MAX96717 DPHY Evaluation Kit

Product Information

The MAX96717F is a DPHY evaluation kit designed for complete
GMSL evaluation using a standard FAKRA coaxial cable or HMTD cable.
It includes a serializer interface (CSI serializer) and a
deserializer interface (CSI deserializer). The kit is powered by
USB, a 12V wall adapter, or an external power supply. It features a
powerful and simple GUI for comprehensive device evaluation.

Product Usage Instructions

Connect the MAX96717F DPHY EV kit to your computer using the
included USB cable.
Install the EV kit software (GUI) onto your Windows 10 or
higher computer using the MAXSerDesEV-GMSL_Vxxxx_Install.exe
file.
Follow the instructions in the GUI user’s guide to configure
and control the MAX96717F DPHY EV kit.
For serial link coax cable configuration, connect the MAX96717F
serializer to the MAX96716 deserializer using a coaxial cable.
For HMTD cable configuration, refer to the Ordering Information
section for HMTD specific EV kits.
Use the GUI program MAXSerDesEV-GMSL.exe to send GMSL data from
the serializer to the deserializer, converting it into MIPI
CSI-2.
Refer to the MAX96717 EV Kit Default Jumper diagram to
configure jumpers on the MAX96717F DPHY EV kit board.

View Fullscreen

Evaluates: MAX96717F

Click here to ask an associate for production status of specific part numbers.
MAX96717 DPHY Evaluation Kit

General Description
The MAX96717 DPHY evaluation kit (EV kit) provides a proven design to evaluate the MAX96717 high-bandwidth gigabit multimedia serial link (GMSL) serializer with spread spectrum and full-duplex control channel using a standard FAKRA coaxial (Coax) or HMTD cable. The EV kit also includes Windows® 7 and Windows® 10 software that provides a simple graphical user interface (GUI) for exercising features of the device. The EV kit comes with a MAX96717, MAX96717F, MAX96717K or MAX96717R IC installed.
For complete GMSL evaluation using a standard FAKRA coaxial cable or HMTD cable, order the MAX96717 Coax EV kit and a companion deserializer board (MAX96716 Coax EV kit referenced in this document).
Note: In the following sections, “serializer” refers to camera serializer interface (CSI) serializer, including MAX96717, MAX96717F, MAX96717K and MAX96717R. “Deserializer” refers to CSI deserializer MAX96716 and its variants.
This document applies to both Coax and HMTD evaluation kits. Coax cable is also referenced in this document.

Benefits and Features
Ability for Serializer to send GMSL data to Deserializer, converting it into MIPI CSI-2
Windows 10 or Higher Compatible Software Support USB Controlled Interface (Cable Included) Powerful and Simple GUI for Comprehensive Device
Feature Evaluation Board Powered by USB, 12V Wall Adapter or
External Power Supply Proven PCB Layout Fully Assembled and Tested Note: Coax EV kits are configured to use PoC and FAKRA connectors. For HMTD connector, order HMTD specific EV kits found in the Ordering Information section.
Ordering Information appears at end of data sheet.

MAX96717 EV Kit Files
FILE
MAXSerDesEV-GMSL_Vxxxx_Install.exe
MAXSerDesEV-GMSL.exe

DECRIPTION
Installs the EV kit software (GUI) onto Windows 10 or higher computers. Includes GUI user’s guide, microcontroller firmware, and documentation.
GMSL graphical user interface (GUI) program

Windows is a registered trademark and registered service mark of Microsoft Corporation.

319-100949; Rev 2; 9/22

© 2022 Analog Devices, Inc. All rights reserved. Trademarks and registered trademarks are the property of their respective owners. One Analog Way, Wilmington, MA 01887 U.S.A. | Tel: 781.329.4700 | © 2022 Analog Devices, Inc. All rights reserved.

MAX96717 DPHY Evaluation Kit

Evaluates: MAX96717F

SAM TEC

RESET

ARM MKL 02Z 32V
FG4

5V (USB) USB

ARM MK2 0D X256
VLH 7

LEVE L SH IFT MAX 3373
LEVE L SH IFT MAX 3373

25 MHz

I2C/UART POWER DOW N

3.3V SCL SDA GND External uC

DPHY CSI-2

LINE FAULT MONITOR

MAX96717

OUTA+

OUTALINE FAULT MONITOR

12V POC FILTER FAKRA COA X
H MT D

VDD VD D18 VD DIO

1.2V 1.8V

3.3 V

NOT USED

12 V 5V (USB) EXT ER NAL

1V 3.3V MAX 20019

3.3V 2.5V 1.8V 1.2V MAX 16922

Figure 1. MAX96717 DPHY EV Kit Block Diagram

LOC K

3.3 V

12V 5V USB

ER ROR

EXT ER NAL POWER

12V BARREL JACK

POWER SWITCH

TEENS Y RESE T SWIT C H

USB C ON N ECT ION

POWER TEST POIN TS
VDD JUMPER
PWR SUPPLY JUM PER

ERRB LED LOCK LED D UT DUT RES ET S W FAKRA CONNECTOR

POC FI LTE R COMPONE NTS

GPIO JUMPERS VDDIO JUMPER

I2C SCL JUM PER

Figure 2. MAX96717 EV Kit Picture of Board (Top View)

I2C SDA JUM PER

EXTERNAL UC POC JUMP ER

www.analog.com

Analog Devices 2

MAX96717 DPHY Evaluation Kit
TEENS Y MCU MOD UL E

Evaluates: MAX96717F

XTAL

PMI C IC

SAM TEC C ON N ECT OR

Figure 3. MAX96717 EV Kit Picture of Board (Bottom View)

Figure 4. MAX96717 EV Kit Default Jumper
www.analog.com

Analog Devices 3

MAX96717 DPHY Evaluation Kit

Evaluates: MAX96717F

Quick Start
This procedure applies to both Coax and HMTD EV kits. Figure 5 shows a typical application that uses the CSI serializer with the CSI deserializer.
Required Equipment
The following equipment is required to successfully use the MAX96717 DPHY EV kit in a serial link coax cable configuration:
MAX96716 DPHY EV kit rev A
FAKRA Cable Assembly
PC with Windows 10 or higher and GMSL2 Software
PC running GMSL Software
Power supply source (500mA USB port, 5V/1A DC Supply or 12V barrel jack DC supply [provided])
Micro-USB cable
Procedure
1) Follow the steps below to verify board operation.
2) Download and install the latest GMSL EV kit software from www.maximintegrated.com or contact Maxim Applications. Follow the GMSL GUI User’s Guide instructions.
3) Verify that jumpers on the serializer board are in their default positions, as shown in Figure 2, and SW1 is in the OFF position.
4) Verify that jumpers on the deserializer board are in their default positions, and SW1 is in the OFF position.
5) Set up the system as below: · Connect FAKRA cable from FAKRA PCB connector from serializer to deserializer (Link A or Link B). · Connect +12V wall power supply into the POWER connector.
6) Turn SW1 to the ON position on both serializer and deserializer EV kits.
7) Verify that all of the power LEDs and red Teensy LED are illuminated, indicating that the board is powered, and Teensy uC is powered on both serializer and deserializer.

8) Verify the LOCK LED on both serializer and deserializer EV kits are illuminated, indicating that the link is successfully established. If the LOCK_LED is OFF or ERR_LED is ON, refer to the Troubleshooting section.
9) Start the GMSL GUI software.
10) When the GUI opens, it automatically searches for any active listener in both I2C and UART mode and identifies a valid GMSL product. Once the serializer and deserializer are identified, they are shown as tabs in the GUI.
11) Read register 0x00 in both deserializer and serializer to ensure both devices are active.
12) Basic bring-up is complete. Refer to the GMSL GUI User’s Guide, GMSL Bring-up Guide, the latest datasheet, or contact Maxim Applications for additional details.
Configuration (CFG) Pin Settings
The serializer’s CFG pins use the pin voltage latched at power-up to configure the device. On-board I2Cconfigurable digital potentiometers or 0402 resistors set the configuration (CFG) pin voltage levels. By default, the board is wired to use the digital potentiometers.
The CFG states can be configured using the GMSL 2 GUI. Use the following GUI menu path: Tools > Set CFG Pin Levels.
To switch between using the digital potentiometer or resistor network to set CFG states, use 0 resistors to connect the CFG0/1 nets. The voltage on the CFG pins can be monitored on the CFG0 and CFG1 test points or on the 2×12 MFP header (J1).
If the serializer is not identified in the GUI, it is still possible to write to the CFG pins. For more information, refer to the Troubleshooting section.
The voltage levels scale with VDDIO. Tables 1-5 indicate the voltage levels necessary to configure the serializer for different modes of operation.

www.analog.com

Analog Devices 4

MAX96717 DPHY Evaluation Kit

Evaluates: MAX96717F

MI PI CSI-2 D PHY

IM AGE

SENSOR

I2C

MAX96717

GPIO

PMI C

POC

MI PI CSI-2 D PHY

IM AGE

SENSOR

I2C

MAX96717

GPIO

PMI C

POC

MI PI CSI-2 D PHY

IM AGE

SENSOR

I2C

MAX96717

GPIO

PMI C

POC

MI PI CSI-2 D PHY

IM AGE

SENSOR

I2C

MA X96 717

GPIO

PMI C

POC

GMSL LINK A GMSL LINK B GMSL LINK C GMSL LINK D

POWER SUPPLY

POC MI PI CSI-2 C PHY/D PH Y
POC

MAX9672 4 POC

SOC/FPGA

I2C
POC GPIO

Figure 5. MAX96717 EV Kit Typical Block Diagram

Table 1 MAX96717/717F/717K CFG0 Pin Input Map

CFG0 INPUT VOLTAGE (PERCENT OF VDDIO)

SUGGESTED RESISTOR VALUES
(1% TOLERANCE)

MIN
0% 16.9% 28.8% 40.7% 52.6% 64.5% 76.4% 88.3%

TYP
0% 20.2% 32.1% 44.0% 56.0% 67.9% 79.8% 100%

MAX
11.7% 23.6% 35.5% 47.4% 59.3% 71.2% 83.1% 100%

R1 ()
OPEN 80600 68100 56200 44200 32400 20500 10000

R2 ()
10000 20500 32400 44200 56200 68100 80600 OPEN

MAPPED CONFIGURATION

I2CSEL I2C
UART

ROR/XTAL ROR XTAL ROR XTAL

DEVICE ADDRESS
0x80 0x84 0x80 0x84 0x84 0x80 0x84 0x80

www.analog.com

Analog Devices 5

MAX96717 DPHY Evaluation Kit

Evaluates: MAX96717F

Table 2. MAX96717R CFG0 Pin Input Map

CFG0 INPUT VOLTAGE (PERCENT OF VDDIO)

MIN 28.8% 40.7%

TYP 32.1% 44.0%

MAX 35.5% 47.4%

SUGGESTED RESISTOR VALUES
(1% TOLERANCE)

R1 ()

R2 ()

68100

32400

56200

44200

MAPPED CONFIGURATION
DEVICE ADDRESS 0x80 0x84

Table 3. MAX96717/717K CFG1 Pin Input Map

CFG1 INPUT VOLTAGE (PERCENT OF VDDIO)

SUGGESTED RESISTOR VALUES(1% TOLERANCE)

MIN

TYP

MAX

R1 ()

R2 ()

0% 16.9% 28.8% 40.7% 52.6% 64.5% 76.4% 88.3%

0% 20.2% 32.1% 44.0% 56.0% 67.9% 79.8% 100%

11.7% 23.6% 35.5% 47.4% 59.3% 71.2% 83.1% 100%

OPEN 80600 68100 56200 44200 32400 20500 10000

10000 20500 32400 44200 56200 68100 80600 OPEN

MAPPED CONFIGURATION (GMSL2 OPERATING MODE)

CXTP

DATA RATE (GBPS)

TUNNEL/PIXEL MODE

3 6 STP 3 6

Tunnel Pixel

3 6 COAX 3 6

Tunnel Pixel

Table 4. MAX96717F CFG1 Pin Input Map

CFG1 INPUT VOLTAGE (PERCENT OF VDDIO)

SUGGESTED RESISTOR VALUES
(1% TOLERANCE)

MIN
0% 16.9% 28.8% 40.7% 52.6% 64.5% 76.4% 88.3%

TYP
0% 20.2% 32.1% 44.0% 56.0% 67.9% 79.8% 100%

MAX
11.7% 23.6% 35.5% 47.4% 59.3% 71.2% 83.1% 100%

R1 ()
OPEN 80600 68100 56200 44200 32400 20500 10000

R2 ()
10000 20500 32400 44200 56200 68100 80600 OPEN

MAPPED CONFIGURATION (GMSL2 OPERATING MODE)

CXTP

DATA RATE (GBPS)

TUNNEL/PIXEL MODE

3 STP
3

Tunnel Pixel

3 COAX
3

Tunnel Pixel

www.analog.com

Analog Devices 6

MAX96717 DPHY Evaluation Kit

Evaluates: MAX96717F

Table 5. MAX96717R CFG1 Pin Input Map

CFG0 INPUT VOLTAGE (PERCENT OF VDDIO)

MIN 52.6% 88.3%

TYP 56.0% 100%

MAX 59.3% 100%

SUGGESTED RESISTOR VALUES
(1% TOLERANCE)

R1 () 44200 10000

R2 () 56200 OPEN

MAPPED CONFIGURATION
TUNNEL/PIXEL MODE Tunnel Pixel

Table 6. Serializer Jumper Descriptions
The following table contains details of all the connectors, jumpers, and test points of the EV kit. The power configuration of the EV kit hardware can be reconfigured to allow external supply connections. Figure 6 shows the power connection options.

JUMPER

SIGNAL

POWER J1 J2 J3 J4 J5 J6 VDDIO VDD VDD_REF RX_SDA TX_SCL EXP EXT_UC JAP

+12V, EXT PWR, 5V USB, MFP HMTD SIOA (+/-) USB Connection SAMTEC Connector External 12V Input External Supply Input VDDIO, 1.8V, 3.3V VDD, 1V, 1.2V VDD_REF UART TX, I2C SDA UART RX, I2C SCL SDA_RX, SCL_TX SDA, SCL, GND, VDD_REF COAX SIOA+

DEFAULT POSITION
+12V Open Open Open Open N/A Open 3.3V 1.2V 3.3V TNZ_SDA TNZ_SCL Open Open Open

FUNCTION
Power to supply voltage VSUP. Connection for MFP signals. HMTD connector for SIOA GMSL signal. Connection from PC to TEENSY and +5V USB connection. Connector for MIPI signals and MFP (SPI, I2C, GPIOs) signals. 12V DC input for board power. Header for GND connection and optional external voltage. Connection between VDDIO, 1.8V and 3.3V. Connection between VDD, 1V and 1.2V. Connection between VDD_REF and 3.3V for I2C/UART lines. Selection of I2C or UART connection to TEENSY. Selection of I2C or UART connection to TEENSY. External I2C or UART connections. External I2C or UART connections through the levels translator. GMSL and PoC connection for COAX Link A.

www.analog.com

Analog Devices 7

MAX96717 DPHY Evaluation Kit

Evaluates: MAX96717F

U SB_5V TP
USB

DC POWE R JACK , J1
T ERM INAL BLOCK, J3

12 V TP
SW1

EXT ER NAL 5V-14 V

VSUP

MA X20 019 1.0 V 3.3 V

12V POC FILTER

FAKRA COAX A

1V 3V3
TP

MA X16 922 3.3 V 2.5 V 1.8 V 1.2 V

D NI

3V3 _OUT

TP 1V8

TP 1V

VD DIO VDD

Figure 6. MAX96717 EV Kit Power Diagram

Troubleshooting
If the MAX96717 EV kit PCB fails to power-up or does not function properly, try the appropriate remedial actions below.
1) Verify the board’s red power switch (SW1) is set to the ON position.
2) Verify that the device is powered properly. Ensure that the voltages are within their operating ranges at all device pins. Verify that power LED is illuminated and/or measure voltage rail jumpers.
3) Check that all jumpers are correctly set. Refer to the default jumper settings table in the serializer and deserializer EV kit data sheets. Also, ensure that all jumpers are firmly attached. Replace loose or damaged jumpers, if necessary.
4) Check that the USB cable is properly seated in the USB port.
5) Check that the coax/STP cable connection between serializer and deserializer is properly secured.
6) Verify that the DUT has not been inadvertently put into Teensy reset mode. The board’s TEENSY_RST button should only be pressed when firmware is being flashed to the DUT. If the button is pressed during normal operation, the device goes into Teensy reset mode. Power cycle the board to resume normal operation with the current firmware.
7) Validate that the correct CFG pin voltages are being used to configure the serializer. Check the method of biasing the CFG voltage at powerup. Measure the voltages at the pins. For details, refer to the Configuration (CFG) Pin Settings section.

8) If the CFG pin settings are incorrect, but the device is not identified in the GUI, proceed to the Configuration (CFG) Pin Settings section and set the desired CFG state values. Reset the part and verify if the GUI automatically identifies the device. If not, use the following menu path to locate the device: Options tab > Identify Devices. The low-level Commands tab can be monitored to see if I2C writes to the CFG pots are successful.
9) Check that the I2C/UART jumpers match the DUT communication mode (SCL/SDA for I2C, TX/RX for UART).
10) Check that the AC coupling capacitors are populated correctly and routing the serial link to the correct connector for Coax or STP mode. For coax boards, capacitors C12 and C13 should be populated. For STP boards, capacitors C3 and C19 should be populated (MAX96717 EV kit boards are shipped with the correct capacitors installed.).
11) Check that the microcontroller firmware is active by observing the blinking red Teensy LED at power-up. If the LED is not blinking, refer to the available software documentation to reprogram the microcontroller.
12) Check that the PC is detecting the COM port when the micro-USB cable is connected. Use the Windows Device Manager to check COM port status.
13) Power-cycle the board and reopen the GUI. 14) Try a new or different serializer or deserializer board.

www.analog.com

Analog Devices 8

MAX96717 DPHY Evaluation Kit

Evaluates: MAX96717F

MAX96717 DPHY EV Kit Package Contents

ITEM DESCRIPTION

QTY

MAX96717 DPHY EV kit (or a variant)

Micro-USB Cable

12V DC Wall Supply

Coax Cable for Coax EV kits or HMTD cable for HMTD EV kits

Major Component Suppliers
SUPPLIER Rosenberger Hochfrequenztechnik GmbH
TDK Corp. Diodes Inc. Murata Electronics North America, Inc.
Coilcraft Panasonic North America
ECS, Inc. Vishay
KYOCERA Sullins Electronics Corp

PHONE 011-49-86 84-18-0
547-803-6100 972-987-3900 770-436-1300 847-639-6400
N/A 913-782-7787 1-402-563-6866
N/A 760-744-0125

WEBSITE www.rosenberger.de product.tdk.com/info/en/catalog/index.html
www.diodes.com www.murata-northamerica.com
www.coilcraft.com na.panasonic.com/us/
www.ecsxtal.com www.vishay.com https://global.kyocera.com/ www.sullinscorp.com

Ordering Information

PART

TYPE

MAX96717-AAK-EVK#**

CSI-2 to GMSL2 Serializer DPHY w/COAX

MAX96717-ACK-EVK#**

CSI-2 to GMSL2 Serializer DPHY w/HMTD

MAX96717K-AAK-EVK#**

CSI-2 to GMSL2 Serializer DPHY w/COAX

MAX96717K-ACK-EVK#**

CSI-2 to GMSL2 Serializer DPHY w/HMTD

MAX96717F-AAK-EVK#

CSI-2 to GMSL2 Serializer DPHY w/COAX

MAX96717F-ACK-EVK#*

CSI-2 to GMSL2 Serializer DPHY w/HMTD

MAX96717R-AAK-EVK#**

CSI-2 to GMSL2 Serializer DPHY w/COAX

MAX96717R-ACK-EVK#**

CSI-2 to GMSL2 Serializer DPHY w/HMTD

*Contact factory. **Future product contact factory for availability.

www.analog.com

Analog Devices 9

MAX96717 DPHY Evaluation Kit

Evaluates: MAX96717F

MAX96717 EV Kit Bill of Materials (Coax)

ITEM QTY

REF DES

VAR STATUS

MAXINV

MFG PART #

MANUFACTURER

1 C1

Pref

20-0022P-27J

C1005C0G1H220G050

TDK

1 C2

Pref

C4, C8, C11, C16,

C18, C21-C24, C26-

22 C31, C39, C40, C45, Pref

C46, C55, C119,

C120

20-0027P-27 20-000U1-DA22

C0402C0G500270JNP; GRM1555C1H270JA01
CGA2B1X7R1C104K050BC; GCM155R71C104KA55

VENKEL LTD.;MURATA TDK;MURATA

4 C6, C9, C14, C17 Pref

C10, C36-C38,

14 C41-C43,

Pref

C47-C53

2 C12, C13

Pref

20-00U01-12A 20-0010U-BA92
20-000U1-04A

GRM155R71H103JA88
GRT188R61C106KE13
CGA2B3X7R1H104K050BB; C1005X7R1H104K050BB; GRM155R71H104KE14; GCM155R71H104KE02; C1005X7R1H104K050BE; UMK105B7104KV-FR; CGA2B3X7R1H104K050BE

MURATA MURATA
TDK;TDK;MURATA;MURATA; TDK;TAIYO YUDEN;TDK

1 C15

Pref

20-0001U-CA22

CGA3E1X7R1V105K

TDK

3 C20, C25, C44

Pref

20-002U2-11D

GRM188Z71C225KE43

MURATA

2 C34, C35

Pref

2 C54, C56

Pref

1 C57

Pref

20-0047U-A42
20-004U7-X3 20-0100U-CA04

C3216X5R1E476M160AC
C1608X5R0J475M080AB; GRM188R60J475ME19; JMK107BJ475MA T491X107K025A

TDK
TDK;MURATA;TAIYO YUDEN KEMET

2 CFG0, CFG1

Pref

2 D1, D2

Pref

1 D3

Pref

1 D4

Pref

2 DS1, DS3

Pref

1 DS2

Pref

1 DS4

Pref

1 EV_KIT_BOX1

Pref

3 EXP, J10,

Pref

VDD REF

2 EXT, GND

Pref

1 EXT_UC

Pref

1 J1

Pref

1 J3

Pref

1 J4

Pref

1 J5

Pref

1 J6

Pref

4 J7, TNZ_SCL/RX,

Pref

TNZ_SDA/TX, VDDIO

1 JAP

Pref

1 L1

Pref

2 L2, L4

Pref

2 L3, L15

Pref

2 L5, L14

Pref

5 L8, L9, L11,

Pref

L13, L17

1 L12

Pref

1 L16

Pref

1 L18

Pref

1 POWER

Pref

R2, R3, R29,

11 R40-R42, R44, R45, Pref

R60, R62, R65

2 R4, R5

Pref

R6, R7, R9-R11,

R13, R14, R28,

19 R30-R32, R43, R61, Pref

R63, R64, R67, R68,

R150, R151

02-TPMINI5000-00

5000 KEYSTONE

30-ES1D-00 30-DFLS140L-00 30-B360B13F-00 30-SMLP11UTT86-00 30-SMLP11MTT86-00 30-SMLE13BC8T-00
00-SAMPLE-01
01-PBC02SAAN2P-21
01-9020BUSS20AWG-00

ES1D DFLS140L B360B-13-F SML-P11UTT86 SML-P11MTT86
SMLE13BC8T

FAIRCHILD SEMICONDUCTOR DIODES INCORPORATED DIODES INCORPORATED ROHM ROHM
ROHM SEMICONDUCTOR

SRLZR_COAX_HSD_HMTD_BOX

MAXIM

PBC02SAAN 9020 BUSS

SULLINS ELECTRONICS CORP. WEICO WIRE

01-PBC04SAAN4P-21

PBC04SAAN

SULLINS ELECTRONICS CORP.

01-PBC12SAAN12P-21 01-198156815P-26 01-QTH03001LDA-17 01-PJ002AH3P-27 01-3935700022P-25

PBC12SAAN 1981568-1 QTH-030-01-L-D-A PJ-002AH

SULLINS ELECTRONICS CORP. TE CONNECTIVITY SAMTEC CUI INC. 393570002 MOLEX

01-PBC03SABN3P-21

PBC03SABN

SULLINS

01-59S2AQ40MT5Z15P-01 59S2AQ-40MT5-Z_1

EL111000001783 EL111000001781 50-002U2-0MW 50-004U7-0FE 51-00600-0AU 50-RFCMF1220100M3-00 50-00120-SM3A 00-SAMPLE-02 01-PEC04SAAN4P-21

MSS6132T-223ML PFL1609-471ME TFM201610ALMA2R2MTAA DFE252012P-4R7M=P2 BLM18KG601SN1 RFCMF1220100M3 BLM18SG121TN1 1210POC-682MR PEC04SAAN

80-0010K-Q6

ERJ-2GEJ103

80-0020K-Q6

ERJ-2GEJ203

ROSENBERGER
COILCRAFT COILCRAFT TDK MURATA MURATA WALSIN TECHNOLOGY CORPORATION MURATA COILCRAFT SULLINS ELECTRONICS CORP.
PANASONIC
PANASONIC

80-0000R-26A

ERJ-2GE0R00

PANASONIC

22PF 27PF

VALUE

0.1UF

0.01UF 10UF

0.1UF

DESCRIPTION CAPACITOR; SMT (0402); CERAMIC CHIP; 22PF; 50V; TOL=2%; TG=-55 DEGC TO +125 DEGC; TC=C0G CAPACITOR; SMT; 0402; CERAMIC; 27pF; 50V; 5%; C0G; -55degC to + 125degC; 0 +/-30PPM/degC
CAPACITOR; SMT (0402); CERAMIC CHIP; 0.1UF; 16V; TOL=10%; TG=-55 DEGC TO +125 DEGC; TC=X7R; AUTO; NOTE: PLEASE USE MAXINV 20-000u1-L1A
CAPACITOR; SMT (0402); CERAMIC CHIP; 0.01UF; 50V; TOL=5%; TG=-55 DEGC TO +125 DEGC; TC=X7R CAPACITOR; SMT (0603); CERAMIC CHIP; 10UF; 16V; TOL=10%; TG=-55 DEGC TO +85 DEGC; TC=X5R; AUTO
CAPACITOR; SMT (0402); CERAMIC CHIP; 0.1UF; 50V; TOL=10%; TG=-55 DEGC TO +125 DEGC; TC=X7R

CAPACITOR; SMT (0603); CERAMIC CHIP; 1UF;

1UF

35V; TOL=10%; TG=-55 DEGC TO +125 DEGC; TC=X7R;

AUTO; NOTE: SET TO OBSOLETE USE MAXINV NO 20-

0001U-BA46

2.2UF

CAPACITOR; SMT (0603); CERAMIC CHIP; 2.2UF; 16V; TOL=10%; TG=-55 DEGC TO +125 DEGC; TC=X7R

47UF

CAPACITOR; SMT (1206); CERAMIC CHIP; 47UF; 25V; TOL=20%; MODEL=C SERIES; TG=-55 DEGC TO +85 DEGC; TC=X5R ;NOTE: THESE PARTS HAVE 28 WEEKS LEAD TIME; MANUFACTURING DELAYS HAVE BEEN REPORTED ON THIS PRODUCT

4.7UF 100UF
N/A
ES1D DFLS140L B360B-13-F SML-P11UTT86 SML-P11MTT86 SMLE13BC8T SRLZR_COAX_HSD_HMTD_BOX PBC02SAAN MAXIMPAD
PBC04SAAN
PBC12SAAN 1981568-1 QTH-030-01-L-D-A

CAPACITOR; SMT (0603); CERAMIC; 4.7UF; 6.3V; TOL=20%; MODEL=C SERIES; TG=-55 DEGC TO +85 DEGC; TC=X5R
CAPACITOR; SMT (7343-43); TANTALUM CHIP; 100UF; 25V; TOL=10%
TEST POINT; PIN DIA=0.1IN; TOTAL LENGTH=0.3IN; BOARD HOLE=0.04IN; RED; PHOSPHOR BRONZE WIRE SILVER PLATE FINISH; RECOMMENDED FOR BOARD THICKNESS=0.062IN; NOT FOR COLD TEST;NOTE: SET TO OBSOLETE DUE TO CORRECTION IN STEP MODEL COLOR
DIODE; RECT; SMA (DO-214AC); PIV=200V; IF=1A
DIODE; SCH; SMT (POWERDI-123); PIV=40V; IF=1A DIODE; SCH; SCHOTTKY BARRIER DIODE; SMB; PIV=60V; Io=3A; -55 DEGC TO +125 DEGC DIODE; LED; SMT; PIV=1.8V; IF=0.02A
DIODE; LED; SMT; PIV=5V; IF=0.02A
DIODE; LED; SML-E1 SERIES; BLUE; SMT (0603); VF=2.9V; IF=0.005A;
EV KIT PACKAGING SET FOR SERIALIZER COAX OR HSD OR_HMTD BOX; LARGE BROWN 15 1/8 inch X 8 3/4 inch X 3 inch
CONNECTOR; MALE; THROUGH HOLE; BREAKAWAY; STRAIGHT; 2PINS EVK KIT PARTS; MAXIM PAD; WIRE; NATURAL; SOLID; WEICO WIRE; SOFT DRAWN BUS TYPE-S; 20AWG
CONNECTOR; MALE; THROUGH HOLE; BREAKAWAY; STRAIGHT; 4PINS; -65 DEGC TO +125 DEGC
CONNECTOR; MALE; THROUGH HOLE; BREAKAWAY; STRAIGHT; 12PINS; -65 DEGC TO +125 DEGC
CONNECTOR; FEMALE; SMT; MICRO USB STANDARD TYPE B ASSY; RIGHT ANGLE; 5PINS
CONNECTOR; FEMALE; SMT; HIGH SPEED GROUND PLANE HEADER; STRAIGHT THROUGH; 60PINS

PJ-002AH

CONNECTOR; MALE; THROUGH HOLE; DC POWER JACK; RIGHT ANGLE; 3PINS

CONNECTOR; FEMALE; THROUGH HOLE; 0.3MM 393570002 PITCH BEAU EUROSTYLE FIXED MOUNT PCB
TERMINAL BLOCK; RIGHT ANGLE; 2PINS

PBC03SABN

CONNECTOR; MALE; THROUGH HOLE; BREAKAWAY; STRAIGHT; 3PINS

59S2AQ-40MT5-Z_1 22UH 0.47UH 2.2UH 4.7UH
RFCMF1220100M3
6.8UH PEC04SAAN 10K 20K

CONNECTOR; MALE; THROUGH HOLE; FAKRA-HF RIGHT ANGLE PLUG PCB WITH HOUSING; RIGHT ANGLE; 5PINS
INDUCTOR; SMT; SHIELDED; 22UH; 20%; 1.9A
INDUCTOR; SMT; SHIELDED; 0.47UH; 20%; 1.3A INDUCTOR; SMT (2016); THIN FILM; 2.2UH; TOL=+/-20%; 2.1A INDUCTOR; SMT (2520); FERRITE CORE; 4.7UH; TOL=+/-20%; 1.7A 600 INDUCTOR; SMT (0603); FERRITE-BEAD; 600; TOL=+/-25%; 1.3A
INDUCTOR; SMT; CERAMIC CHIP; CHOKE; 0.3A
120 INDUCTOR; SMT (0603); FERRITE-BEAD; 120; TOL=+/-25%; 3A EVKIT PART-INDUCTOR; SMT; FERRITE; CHOKE; TOL=+/-20%; 1A CONNECTOR; MALE; THROUGH HOLE; BREAKAWAY; STRAIGHT; 4PINS
RESISTOR; 0402; 10K OHM; 5%; 200PPM; 0.10W; THICK FILM
RESISTOR; 0402; 20K OHM; 5%; 200PPM; 0.10W; THICK FILM

0 RESISTOR; 0402; 0 OHM; 0%; JUMPER; 0.10W; THICK FILM

COMMENTS

www.analog.com

Analog Devices 10

MAX96717 DPHY Evaluation Kit

Evaluates: MAX96717F

MAX96717 EV Kit Bill of Materials (Coax) (continued)

ITEM QTY

REF DES

VAR STATUS

MAXINV

MFG PART #

MANUFACTURER

1 R12

Pref

80-0200R-23

CRCW0402200RFK

VISHAY DALE

R15, R16, R21,

8 R23, R121,

Pref

R128-R130

80-04K99-18

ERJ-2RKF4991

PANASONIC

4.99K

1 R18

Pref

80-049R9-24

CRCW060349R9FK

VISHAY DALE

2 R19, R79

Pref

80-0200K-BA14

3214W-1-204

BOURNS

200K

2 R24, R25

Pref

1 R26

Pref

80-005K1-24 80-0402R-24

ERJ-3EKF5101 CRCW0603402RFK

PANASONIC VISHAY DALE

5.1K

VALUE

1 R27

Pref

80-024K9-23

CRCW040224K9FKEDHP

VISHAY DALE

24.9K

3 R33, R34, R39

Pref

2 R35, R36

Pref

1 R37

Pref

5 R71, R73-R76

Pref

1 SW1

Pref

80-0001K-18 80-0033R-23 80-0470R-AA23 80-0000R-27
11-1101M2S3AQE2-00

ERJ-2RKF1001
CRCW040233R0FK
ERJ-2RKF4700 CRCW06030000ZS; MCR03EZPJ000; ERJ-3GEY0R00
1101-M2-S3-A-Q-E-2

PANASONIC VISHAY DALE PANASONIC VISHAY DALE;ROHM; PANASONIC
C&K COMPONENTS

1K 1101-M2-S3-A-Q-E-2

2 SW3, SW4

Pref

11-KMR421GLFS-00

KMR421G LFS

C&K COMPONENTS

KMR421G LFS

1 U1

Pref

2 U2, U3

Pref

2 U4, U5

Pref

1 U6

Pref

1 U7

Pref

2 U8, U9

Pref

00-SAMPLE-03 10-74LVC1G86GV-U 10-MAX5419PETA-T 10-MK20DX256VLH7-C 10-MKL02Z32VFG4-G

MAX96717GTJ/VY+ 74LVC1G86GV MAX5419PETA+ MK20DX256VLH7 MKL02Z32VFG4

10-MAX3373EEKA-K

MAX3373EEKA+

MAXIM NXP MAXIM FREESCALE FREESCALE
MAXIM

MAX96717GTJ/VY+ 74LVC1G86GV MAX5419PETA+ MK20DX256VLH7 MKL02Z32VFG4
MAX3373EEKA+

1 U10

Pref

10-MAX16922ATPHV-T

MAX16922ATPH/V+

MAXIM

MAX16922ATPH/V+

1 U11

Pref

00-SAMPLE-04

MAX20019ATBI/V+

1 Y1

1 Y2

65 TOTAL

1 PCB 172

PURCHASE(DNP) ITEM QTY

REF DES

Pref

60-0025M-0CB

Pref

60-0016M-0CN

–

EPCB96717CSIDPHY

VAR STATUS

MAXINV

2 C3, C19

DNP

20-000U1-04A

1 J2

DNP

N/A

10 R1, R8, R20, R22, R38DNP

1 R17

DNP

80-0000R-26A 80-049K9-24

1 R77

TOTAL 15

DNP

80-0000R-27

not assembled on PCB and will be shipped with PCB)

ITEM QTY

REF DES

VAR STATUS

1 PACKOUT_BOX

Pref

1 PACKOUT_BOX

Pref

MAXINV 88-00713-LRG
87-02163-000

1 PACKOUT_BOX

Pref

1 PACKOUT_BOX

Pref

1 PACKOUT_BOX

Pref

1 PACKOUT_BOX

Pref

85-MAXKIT-PNK EVINSERT 85-84003-006 EH111000002613

1 PACKOUT_BOX

Pref

TOTAL 7

EH111000001907

ECS-250-18-33Q-DS
CX2016DB16000D0PSWC1 MAX96717CSIDPHY
MFG PART # CGA2B3X7R1H104K050BB; C1005X7R1H104K050BB; GRM155R71H104KE14; GCM155R71H104KE02; C1005X7R1H104K050BE; UMK105B7104KV-FR; CGA2B3X7R1H104K050BE
E6S201-40MT5-Z
ERJ-2GE0R00
CRCW060349K9FK; ERJ-3EKF4992 CRCW06030000ZS; MCR03EZPJ000; ERJ-3GEY0R00
MFG PART # 88-00713-LRG 87-02163-000
85-MAXKIT-PNK EVINSERT 85-84003-006 AK67421-0.5
WSU120-2000

MAXIM
ECS INC KYOCERA MAXIM

MAX20019ATBI/V+
25MHZ 16MHZ PCB

MANUFACTURER

VALUE

TDK;TDK;MURATA;MURATA; TDK;TAIYO YUDEN;TDK

0.1UF

ROSENBERGER
PANASONIC VISHAY DALE;PANASONIC VISHAY DALE;ROHM; PANASONIC

E6S201-40MT5-Z 49.9K

MANUFACTURER

N/A

ASSMANN

N/A

TRIAD MAGNETICS

N/A

VALUE

DESCRIPTION 200 RESISTOR; 0402; 200 OHM; 1%; 100PPM; 0.063W;
THICK FILM

COMMENTS

RESISTOR; 0402; 4.99K OHM; 1%; 100PPM; 0.10W; THICK FILM

49.9 RESISTOR; 0603; 49.9 OHM; 1%; 100PPM; 0.10W; THICK FILM
RESISTOR; SMT-J LEAD; 3214 SERIES; 200K OHM; 10%; 100PPM; 0.25W
RESISTOR; 0603; 5.1K OHM; 1%; 100PPM; 0.10W; THICK FILM 402 RESISTOR; 0603; 402 OHM; 1%; 100PPM; 0.10W; THICK FILM RESISTOR; 0402; 24.9K OHM; 1%; 100PPM; 0.125W; THICK FILM ;NOTE:SET TO OBSOLETE; CHANGE POWER RATING ;USE MAXINV ER111000002796 RESISTOR; 0402; 1K OHM; 1%; 100PPM; 0.10W; THICK FILM 33 RESISTOR, 0402, 33 OHM, 1%, 100PPM, 0.0625W, THICK FILM
470 RESISTOR; 0402; 470 OHM; 1%; 100PPM; 0.1W; THICK FILM
0 RESISTOR; 0603; 0 OHM; 0%; JUMPER; 0.10W; THICK FILM

SWITCH; SPDT; THROUGH HOLE; RIGHT ANGLE; 120V; 6A; 1000 SERIES; RCOIL=0.1 OHM; RINSULATION=100G OHM

SWITCH; SPST; SMT; STRAIGHT; 32V; 0.05A; MICROMINIATURE SMT TOP ACTUATED; RCOIL=0.1 OHM OHM; RINSULATION=1G OHM OHM

EVKIT PART – IC; SRLZR; CSI-2 TO GMSL3 SERIALIZER; TQFN32-EP; PACKAGE CODE: T3255+8; PACKAGE OUTLINE: 21-0140; PACKAGE LAND PATTERN: 90-0013
IC; XOR; 2-INPUT EXCLUSIVE-OR GATE; SOT753

IC; DPOT; 200K OHM; 256-TAP NONVOLATILE I2C-INTERFACE DIGITAL POTENTIOMETER; TDFN8EP;NOTE: SET TO OBSOLETE TO USE MAXIM 90SPECS FOOTPRINT
IC; UCON; KINETIS K2X MCU FAMILY; LQFP64
IC; UCON; KINETIS KL02 32 KB FLASH; 48 MHZ CORTEX-M0+ BASED MICROCONTROLLER; QFN16-EP
IC; TRANS; +/-15KV ESD-PROTECTED; 16MPBS; DUAL LOW-VOLTAGE LEVEL TRANSLATOR; SOT238;NOTE: SET TO OBSOLETE TO USE MAXIM 90- SPECS FOOTPRINT
IC; CONV; 2.2MHZ; DUAL; STEP-DOWN DC-DC CONVERTER; DUAL LDOS AND RESET; TQFN20EPNOTE: SET TO OBSOLETE TO USE MAXIM 90- SPECS FOOTPRINT

EVKIT PART-IC; VCON; 3.2MHZ; 500MILLIAMPERE DUAL STEP-DOWN CONVERTER FOR AUTOMOTIVE CAMERA; PACKAGE OUTLINE: 21-100125; LAND PATTERN DRAWING NO.: 90-100079; PACKAGE CODE: T1032+2C; TDFN10-EP;NOTE: SET TO OBSOLETE TO USE MAXIM 90- SPECS FOOTPRINT

CRYSTAL; SMT 3.2X2.5; 18PF; 25MHZ; +/-30PPM; +/-100PPM

CRYSTAL; SMT 2MMX1.6MM; 8PF; 16MHZ; +/-50PPM; +/-200PPM

PCB:MAX96717CSIDPHY

–

DESCRIPTION

COMMENTS

CAPACITOR; SMT (0402); CERAMIC CHIP; 0.1UF; 50V; TOL=10%; TG=-55 DEGC TO +125 DEGC; TC=X7R

EVKIT PART – CONNECTOR; MALE; THROUGH HOLE; PLUG PCB; RIGHT ANGLE; 2PINS; NOTE: PRELIMINARY DATASHEET
0 RESISTOR; 0402; 0 OHM; 0%; JUMPER; 0.10W; THICK FILM
RESISTOR; 0603; 49.9K OHM; 1%; 100PPM; 0.10W; THICK FILM
0 RESISTOR; 0603; 0 OHM; 0%; JUMPER; 0.10W; THICK FILM

DESCRIPTION
BOX;+;LARGE BROWN 15 1/8″ X 8 3/4 X 3″
ESD BAG;+;BAG; STATIC SHIELD ZIP 8″X10″; W/ ESD LOGO PINK FOAM;FOAM;ANTI-STATIC PE 12inX12inX5MM – PACKOUT WEB INSTRUCTIONS FOR MAXIM DATA SHEET
LABEL(EV KIT BOX) – PACKOUT
CONNECTOR; USB CABLE; MALE-MALE; USB_2.0; 5PINS-4PINS; 500MM ACCESSORY; WALL ADAPTER; VI-(90-264VAC); VO-(12VDC); 6FT

COMMENTS

www.analog.com

Analog Devices 11

MAX96717 DPHY Evaluation Kit
MAX96717 EV Kit Schematic
10K R29

www.analog.com

VDDIO R15

R79 200K 3214W-1-204
11

SILKSCREEN:CFG0
R21 33

SILKSCREEN: RESET PWDNB

3V3

4.99K

VDDIO

4.99K

SW3

KMR421G LFS

C119 0.1UF

3V3
DNI
TNZ_SCL_ALT TNZ_SDA_ALT 0X5E

POTCFG0 U4
MAX5419PETA+

R121 4.99K

1 VDD

2 SCL R10

3 SDA

4 A0

H8 W7 L6 GND 5

R128 4.99K

0X5C

3V3

DNI
R20
0 R150
0

CFG0
MFP1/CFG0

R44 10K

R45 10K

TNZ_SCL_ALT TNZ_SDA_ALT

3V3

VDDIO R16

R19 200K 3214W-1-204
11

4.99K

VDDIO

SILKSCREEN:CFG1
R23 33
4.99K

GND

MFP0/PCLK MFP1/CFG0 MFP2/CFG1 SDA_RX SCL_TX
RSVD
R32
0 R38
0 DNI X2
1V8

X1/OSC

1 PWDNB 2 MFP0 3 MFP1/CFG0 4 MFP2/CFG1 5 MFP9 6 MFP10 7 RSVD 8 X1/OSC
R26 402

C120 0.1UF

3V3
TNZ_SCL_ALT TNZ_SDA_ALT 0X5E
DNI

POTCFG1 U5
MAX5419PETA+

1 VDD R11

2 SCL R13

3 SDA

4 A0

H8 W7 L6 GND 5

R129 4.99K
R130 4.99K

DNI
R22
0 R151
0

CFG1
MFP2/CFG1

C8 0.1UF

C9 0.01UF

0X5C

5 MFP8 32 MFP7 31
D1N 30 D1P 29 CKN 28 CKP 27 D0N 26 D0P 25

9 X2 10 XRES 11 VDD18 12 SIOP 13 SION 14 CAPVDD 15 VDD 16 VDDIO

MFP8/D13 MFP7/D12 D1N/D11 D1P/D10 CKN/D9 CKP/D8 D0N/D7 D0P/D6

U1 MAX96717GTJ/VY+

D3N 24 D3P 23 MFP6 22 MFP5 21 D2N 20 D2P 19 MFP4 18 MFP3 17

D3N/D5 D3P/D4 MFP6/D3 MFP5/D2 D2N/D1 D2P/D0 MFP4/HS/RCLKOUT MFP3/VS/LOCK/ERRB

33 EP

C10 10UF

SIOP SION

C11 0.1UF

1V8

VDDIO

1 1.8V

SILKSCREEN:

C14 0.01UF

C16 0.1UF

C17 0.01UF

VDD
C18 0.1UF

VDDIO

3V3

3 3.3V

1.0V SILKSCREEN:

12V

J10 PBC02SAAN
C4 0.1UF

R24

R25

5.1K L1

5.1K L18
21

22UH

6.8UH

L2 21
0.47UH

DNI
C12 0.1UF
L4 2
0.47UH

SIOP

DNI
JAP

59S2AQ-40MT5-Z_1

SILKSCREEN: OUTA+

0.01UF

OVERLAY PAD WITH L7

DNI

2 2

R30 C1 22PF
0 C2 27PF

R27
25.5K
MFP3/VS/LOCK/ERRB
R28 0

U2 74LVC1G86GV

VCC 5 Y4

2A 3 GND

VDDIO R33 1K

RED

3V3

DS1

SML-P11UTT86

SILKSCREEN: ERROR

VDDIO

U3 74LVC1G86GV 7

VDDIO 1B

VCC 5 Y4

2A 3 GND

VDDIO R34 1K

GREEN

3V3

DS2

SML-P11MTT86

SILKSCREEN: LOCK

1V2 3 1.2V

Y1 25MHZ

R31

R43

R17
49.9K
2 4 3 5

R18
49.9

Evaluates: MAX96717F

DNI
C13 0.1UF

SION

Analog Devices 12

Analog Devices 13

www.analog.com

3V3

600

C25

C20 C21 C22 C23

2.2UF

2.2UF 0.1UF 0.1UF 0.1UF

USB_5V

USB5V

C38

10UF

1981568-1
L12 1 6

RFCMF1220100M3

L11 600

R36 R35

33 33

5 USB0_DP 6 USB0_DM 34 RESET_B

R14 0 SH_GND4

VDDA 13 VDD 3 VDD 30 VDD 48
VOUT33 7 VREGIN 8 VREFH 14
VREFL 15 VBAT 21

R37 470

C24 0.1UF

600

VSSA

3V3 L17
600 1

C27
0.1UF 2

PGA0_DP/ADC0_DP0/ADC1_DP3 9

PGA0_DM/ADC0_DM0/ADC1_DM3 10

PGA1_DP/ADC1_DP0/ADC0_DP3 11

PGA1_DM/ADC1_DM0/ADC0_DM3 12

PTA0 22

PTA1 23

PTA2 24

PTA3 25

PTA4/LLWU_P3 26

U6 MK20DX256VLH7

PTA5 27 PTA12 28 PTA13/LLWU_P4 29

PTA18 32

PTA19 33

PTB0/LLWU_P5 35

PTB1 36

PTB2 37

PTB3 38

PTB16 39

PTB17 40

PTB18 41

PTB19 42

PTC0 43

PTC1/LLWU_P6 44

PTC2 45

PTC3/LLWU_P7 46

PTC4/LLWU_P8 49

PTC5/LLWU_P9 50

PTC6/LLWU_P10 51

PTC7 52

PTC8 53

PTC9 54

PTC10 55

PTC11/LLWU_P11 56

PTD0/LLWU_P12 57

PTD1 58

PTD2/LLWU_P13 59

PTD3 60

PTD4/LLWU_P14 61

PTD5 62

PTD6/LLWU_P15 63

PTD7 64

PTE0 1

PTE1/LLWU_P0 2

VREF_OUT/CMP1_IN5/CMP0_IN5/ADC1_SE18 17 DAC0_OUT/CMP1_IN3/ADC0_SE23 18 XTAL32 19 EXTAL32 20

TNZ_SCL_ALT TNZ_SDA_ALT TNZ_SCL TNZ_SDA TNZ_RX TNZ_TX

C26 0.1UF

VSSA

16 VSSA 4 VSS
31 VSS 47 VSS

Y2 16MHZ

GND NC

3V3
U7 IC_MKL02Z32_QFN16 VDD_VREFH

14 PTA0/IRQ_0 15 PTA1/IRQ_1/LPTMR0_ALT1 16 PTA2
3 PTA3 4 PTA4 5 PTA5 6 PTA6 7 PTA7/IRQ_4

PTB0/IRQ_5 8 PTB1/IRQ_6 9 PTB2/IRQ_7 10 PTB3/IRQ_10 11 PTB4/IRQ_11 12 PTB5/IRQ_12 13

VREFL_VSS

SW4 KMR421G LFS

L13

600

GND

3V3

VDDIO

C30

C28

7 10K R41

7 10K R2

0.1UF

2 17

VCC VL

3-STATE 6

MAX3373EEKA+

8 I/O VCC1

I/O VL1 5

1 I/O VCC2

I/O VL2 4

GND

10K R3 R61 0

VDDIO PWDNB

7 2
3

R39

RED
DS3 SML-P11UTT86

MAX96717 DPHY Evaluation Kit
MAX96717 EV Kit Schematic (continued)

Evaluates: MAX96717F

MAX96717 DPHY Evaluation Kit
MAX96717 EV Kit Schematic (continued)

C35 47UF
www.analog.com

VSUP

ES1D

R4
20K

C41 10UF C42 10UF C43 10UF

C37 10UF C40 0.1UF
C15 1UF LSUP 17 C45 0.1UF

7 GND 19 GND1 14 GND2
4 GND3 9 PGND2 21 EP

20 EN 1 BST

VOUT1 VOUT1 VOUT1

2 PV1 11 PV2 12 PV3 16 PV4

VOUT1 R5 20K

6 PWM 18 RESET

U10 MAX16922ATPH/V+

OUTS1 5 OUTS2 8
OUT3 13 OUT4 15
LX1 3 LX2 10

VOUT1 VOUT2

4.7UH 1
1 2.2UH

L14 2
2 L3

DFLS140L

C47 10UF C48 10UF C49 10UF C51 10UF

12V

SILKSCREEN ALL THE PIN NAMES

3V3

1V8

1V2

R73

R74

2V5 1V8

J5 PJ-002AH

33 22

SILKSCREEN ON OFF NAMES
SW1
1101-M2-S3-A-Q-E-2

22 J6

33 11

SHIELD

393570002
SILKSCREEN PIN NAMES

R12

200

R75

1V2

USB_5V

VSUP SILKSCREEN PIN N1A2VMES

USB_5V
2
EXT
POWER

12V
4

C53 10UF

C55 0.1UF

D4 B360B-13-F

C57

100UF

DS4

SMLE13BC8T

C36 10UF C39 0.1UF 11

Evaluates: MAX96717F

C34 47UF
Analog Devices 14

VSUP

ES1D

BLUE LED SILKSCREEN: POWER

U11 MAX20019ATBI/V+

1 SUP

BST 10

C46

0.1UF L5

LX1 2

4.7UH

C52 10UF

9 EN

PGND 3

C44 2.2UF

7 BIAS

8 AGND EP

PV2 5

L15

LX2 4 1

2.2UH

OUT2 6

C50 10UF

1V R71 0

R76 0
3V3 DNI R77 0

3.3V

SILKSCREEN PIN NAMES
L16

120

EXT

C54 4.7UF

C56 4.7UF

GND

MAX96717 DPHY Evaluation Kit
MAX96717 EV Kit Schematic (continued)

Evaluates: MAX96717F

SIOP SION

DNI C19 0.1UF

C3 0.1UF
DNI

1 1 HSD_1 2 2 HSD_2

DNI
J2 E6S201-40MT5-Z

9 8 7 6 5 4 3

www.analog.com

Analog Devices 15

Analog Devices 16

www.analog.com

D0N/D7 D0P/D6
CKN/D9 CKP/D8
D3N/D5 D3P/D4

MFP3/VS/LOCK/ERRB MISO MFP8/D13 MFP5/D2 MFP6/D3

MFP4/HS/RCLKOUT

SDA_RX

VDDIO

DNI
R66
0

0 R67

11 33 55 77 99 11 11 13 13 15 15 17 17 19 19 21 21 23 23 25 25 27 27 29 29 31 31 33 33 35 35 37 37 39 39 41 41 43 43 45 45 47 47 49 49 51 51 53 53 55 55 57 57 59 59

SILKSCREEN:

63 63 64 64

61 61 62 62

J4 QTH-030-01-L-D-A

22 44 66 88 10 10 12 12 14 14 16 16 18 18 20 20 22 22 24 24 26 26 28 28 30 30 32 32 34 34 36 36 38 38 40 40 42 42 44 44 46 46 48 48 50 50 52 52 54 54 56 56 58 58 60 60

D1N/D11 D1P/D10
D2N/D1 D2P/D0

DNI
R80 0
DNI
R81 0
R68 0

MFP2/CFG1 PWDNB MFP7/D12 MFP0/PCLK MFP1/CFG0
SCL_TX

MOSI SPI_CLK SS1

SILKSCREEN PIN NAMES

MFP0/PCLK

MFP1/CFG0

MFP2/CFG1

MFP3/VS/LOCK/ERRB

MFP4/HS/RCLKOUT

MFP5/D2

MFP6/D3

MFP7/D12

MFP8/D13

RSVD CAN BE USED AS ADC

RSVD

EXTERNAL VOLTAGE REFERENCE

J1 PBC12SAAN
1 2 3 4 5 6 7 8 9 10 11 12

DNI USB_5V
R69

0
DNI 12V
R70

3V3

VDD_REF

C31

0.1UF

VDD_REF EXT_RX/SDA
GND EXT_TX/SCL

EXT_UC PBC04SAAN
1 2 3 4

TNZ_SCL SILKSCREEN:
TNZ_RX

SCL RX

TNZ_SDA SILKSCREEN:
TNZ_TX

SDA TX

TNZ_SCL/RX 2
TNZ_SCL/RX TNZ_SDA/TX
2 TNZ_SDA/TX

8 0.1UF C29

R40 10K

77 10K
R42

VCC VL

4 U9

3-STATE

MAX3373EEKA+

8 I/O VCC1

I/O VL1 5

1 I/O VCC2

I/O VL2 4

GND

7 2
3

R60

10K

SDA_RX

SILKSCREEN:

VDDIO

SCL_TX

EXP

10K

R62

R63 0
R64 0
7 R65 10K

SCL_TX SDA_RX
VDDIO

MAX96717 DPHY Evaluation Kit
MAX96717 EV Kit Schematic (continued)

Evaluates: MAX96717F

MAX96717 DPHY Evaluation Kit
MAX96717 EV Kit Layout

Evaluates: MAX96717F

1″
MAX96717 EV Kit–Silk Top

1″
MAX96717 EV Kit–Top

1″
MAX96717 EV Kit–Layer2

1″
MAX96717 EV Kit–Layer3

www.analog.com

Analog Devices 17

MAX96717 DPHY Evaluation Kit
MAX96717 EV Kit Layout (continued)

Evaluates: MAX96717F

1″
MAX96717 EV Kit–Layer4

1″
MAX96717 EV Kit–Layer5

1″
MAX96717 EV Kit–Layer6

1″
MAX96717 EV Kit–Layer7

www.analog.com

Analog Devices 18

MAX96717 DPHY Evaluation Kit
MAX96717 EV Kit Layout (continued)

Evaluates: MAX96717F

1″
MAX96717 EV Kit–Bottom

1″
MAX96717 EV Kit–Silk Bottom

www.analog.com

Analog Devices 19

MAX96717 DPHY Evaluation Kit

Evaluates: MAX96717F

Revision History

REVISION NUMBER
0

REVISION DATE
9/22

9/22

DESCRIPTION
Initial release Indicating future product use in the Ordering Information table for MAX96717/K/R.

9/22

Updated part numbers in header

PAGES CHANGED
—
7
All

Information furnished by Analog Devices is believed to be accurate and reliable. However, no responsibility is assumed by Analog Devices for its use, nor for any infringements of patents or other rights of third parties that may result from its use.Specifications subject to change without notice. No license is granted by implication or otherwise under any patent or patent rights of Analog Devices. Trademarks and registered trademarks are the property of their respective owners.

www.analog.com

Analog Devices 20

Mouser Electronics
Authorized Distributor
Click to View Pricing, Inventory, Delivery & Lifecycle Information:
Maxim Integrated:
MAX96717-AAK-EVK# MAX96717-ACK-EVK# MAX96717F-ACK-EVK#

Analog Devices Max96717 Dphy Evaluation Kit User Guide

MAX96717 DPHY Evaluation Kit

Product Information

Product Usage Instructions

References

Documents / Resouces

Related Manuals
