TE-36A Triac Constant Current LED Driver

Product Information

The Triac Constant Current LED Driver, Model No.: TE-36A, is a
versatile LED driver designed for indoor LED lighting applications.
It features multiple dimming options, over-heat protection,
over-load protection, and short circuit protection. The driver has
a 5-year warranty and is suitable for retrofit upgrades and new
luminaire designs.

Features:

• Dimming interface: Triac/ELV, AC Push-Dim
• Compatible with leading edge/trailing edge Triac dimmers and
  dimming systems
• PWM digital dimming without altering LED color rendering
  index
• 1 channel constant current output with configurable current via
  DIP switch
• Over-heat / Over-load / Short circuit protection with automatic
  recovery
• Full protective plastic case
• Suitable for downlight, spotlight, and decorative
  applications
• 5-year warranty with a lifespan of 50,000 hours

Technical Parameters:

• Output Voltage: 10-52VDC
• Output Current: 350-1200mA
• Output Power: Max. 36W
• Max. Output Voltage: 58VDC
• Dimming Range: 0-100%
• PWM Frequency: 10-100Hz
• Current Accuracy: ±3%
• Input Voltage Range: 200-240VAC
• Frequency Range: 50/60Hz
• Efficiency: >85%
• Inrush Current: <20A
• Leakage Current: <0.5mA
• No Load Power: <0.5W
• Over Load Power: Auto-recovery
• Short Circuit: Auto-recovery
• Over Temperature: Auto-recovery
• Working Temperature: -20°C to +40°C
• T-case Max Working Humidity: 20-90% RH non-condensing
• Storage Temp/Humidity: -40°C to +80°C / 10-95% RH
  non-condensing
• Temperature Coefficient: ±0.03%/°C
• Vibration Resistance: 5-55Hz / 2g
• IP Rating: IP20
• Security Specifications: EN61000-4-2.3.4.5.6.8.11, EN61547
• Insulation Resistance: >5MΩ
• EMC Emission: CE, EMC
• EMC Immunity: Compliant with relevant standards
• Certifications: CE, EMC

Applications:

The TE-36A Triac Constant Current LED Driver is suitable for a
wide range of applications, including:

• Office / Commercial / Domestic Lighting
• Hotels
• Classrooms
• Warehouse
• Healthcare
• Retail and Display

Product Usage Instructions

Wiring Diagram:

Refer to the following wiring diagrams for different connection
configurations:

1. Connect Triac dimmer (no Neutral wire):

2. Connect Triac dimmer (with Neutral wire):

3. Connect AC Pushswitch:


Triac Dimming Input:

When connected with a Triac dimmer, such as Lutrom, Clipsal, or
Dynalite dimmer, please note that different Triac dimmers from
different suppliers may have different minimum dimming levels.
Ensure that the dimmer supports a minimum dimming level of 1% to
achieve dimming to the lowest level.

AC Push-Dim Input:

The AC Push-Dim interface allows for simple dimming using
commercially available non-latching (momentary) wall switches. The
following actions can be performed:

• Short press: Turn on or off the light.
• Long press (1-6s): Press and hold to achieve step-less dimming.
  With every other long press, the light level goes in the opposite
  direction.

Please refer to the user manual version 1.0.4 for more details
on installation, troubleshooting, and safety instructions.

Triac Constant Current LED Driver
Model No.: TE-36A

ON
123 Multiple Current

Tr i a c Dimming

Push-Dim

Digital Dimming

Synchronization

Over-heat Protection

Over Load Protection

Short Circuit Protection

Warranty 5 years

Features
Dimming interface: Triac/ELV, AC Push-Dim Apply to leading edge/trailing edge Triac dimmers and dimming system PWM digital dimming, no alter LED color rending index 1 channel constant current output, configurable current via DIP switch Over-heat / Over-load / Short circuit protection, recover automatically Full protective plastic case Suitable for indoor LED lighting application 5 Year, 50,000hr warranty

Mechanical Structures and Installations

INPUT 200-240VAC
123

AC N input

AC L input

N

L

AC Push input

L1

L

L1

Push DIM

DIP Switch for current selection

LED OUTPUT

Installation rack

LED

LED output –

LED

LED output +

44 mm

168.5 mm

User Manual Ver 1.0.4

30 mm

Technical Parameters

TE-36A Triac Constant Current LED Driver

Output
Input Protection Environment Safety&EMC

Output Voltage Output Current Output Power Max Output Voltage Dimming Range
PWM Frequency Current Accuracy Input Voltage Range Frequency Range Efficiency Alternating Current Inrush Current Leakage Current No Load Power
Over Load Power Short Circuit Over Temperature Woking Temperature T-case Max Working Humidity
Storage Temp/Humidity Temperature Coefficient Vibration Resistance IP Rating Security Specifications Withstand Voltage Insulation Resistance EMC Emission
EMC Immunity Certications

10-52VDC 350-1200mA Max. 36W 58VDC 0100
2000Hz ±3 200240VAC 50/60Hz >82%/220VAC 0.34A/220VAC Cold start 27.5A at 230VAC < 0.5mA/230VAC < 1.9W
When O/P voltage exceed its range, O/P current declines, auto recovers when the load is reduced. Shutdownautomaticallyifshortcircuitoccurs, auto recovers. Intelligently adjust or turn off the output current if the PCB temp > 100,auto recovers. -3055 70 2090RH, non-condensing -4080,1095RH ±0.03/ (0-50) 10-500Hz, 2G, 6min/cycle, X,Y,Z axes/2min IP20 IEC/EN61347-1, IEC/EN61347-2-13 I/P-O/P: 3750VAC I/P-O/P: 100M/500VDC/25/70RH EN55015, EN61000-3-2 Class C, IEC61000-3-3
EN61000-4-2.3.4.5.6.8.11, EN61547 CE, EMC

LED Current Selection:

1 23
Output Voltage Output Current Output Power

10-52V 350mA 3.5-18.2W

10-52V 500mA 5-26W

10-52V 600mA 6-31.2W

10-52V 700mA 7-36.4W

10-45V 800mA 8-36W

10-40V 900mA 9-36W

10-35V 1050mA 10.5-36W

10-30V 1200mA 12-36W

Applications
Suitable for downlight, spotlight and decorative applications. Office / Commercial / Domestic Lighting, Hotels, Classrooms, Warehouse, Health care, Retail and Display. Use for retrofit upgrades & new luminaire designs.

Page 1

Wiring Diagram

1. Connect Triac dimmer(no Neutral wire)

NL

N

LED OUTPUT

L

LED

L1

L

L1

Push DIM

LED

INPUT 200-240VAC
123

2. Connect Triac dimmer(with Neutral wire)

NL

N

LED OUTPUT

L

LED

L1

L

L1

Push DIM

LED

INPUT 200-240VAC
123

3. Connect AC Pushswitch

INPUT 200-240VAC
123

AC 100-240V

N

N

LED OUTPUT

L

L

LED

L1

LED

L

L1

Push DIM

PushSwitch

N

LED OUTPUT

L

LED

L1

L

L1

Push DIM

LED

INPUT 200-240VAC
123

User Manual Ver 1.0.4

Triac Dimming Input

TE-36A Triac Constant Current LED Driver

While connected with a Triac dimmer, such as Lutrom, Clipsal, Dynalite dimmer, different Triac dimmers from different suppliers may have different minimum dimming levels which the driver can not be dimmed below. To dim to 1%, please make sure the dimmer supports 1% minimum dimming level.
AC Push-Dim input
The provided AC Push-Dim interface allows for a simple dimming method using commercially available non-latching (momentary) wall switchs.
Short press: Turn on or off light.
Long press (1-6s): Press and hold to step-less dimming, With every other long press, the light level goes to the opposite direction.
Dimming memory: Light returns to the previous dimming level when switched off and on again, even at power failure.
Synchronization: If more than one LED driver are connected to the same push switch, do a long press for more than 10s, then the system is synchronized and all lights in the group dim up to 100%. This means there is no need for any additional synchrony wire in larger installations. We recommend the number of LED drivers connected to a push switch does not exceed 25 pieces, The maximum length of the wires from push to LED driver should be no more than 20 meters.
Dimming Curve

PWM duty(%)

100
Gamma=1.6
90 80 70 60 50 40 30 20 10
10 20 30 40 50 60 70 80 90 100
Brightness(%)
