AGT-ML 1500LBS Motorcycle Lift
Product Information:
The AGT-ML 1500LBS Motorcycle Lift is a heavy-duty lift designed
for cleaning and servicing motorcycles and ATVs. It has a low
profile design and features an all-position anti-fall lock design,
swivel wheels for easy positioning, and a removable tow handle. The
lift is made of heavy steel construction for maximum durability and
features dual return springs that retract the ram. It has a
capacity of 1500 lbs with a minimum height of 120mm and a maximum
height of 380mm. The lift comes with safety instructions, and its
main construction includes a rubber pad, foot pedal, hexagon bolts,
handle, safety stand, hinge pin, lifting arm, pump, release pedal,
and more.
Product Usage Instructions:
- Study and understand all instructions before operating the
device. - Use the lift only on hard, level surfaces and do not exceed the
1500 lb. rated capacity. - Position the lift next to the load and lower it by depressing
the release pedal. - Turn the lock bolts until they contact the ground and lift the
rear wheels slightly off of the ground to keep the lift from
rolling. - Secure the load with tie-down straps (sold separately) and
repeatedly depress the foot pedal slowly to raise the lift. Ensure
that the load sits evenly on the lift saddle before raising
it. - Continue to raise the lift to the desired height. Disengage the
stop bar connecting rod from the clamp, lock the lift at one of the
three locking positions on the bottom base with the stop bars, and
lower the lift slightly to securely engage the stop bars. - After lifting, support the vehicle with appropriate means
immediately, and do not adjust the safety valve. - Wear ANSI-approved safety goggles and heavy-duty work gloves
during use and keep clear of the load while lifting and
lowering. - Lower the load slowly, do not use the lift for aircraft
purposes, and lift the vehicle only at the manufacturer-recommended
locations.
PRODUCT MANUAL
AGT-ML 1500LBS MOTORCYCLE LIFT
AGT
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL
REQUIREMENTS, WARNINGS AND CAUTIONS.
1. Forward
This motorcycle has below advantages: 1 . Perfect for cleaning, servicing motorcycles and ATV’s. 2. Low profile design. 3. All position anti-fall lock design. 4 . Removable tow handle. 5 . Swivel wheels for easy positioning. 6 . Heavy steel construction for maximum durability. 7. Dual return springs retract ram
2. Main specifications
Capacity (lbs) MIN height( mm) MAX height( mm)
1500 120 380
G.W.(kg) N.W.(kg) Packing size( mm)
30 28 850*400*150mm
3. Safety instructions
1 . Study, understand, and follow all instructions before operating this device. 2. Do not exceed 1500 lb. rated capacity. 3. Use only on hard, level surfaces. 4. Load saddles equally. 5 . Lifting device only. Immediately after lifting, support the vehicle with appropriate means. 6. Do not adjust safety valve. 7 . Wear ANSI- approved safety goggles and heavy- duty work gloves during use. 8. Keep clear of load while lifting and lowering.
T 9. Lower load slowly. G 10. Do not use for aircraft purposes. A 1 1. Lift vehicle only at manufacturer-recommended locations.
1 2. Inspect before every use; do not use if parts are loose or damaged. 1 3. Secure load with appropriate restraint device. 14 . Immediately after lifting load, ensure lift mechanical load holding means is engaged. 1 5. Do not move or dolly the vehicle while on the Lift. 1 6. No alterations shall be made to this product. 1 7. Keep hands away from the Lift Arms when raising or lowering the Lift. 1 8. Stay alert. Watch what you are doing, and use common sense when operating a Lift. Do not use Lift while tired or under the influence of drugs, alcohol, or medication. A moment of inattention while operating lifts may result in serious personal injury
1 9. Never allow anyone to ride Lift when it is being raised, lowered, or while holding an ATV or motorcycle. 2 0. Before use, read manufacturer’s instruction manual for the ATV or motorcycle being lifted. 2 1 . Store idle Lift out of reach of children and other untrained persons. Lifts are dangerous in the hands of untrained users. 2 2 . Lift service must be performed only by qualified repair personnel. Service or maintenance performed by unqualified personnel could result in a risk of injury. 23 . Maintain labels and nameplates on the Lift. These carry important information. 2 4 . The warnings, precautions, and instructions discussed in this manual cannot cover all possible conditions and situations that may occur. The operator must understand that common sense and caution are factors, which cannot be built into this product, but must be supplied by the operator.
2
4. Main construction
PART NO 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
DESCRIPTION Rubber pad Foot pedal Outer hexagon bolt M6x16 Hexagon socket bolt M8x25 Outer hexagon bolt M8x12 Flying bolt M6x20 Handle Hexagon socket bolt M6x12 Safety stand Rubber pad Flat washer 12 B pin Working plate Hinge pin 12×80
Base Front wheel
QTY 1 1 1 2 1 1 1 2 1 2 10 10 1 4 1 2
PART NO
T17 G18 A19
DESCRIPTION Hinge pin 12×65
Front stand Back stand
20
Lock nut M16
21
Flat washer 16
22
Outer hexagon bolt M16 x95
23
Lifting arm
24
Safety jump ring
25
Lock handle
26
Caster wheel
27
Spring washer 12
28
Nut M12
29
Handle socket
30
Pump
31
Release pedal
QTY 6 1 1 2 2 2 1 1 2 2 2 2 1 1 1
5. Operation instruction
Lifting
1. Lift the Stop Bar Connecting Rod and secure it to the Stop Bar Rod Clamp . 2 . Use the Handle to roll the Lift and position it next to the load. Lower the Lift by depressing the Release Pedal .
3
3 . Once positioned under the load, turn the Lock Bolts until they contact the ground and lift the Rear Wheels
slightly off of the ground to keep the Lift from rolling.
4 . Use tie- down straps (sold separately) to secure the load. Repeatedly depress the Foot Pedal
slowly to raise the Lift. When the Lift makes
contact with the load, make sure the load sits
evenly on the Lift Saddle before raising the load.
If
the load is not evenly distributed on the two
Rubber Pads or not secured in place with
tie-down straps, it may fall from the Lift,
resulting in personal injury and property damage.
5 . Continue to raise the Lift to the desired height.
Disengage the Stop Bar Connecting Rod from
the
clamp. Lock the Lift at one of the three locking
positions on the Bottom Base with the Stop Bars
and lower Lift slightly to securely engage the Stop Bars. Not engaging the Stop Bars may result in serious
injury or death, and damage the Lift.
Note: Stop Bars fit behind the welded stops on both sides of the Bottom Base. showing Stop Bars in the
locked position.
Lowering
1. Carefully remove all tools, parts, etc. from under the Lift. 2 . Depress the Foot Pedal slowly to raise the Lift enough to disengage the Stop Bars . Lift up the Stop Bar Connecting Rod and secure it to the Stop Bar Rod Clamp .
T 3 . Press the Release Pedal slowly and gently lower the load. Never allow the load to come down quickly or G suddenly. A 4 . Once the load is on the ground, remove the tie-down straps. When the Lift is clear of the load, turn the
Lock Bolts until they are clear of the ground, allowing the Rear Wheels to firmly contact the ground. Roll the Lift out from under the load. 5 . Clean external surfaces of the Lift with a clean, dry cloth. Store Lift in dry, indoor area out of reach of children.
6. Maintenance
1 . Before each use, inspect the general condition of the Lift. Check for broken, cracked, or bent parts, loose or missing parts, and any condition that may affect the proper operation of the product. If a problem occurs, have the problem corrected before further use. Do not use damaged equipment. 2 . Before each use, thoroughly test the Lift for proper operation prior to its actual use. 3 . Change the hydraulic oil at least once every three years: a. With the Lift fully lowered, remove the Oil Filler Plug on the side of the Bottle Jack . b. With assistance, place the Lift on its side to allow the old hydraulic oil to drain out of the jack ‘s Oil Reservoir completely, and dispose of the old hydraulic oil in accordance with local regulations. c. With the Lift upright, completely fill the jack ‘s Oil Reservoir with a high quality hydraulic oil (sold separately) until the oil just begins to run out of the oil fill hole. d. Reinstall the Oil Filler Plug. 4 . Wipe dry with a clean cloth. Then, store the Lift in a safe, dry location out of reach of children and other non- authorized people.
4
