MZ-1A Oem High Range Pressure Switches
Product Information
The MZ_ _A / MX_ _A OEM High Range Pressure Switches are
pressure switches designed for industrial applications. They come
with a range selection table to choose the appropriate model code
based on the desired pressure range. These pressure switches have a
maximum working pressure ranging from 200 psi to 500 psi, depending
on the model. They are equipped with a SPDT snapaction microswitch
with an electrical rating of 15 Amp, 250 VAC. The enclosure is IP66
standard, featuring a transparent tough polycarbonate cover for
protection. The wetted parts are made of SS316 and Teflon, ensuring
durability and resistance to corrosive materials. The pressure port
is 1/4 NPTF standard and the cable gland is M20 x 1.5 standard
(polyamide). The maximum temperature of the working medium is 80°C,
and for higher temperatures, impulse tubing should be used.
Product Usage Instructions
- Select the appropriate model code from the Range Selection
table based on the desired pressure range. - Install the pressure switch according to the provided
installation drawing. - Ensure that the wetted parts mentioned in italics are properly
installed. - Connect the pressure port (SS316) to the desired system or
equipment. - Secure the pressure switch using the mounting bracket and four
cover locking screws. - Insert the cable through the cable entry and tighten the cable
gland (M20 x 1.5 standard). - Make sure the pressure switch is within the specified maximum
temperature limit (80°C). - For higher temperatures, use impulse tubing.
- Refer to the user manual for any additional information or
graphs related to minimum differential increases with
setpoint.
MZ_ _A / MX_ _A OEM HIGH RANGE PRESSURE SWITCHES
PRESSURE CAPSULE DETAILS
3 2 1
Note : wetted parts are mentioned in italics.
INSTALLATION DRAWING
115 4.53
COVER LOCKING SCREW 4 NOS
No. Description
8
1. Pressure Port (SS316) 2. Housing Plate (SS316)
3. Disc
4. Mounting Bracket
7
5. Plunger
6
6. Ring (SS316)
5
7. O-Ring (Teflon®) 8. Diaphragm (Teflon®)
4
95 3.74 85 3.35
40.0 1.58
125.0 4.92
CABLE ENTRY
75Bulletin No. KA121024
PRESSURE PORT 1/4″ NPT(F)
50 1.97
5.5 SLOT WIDTH 0.22
2 NOS FOR MOUNTING
APPROX. DIMENSIONS IN
mm inches
274
MZ_ _A / MX_ _A OEM HIGH RANGE PRESSURE SWITCHES
RANGE SELECTION TABLE
Model Code
Range psi
MZ-1A
1.5-15.0
MZ-4A
3.0-50.0
MZ-7A
7.0-100.0
MZ-10A
7.0-150.0
MZ-15A
15.0-200.0
MZ-30A
70.0-350.0
MX-1A
MX-4A
MX-7A
MX-10A
MX-15A
MX-30A
*Approximate Maximum Differential psi 2.0 3.0 6.0 12.0 20.0 20.0 –
*Adjustable Differential psi
2 – 6 3 – 7 12 – 29 12 – 29 14 – 36 22 – 45
Maximum Working Pressure psi 200 200 200 350 350 500 200 200 200 350 350 500
*Minimum differential increases with setpoint (Graphs available on request) Rising pressure for MZ series
SPECIFICATIONS :
Range Electrical rating Enclosure# Wetted parts Pressure port Cable gland Maximum temperature of working medium
: As per model code : 15 Amp, 250 VAC, SPDT snapaction microswitch : IP66 standard, transparent tough polycarbonate cover : SS 316 & Teflon : 1/4″ NPTF standard : M20 x 1.5 standard (polyamide) : 80o C maximum. Please use impulse tubing for higher temperatures
# – IP66 is approximately equivalent to NEMA 4X
HOW TO ORDER MZ_ _A SERIES OEM PRESSURE SWITCHES
Please select model code from Range Selection table
275
