8201 HF LF Back up Alarm
• LF Buzz
• LF Continuous tone BS5839
• Siren 2 way ramp (long)
• Siren 2 way ramp (short)
• Swedish all clear signal
• Swedish Fire signal
• Sweep tone (1 Hz)
• Sweep tone (3 Hz)
• Sweep tone (9 Hz)
• US Temporal Pattern HF LF Sweep (Cranford tone)

Primary Tone Description

The following are the primary tone descriptions:

• No sound
• 800Hz for 500ms, then 1000Hz for 500ms
• 970Hz continuous tone
• 500-1200Hz for 3500ms, then off for 500ms
• 1200-500Hz swept every 1000ms (1Hz)
• 2350-2900Hz swept every 333ms (3Hz)
• 800Hz for 250ms, then 960Hz for 250ms
• 500Hz for 250ms, then 600Hz for 250ms
• 500-600Hz swept every 500ms (2Hz)
• 970Hz for 625ms, then OFF for 625ms
• 500-1200Hz sweep for 3750ms, then OFF for 250ms
• 800Hz for 250ms, then 970Hz for 250ms
• 554Hz for 100ms, then 440Hz for 400ms

TAU-BS-01 HYFIRE TAURUS SOUNDER BASE
QUICK START GUIDE

THE BOX

INSIDE THE BOX

MOUNTING STEPS

Taurus QR code

· 1 x Sounder Base

Proceed as follows to complete the device installation.

Manual QR code · 2 x CR123A batteries

TAU-BS-01
Hyfire Taurus

Product code Product name

· 3 x Screws · 1 x Battery cover · 1 x Quick start guide

1

2

Sounder Base

· 1 x QR code

Available also in black plastic: TAU-BS-01-BL
IMPORTANT TO CONSIDER
When mounting a wireless device a comprehensive radio survey should have been carried out to establish the location that provides the best coverage and optimum reach. Taking into consideration the building structure and materials, the survey identifies the wireless infrastructure required and product locations for optimum performance, identifying any factor that could prevent radio integrity. Avoid fixing or mounting the unit close to the following: · Equipment that utilises large electrical currents · Large metal objects or structures · Fluorescent lighting fittings · Metal ceiling structures · IT cabling. Keep 2 meters minimum spacing between other wireless equipment in the area to avoid signal interference.
EN54 approved environmental temperature range is -10°C to +55°C
UNBOXING
· When unboxing the Sounder Base you will find the unit and its mounting base. · This comes with pre-formed mounting holes to mount the mounting base. · A securing screw is fitted to ensure unwanted removal of the attached device. · Two screws are supplied to fix the sounder to the mounting base and one screw (optional)
can be used to fix the battery cover, when the base is topped by the lid. · Dip switches are found inside the sounder to select your desired tone and volume. For more information, please refer to the complete product manual.
Unit B12a, Holly Farm Business Park, Honiley, Warwickshire, CV8 1NP T: +44 (0)1926 485282, E: [email protected], W: www.hyfirewireless.com

Remove the mounting base from the sounder.

MOUNTING HOLES
· Locate the mounting holes and mark them using a pencil on the desired surface your are drilling. · Using a suitable-sized drill bit (6 mm) drill the marked screw points on your chosen surface. · Ensure you use the correct fixings for the type of surface you are mounting to. · Screw the base to the ceiling using all fixing holes and appropriate-sized screws.

FIXING HOLES

3

TONE AND VOLUME SELECTION

BATTERY COMPARTMENT

PROGRAMMING SWITCH

COVER

· Put the sounder back onto the mounting base and secure wReitmh othveettwhoe sbcartetwersyscuopmplpieadrt.ment cover on the base.

· Select the tone and volume you require (see next page)

· Ensure the programming switch in the base of the sounder

is in position ON.

FIXING HOLES

4

BATTERY A LODGTOENMEENT AND VOLUME SELECTION

BATTERY B LODGEMENT LED INDICATOR

·tinhFdeiityctaahtreieo2nthxseCocRno1trh2ree3cAbtabwsaaetytoerfrotieuhsnedesnoosubunsredinrevgrinbygoasutheh.eapveolcaPhrieRtycOkSGeWdRIATMCMHING · The LED will signal 4 times red. ··a··w··lMTEESPtitehnneuohreslstvneutuetLahcrhrEtteeteeihDvtytthesewhowoelseuyouiwtlpngolrseibrrdncteopcrleeieeglhnraawnrkbican/nseamrfdeetcsthmvwdkhueoepio4slnbpunbegtalmticaimosesoteewdttneeh.yoidsrteof.ycsuthmcghrorieoenevuqesetnuohnrtiueariannesbngd(datsehbsetriaehsebseofeanonfseartsemxhnitgetdsopnsspaapoeagloucresnut)idrteieorn 1. oisf itnhepossoiutinodneOr Nba. se anti tamper protection.

COBLMOABDCTPATGOATEETVRRMEETYERRMANYETNT

– ++ –

5
BATTERY B LODGEMENT LED INDICATOR

· Ensure switch on position.
· Fit the 2x CR123A batteries ensuring you have checked
they are the correct way round observing the polarity indications on the base of the sounder base.
FO···IPTMTXhhToIeevINOeLLGEEtNhDDHAewwOLsiiwllLSll iEbsCticlgRiFhnnOEkianWlRfet4hwteimsbeaecssoenreoddfs.tghreeesonuannddetrhbeansseigtonaplosition 1. ·aFlEtieRtnrstenhumaerteoibvvyaeeotlutytehgrreeryepbcelaaontcm/terepertdayhre4ctmobtmiaemtnpteetasrrc.ytomcvoeevrnetorncaostvhteehribsoanfsoterhm. esbpaasret .
of the sounder base anti tamper protection.

6
· Fit the detector or the blanking cap to the top of the device and secure the safety screw using a M3 allen key. · Put the QR code available in the box either on the system map or on the dedicated pages at the end of translator or expander manual.

L50-BS-1400 (Rev_P.5)

TAU-BS-01 HYFIRE TAURUS SOUNDER BASE
QUICK START GUIDE

TONE AND VOLUME SELECTION
Use the DIP switch on the back of the sounder body to select tone and volume. Primary and secondary tone are selected according to panel setting.

SWITCH NUMBER
1 2 3 4 5 6 7 8

DIP SWITCH GROUP FUNCTION
ACOUSTIC OUTPUT TONE SETTING
ACOUSTIC OUTPUT VOLUME SETTING
NOT USED

NOTES CHECK TONE SET TABLES CHECK ACOUSTIC VOLUME TABLE

ACOUSTIC VOLUME LEVEL
HIGH*

DIP CONFIGURATION
11

MEDIUM HIGH

01

MEDIUM

10

LOW

LOW

00

* EN 54-3 approved volume

ACOUSTIC OUTPUT
TONE SETTING

ACOUSTIC OUTPUT
VOLUME SETTING

1
ON

1234 5678

0

Tone number

DIP switch configuration: 1, 2,
3, 4 and 5

0

11111

1 *

11101

2 *

01011

3 *

10101

4 *

00111

5

10010

6

11110

7

11100

8

10100

9

10001

10

10110

11

00001

12

00101

13

11011

14

11001

15

01001

16

01111

17

01101

18

01110

19

01100

20

11010

21

01010

22

11000

23

00000

24

00010

25

00100

26

00110

27

10111

28

10011

29

01000

30

00011

31

10000

* EN 54-3 approved volume

Primary Tone Designation
Silent Warble Tone Continuous tone Slow Whoop (Dutch) German DIN tone Alternate HF slow sweep Alternative warble Alternative warble Analogue sweep tone Australian Alert (intermittent tone) Australian Evac (slow whoop) FP1063.1-Telecom French tone AFNOR HF Back up interrupted tone HF Back up interrupted tone – fast HF Continuous Interrupted tone Interrupted tone medium ISO 8201 LF BS5839 Pt 1 1988 ISO 8201 HF LF Back up Alarm
LF Buzz LF Continuous tone BS5839
Siren 2 way ramp (long) Siren 2 way ramp (short) Swedish all clear signal
Swedish Fire signal Sweep tone (1 Hz) Sweep tone (3 Hz) Sweep tone (9 Hz) US Temporal Pattern HF LF Sweep (Cranford tone)

Unit B12a, Holly Farm Business Park, Honiley, Warwickshire, CV8 1NP T: +44 (0)1926 485282, E: [email protected], W: www.hyfirewireless.com

Primary Tone Description
No sound 800Hz for 500ms, then 1000Hz for 500ms
970Hz continuous tone 500-1200Hz for 3500ms, then off for 500ms
1200-500Hz swept every 1000ms (1Hz) 2350-2900Hz swept every 333ms (3Hz) 800Hz for 250ms, then 960Hz for 250ms 500Hz for 250ms, then 600Hz for 250ms
500-600Hz swept every 500ms (2Hz) 970Hz for 625ms, then OFF for 625ms 500-1200Hz sweep for 3750ms, then OFF for 250ms 800Hz for 250ms, then 970Hz for 250ms 554Hz for 100ms, then 440Hz for 400ms
2800Hz for 1s, then OFF for 1s 2800Hz for 150ms, then OFF for 150ms
2800Hz continuous 800Hz for 500ms,then OFF for 500ms 1000Hz for 250ms, then OFF for 250ms 970Hz for 500ms, then OFF for 500ms 2850Hz for 500ms, then OFF for 500ms 800Hz for 150ms, then OFF for 150ms
800-950Hz swept every 9ms 800Hz continuous
500-1200Hz rising for 3000ms, then falling for 3000ms 500-1200Hz rising for 250ms, then falling for 250ms 660Hz continuous 660Hz for 150ms, then OFF for 150ms 800-900Hz swept every 1000ms 800-970Hz swept every 333ms (3Hz) 800-970Hz swept every 111ms (9Hz) (2900Hz for 500ms ON, 500ms OFF) x3, then 1500ms OFF 800-1000Hz swept every 500ms (2Hz)

Secondary Tone Description
970Hz continuous 800Hz continuous 1000Hz continuous tone 500-1200Hz for 3500ms, then off for 500ms 800Hz continuous 2400Hz continuous 800Hz continuous 500Hz continuous 500Hz continuous 2400Hz continuous 500-1200Hz sweep for 3750ms, then OFF for 250ms 500-1200Hz rising for 250ms, then falling for 250ms 800Hz continuous 2800Hz continuous 970Hz continuous 2800Hz continuous 800Hz continuous 800Hz continuous 970Hz for 500ms, then OFF for 500ms 2850Hz for 500ms, then OFF for 500ms 800Hz continuous 800Hz continuous 800Hz continuous 800Hz continuous 800Hz continuous 660Hz continuous 660Hz for 150ms, then OFF for 150ms 800Hz continuous 800Hz continuous 800Hz continuous 2900Hz continuous 800Hz continuous
