HMW98 1-10V HF Motion Sensor
Product Information
- Product Name: IP65 HF Motion Sensor with 5.0 SIG Mesh
(HMW98) - Product Type: High-bay HF motion sensor
- Compatibility: Bluetooth 1-10V
- Installation Height: Up to 15m
- Structure: Robust IP65 design
- Installation Methods: Ceiling mount, conduit, clamp
- Communication: Bluetooth wireless mesh networking
- App Features: Quick setup mode, advanced setup mode, tri-level
control, daylight harvest, DCircadian rhythm, floorplan feature,
1-10V dimming control method, grouping luminaires via mesh network,
scenes, detailed motion sensor settings, Dusk/Dawn photocell
(Twilight function), push switch configuration, schedule based on
time and date, Astro timer (sunrise and sunset), staircase function
(master & slave), device firmware update over-the-air (OTA),
remote control via gateway support, network sharing via QR code or
keycode, offline commissioning, different permission levels via
authority management, continuous development in progress - Warranty: 5 years
Product Usage Instructions
- Choose an appropriate installation method: ceiling mount,
conduit, or clamp. - Ensure that the mains voltage is within the range of 220-240VAC
and the frequency is 50/60Hz. - Install the HMW98 motion sensor at a height of up to 15m using
the selected installation method. - Download the smartphone app for iOS or Android platforms.
- Open the app and follow the instructions to set up and
commission the HMW98 motion sensor. - Use the app’s quick setup mode or advanced setup mode to
configure the desired settings for tri-level control, daylight
harvest, DCircadian rhythm, 1-10V dimming, motion sensor
sensitivity, and other features. - Utilize the floorplan feature in the app to simplify project
planning and visualize the placement of luminaires. - Create scenes in the app to control multiple luminaires
simultaneously based on specific requirements. - Take advantage of additional features such as Dusk/Dawn
photocell (Twilight function), push switch configuration,
schedule-based control, Astro timer (sunrise and sunset), staircase
function, and device firmware update over-the-air (OTA) for
enhanced functionality. - Manage authority levels and permissions for different users
through the app’s authority management feature. - For remote control and interoperability with other devices, use
the app in conjunction with the HBGW01 gateway or EnOcean
self-powered switch modules. - Refer to the web app/platform at www.iot.koolmesh.com for
dedicated project management, offline commissioning, network
sharing via QR code or keycode, and other advanced features.
IP65 HF Motion Sensor with
5.0 SIG Mesh
HMW98 (High Bay)
Tri-level control & Daylight harvest & 1-10V Dimmable
RED
IP65
Product Description
HMW98 is a Bluetooth 1-10V high-bay HF motion sensor, with capability
of up to 15m installation height. It is designed with robust IP65 structure,
and offers 3 different installation methods. With Bluetooth wireless mesh
networking, it makes communication much easier without any hardwiring,
which eventually adds values to luminaires and saves costs for projects.
Ceiling mount
conduit
Meanwhile, simple device setup and commissioning can be done via
app.
App Features
Hardware Features
clamp
Quick setup mode & advanced setup mode Tri-level control Daylight harvest
DCircadian rhythm (Human centric lighting) Floorplan feature to simplify project planning
1-10V dimming control method
3 Meth
3 installation methods
IP IP65 design
High-bay (up to 15m height)
Web app/platform for dedicated project management Koolmesh Pro iPad version for on-site configuration
5-year warranty
rGrouping luminaires via mesh network
Scenes
Detailed motion sensor settings
a Dusk/Dawn photocell (Twilight function)
5.0 SIG mesh
Push switch configuration Schedule to run scenes based on time and date
f Astro timer (sunrise and sunset)
iOS
Android
for iOS
for Android
Smartphone app for both iOS & Android platform
t Staircase function (master & slave)
Internet-of-Things (IoT) featured Device firmware update over-the-air (OTA)
for iPad Koolmesh Pro app for iPad
Device social relations check Bulk commissioning (copy and paste settings) Dynamic daylight harvest auto-adaptation
Web
for Web Web app/platform: www.iot.koolmesh.com
Power-on status (memory against power loss)
Offline commissioning
Different permission levels via authority management
Network sharing via QR code or keycode
Remote control via gateway support HBGW01 Interoperability with Hytronik Bluetooth product portfolio
Fully support EnOcean self-powered switch module PTM215B (HBES01/W & HBES01/B)
Compatible with EnOcean BLE switches
Continuous development in progress…
Subject to change without notice.
Edition: 25 Jun. 2021 Ver. Draft Page 1/4
Technical Data
Input Characteristics Model No.
Mains voltage Stand-by power Load ratings:
Capacitive Resistive Warming-up
HMW98 220_240VAC 50/60Hz
<1W
800VA 1000W
20s
Sensor Data
Model No.
HMW98
Sensor principle
High Frequency (microwave)
Operation frequency
5.8GHz +/- 75MHz
Transmission power
<0.2mW
Detection range
Max installation height15m Max detection range10m (diameter)
Detection angle
360O
Safety and EMC EMC standard (EMC) Safety standard (LVD)
EN55015, EN61000-3-2/-3-3 EN60669-1, EN60669-2-1
Radio Equipment (RED)
EN300440, EN301489-1/-17/-3, EN62479,EN300328
Certification
CB, CE , EMC, RED, RCM
Environment Operation temperature IP rating
DMechanical Structures and Installations
For more details, please refer to user manual.
rA. Ceiling mount aLED indicator f Photocell
Bluetooth module
91.5 80.7 75
4.1
Ta: -20OC ~ +70OC IP65
t
4.1 66.6 81.5
Sensor module
Cable entry
59.3 57.3 47.5 24.5
Installation rack
Subject to change without notice.
Edition: 25 Jun. 2021 Ver. Draft Page 2/4
B. Screw to the Luminaire by conduit
LED indicator
Photocell
Bluetooth module Cable entry
Sensor module
75
59.6
0.825″
64
66.6 89.9
35.2
47.5
57.3
59.3
C. Attach to the shade by clamp
LED indicator Photocell
Bluetooth module
Angle adjustment Luminaire clamp
D Sensormodule
59.6 66.6
163.2
rNote:We recommend the mounting distance between sensor to sensor should be more than 2m to prevent sensors a from false-triggering.
1
f t DetectionPattern
84.5 59.3 29
75 33.7
15
4.5
4.5 28.5
0
5
10% 30% 50%
75%
15
Ceiling mounted height(m)
Subject to change without notice.
Edition: 25 Jun. 2021 Ver. Draft Page 3/4
Wiring Diagram
L N
Brown Blue Grey Red Black
L
N LED driver
1-10V+ 1-10V-
HMW98
Placement Guide and Typical Range Smart Phone to Device Range
D r6-10m
10m
The smart device with the App installed will have a typical range of 10m, but varies from device to device. During commissioning, the installer will need to be in range of the devices when searching for devices to add to the network.
Once the devices have been added to the network via the App, the devices will start communicating within the wireless mesh. This means that once the network is complete, all devices are accessible from the smart device when in a 20m range of a single point.
a Additional Information / Documents
1. To learn more about detailed product features/functions, please refer to www.hytronik.com/download ->knowledge ->Introduction of App Scenes and Product Functions
f 2. Regarding precautions for Bluetooth product installation and operation, please kindly refer to t www.hytronik.com/download ->knowledge ->Bluetooth Products – Precautions for Product Installation and Operation
3. Regarding precautions for microwave sensor installation and operation, please kindly refer to www.hytronik.com/download ->knowledge ->Microwave Sensors – Precautions for Product Installation and Operation
4. Data sheet is subject to change without notice. Please always refer to the most recent release on www.hytronik.com/products/bluetooth technology ->Bluetooth Sensors
5. Regarding Hytronik standard guarantee policy, please refer to www.hytronik.com/download->knowledge ->Hytronik Standard Guarantee Policy
