PN-LC652 LCD Monitor

Product Information

The PN-LC Series is a range of LCD monitors available in three
models: PN-LC652, PN-LC752, and PN-LC862. These monitors are
designed for professional use and offer high-quality display
performance.

Product Usage Instructions

Dismantle Procedure:
To dismantle the product, follow the steps below:
1. Remove the back covers (see section 5).
2. Remove the printed circuit boards (see section 6).
3. Dismantle the LCD (see section 7).
4. Remove the electrolyte capacitors (see section 8).
Batteries:
The PN-LC Series uses AAA batteries for the remote control. To
remove the battery, simply detach it from the remote control.
Back Covers:
The back cover of the monitor can be removed using a
screwdriver.
PWB and Other Electronic Components:
All electronic components, including the main PWB, power PWB,
T-CON PWB, key PWB, front PWB, OPS PWB, and speaker, can be removed
using a screwdriver.
LCD Module Bezels/Angles:
The LCD module bezels and angles can be dismantled according to
the instructions provided for each specific model (PN-LC652,
PN-LC752, PN-LC862).
Capacitors:
The power PWB contains capacitors with a diameter larger than
25mm. To remove these capacitors, use a nipper to cut the
leads.
Parts List:
For professional repairers, spare parts are available in
accordance with the legal requirements of EU Regulation 2019/2021.
The spare parts include the internal power board, connectors to
connect external equipment, batteries and accumulators,
DVD/Blue-Ray module, and HD/SSD module.

View Fullscreen

PN-LC Series Dismantle Instruction
LCD MONITOR

MODEL

PN-LC652 PN-LC752 PN-LC862

Dismantle Instruction

PN-LC Series Dismantle Instruction
Table of contents
1. Scope ………………………………………………………………………………………………… 3 2. Tools for dismantling………………………………………………………………………………… 3 3. Dismantle Procedure ……………………………………………………………………………….. 3 4. Batteries …………………………………………………………………………………………….. 4 5. Back covers ………………………………………………………………………………………….. 5 6. PWB and other electronic components ……………………………………………………………. 6
(1) MAIN PWB ……………………………………………………………………………………….. 6 (2) POWER PWB……………………………………………………………………………………… 6 (3) T-CON PWB………………………………………………………………………………………. 7 (4) IR/LED PWB ……………………………………. ! (5) KEY PWB…………………………………………………………………………………………. 8 (6) Speaker ………………………………………………………………………………………….. 8 7 LCD Module bezels/angles ………………………………………………………………………….. 9 8 Capacitors………………………………………………………………………………………….. 11 9 Parts List …………………………………………………………………………………………… 12
2

PN-LC Series Dismantle Instruction
1. Scope
This document describes dismantling instruction according to Annex VII of Directive 2012/19/EU.
2. Tools for dismantling
– Screw Driver – Nipper 3. Dismantle Procedure
This product can be dismantled by below steps. 1. Remove Back covers (section 5) 2. Remove Printed circuit boards (section 6) 3. Dismantle LCD (section 7) 4. Remove Electrolyte Capacitors (section 8)
3

4. Batteries
This model uses only AAA battery for remote control. Battery can easily be removed.
