P1910-084-L Recovery 32-Watt Brushed Nickel Integrated LED Pendant
Product Information
The product being referred to in these installation instructions
is item#P1910-84/66A-L. It is a LED fixture that comes with a LED
driver, which can be replaced by a qualified electrician without
cutting any wire or damaging any decorative element to which the
fixture is attached. The fixture has black or smooth wires, white
or ribbed wires, and green or bare copper wires for grounding. The
fixture is also dimmable with LED compatible wall dimmer
switches.
Product Usage Instructions
- Before beginning the installation process, shut off the power
at the fuse box or circuit breaker box. - Remove the lock screws on the canopy from the mounting plate
using a screwdriver. - Loosen the screws and carefully remove the LED driver from the
ceiling canopy. - Un-twist the wire nuts to loosen the red and yellow wires.
- Install the new LED driver by reversing steps 1-4.
- Once the installation is complete, return power to the outlet
box and test the fixture.
Note: The illustration provided in Fig.1 is for installation
purposes only and may or may not be identical to the fixture
purchased.
INSTALLATION INSTRUCTIONS
Item#P1910-84/66A-L (New. 2021/6/25) READ AND SAVE THESE INSTRUCTIONS
W AR NI NG ! SH UT P O WE R O FF AT F US E O R CI RC UIT BRE AKE R.
AVERTISSEMENT! COUPER LE COURANT AU NIVEAU DES FUSIBLES OU DU DISJONCTEUR.
PREPARATION (Fig.1) 1. Shut off power at the fuse box or circuit breaker box
and remove the old fixture including the mounting hardware. 2. Carefully unpack your new fixture and lay out all the parts in a clean area. Take care not to misplace any small parts necessary for installation. 3. Remove mounting plate (C) from ceiling canopy (E). Secure mounting plate (C) to outlet box (A) (Not included) with the mounting screws (D). Tighten until snug. Make sure the side of mounting plate (C) marked “GND” must face out. 4. Press the wire restraint (G) on ceiling canopy (E) to adjust cable to desired height by pulling and pushing the cable. WIRES CONNECTIONS (Fig.2) 5. Pull power supply wires out from outlet box (A). Connect black supply wire to black fixture wire using wire nuts (B). Connect white supply wire to white fixture wire using wire nuts (B). Connect fixture ground wire and supply ground wire together using wire nuts (B). If your outlet box does not have a ground wire, connect the fixture’s ground wire directly to the mounting plate (A) using the green screw provided. Secure all wire nuts with electrical tape. COMPLETING THE INSTALLATION (Fig.1) 6. Assembling fixture body to outlet box (A). Line up holes on ceiling canopy (E) and mounting holes on mounting plate (C). Secure with lock screws (F). Tighten until snug. Replacing LED driver (Fig. 3)
The LED driver can be replaced by a qualified electrician without cutting of wire and without damage to any decorative element to which the fixture is attached. See installation steps for more details (Fig.3)
a. Shut off the power. b. Remove lock screws (F) on canopy (E) from mounting
plate (C) with screw driver (Not included). (Fig.1) c. Loosen screws (CC) and carefully remove led driver
(BB) from ceiling canopy (E). d. Un-twist wire nuts (DD) to loosen red and yellow
wires. e. Reverse steps a-d for installing new LED driver
Your installation is now complete. Return power to
outlet box and test the fixture.
Fig. 1
Fig. 2
FIXTURE WIRES Black or Smooth
Fig. 3
FIXTURE WIRES White or Ribbed HOUSE WIRES Black (Hot)
Set#A-016 -Mounting Plate -Ground Screw -Mounting Screw*2
FIXTURE WIRES Green or Bare Copper (Ground) HOUSE WIRES White (Neutral)
HOUSE WIRES Green (Ground)
Note: Illustration (Fig.1) on this manual is for installation purposes only. It may or may not be
identical to the fixture purchased. Dimmable with LED compatible wall dimmer switches.
LA-3188E
