River Of Goods 20788 Mission 1-light Oil Rubbed Bronze Hardwired Outdoor Wall Lantern Sconce Instruction Manual

20788 Mission 1-Light Oil Rubbed Bronze Hardwired Outdoor Wall Lantern Sconce

Product Information

The product is a lighting fixture that requires electrical
connections to be made for proper installation and operation. The
fixture comes with two machine screws, a mounting bracket,
decorative nuts, and a green grounding attachment screw. The
fixture does not come with bulbs.

Product Usage Instructions

Before assembling the lighting fixture, refer to the section
titled ELECTRICAL CONNECTIONS in the user manual. If you are not
experienced in electrical wiring, refer to a wiring handbook or
have a qualified licensed electrician install the fixture for
you.

1. Turn off the electricity before preparing the fixture.
2. Disconnect and remove any existing fixture and expose the
   supply wiring from the outlet box.
3. Thread the two machine screws into the opposite side of the
   mounting bracket with the long end facing toward the room.
4. Fasten the mounting bracket to the outlet box using the two
   screws supplied.
5. Push the white and black wires through the mounting
   bracket.
6. Attach the green or bare copper grounding wire from the supply
   circuit to the mounting bracket with the green grounding attachment
   screw provided.
7. Make electrical connections according to the instructions
   provided in the manual.
8. Spread the electrical splices so that the black wires are on
   one side of the outlet box and the white wires are on the other
   side.
9. Place the fixture against the mounting surface, allowing the
   machine screws to pass through the cover plate, and secure it with
   decorative nuts provided.
10. Install bulbs (not provided).
11. If applicable, attach shade to the threaded stem, and then
    secure it with finial.
12. Restore electricity and check the operation of your lighting
    fixture.

READ & SAVE
INSTALLATION & OPERATION INSTRUCTIONS

TOOLS & MATERIALS REQUIRED Adjustable wrench Flat Blade screw driver Step Ladder Wire cutters Wiring supplies as required by electrical code
CAUTION: Before assembling your Lighting fixture, refer to the section titled ELECTRICAL CONNECTIONS. If you feel you do not have electrical wiring experience, refer to a do-it yourself wiring handbook or have your fixture installed by a qualified licensed electrician.
GENERAL 1. To ensure the success of the installation, be sure to read these instructions and review the diagrams before beginning. 2. All electrical connections must be in accordance with local codes, ordinances, or the National Electrical Code. If you are unfamiliar with methods of installing electrical wiring, secure the services of a qualified licensed electrician. 3. These fixtures are intended to be mounted to a 4″ x 4″ x 2-1/8″ deep metal octagon outlet box. The box must be directly supported by the building structure. 4. Before starting the installation, disconnect the power by turning off the circuit breaker of by removing the fuse at the fuse box. Turning the power off using the light switch is not sufficient to prevent electrical shock.
PREPARE THE FIXTURE NOTE: FIRST TURN OFF ELECTRICITY Refer to figure 1 for illustration of fixture parts and assembly. 1. If you are replacing an existing fixture, disconnect and remove the old fixture. Expose the supply wiring from the outlet box. 2. Your fixture is supplied with two machine screws, thread the machine screws into the opposite side of the mounting bracket. The long end of the machine screws should be facing toward the room.

3. Fasten the mounting bracket to the outlet box using the two screws supplied. 4. Push white and black wire through mounting bracket 5. Attach grounding wire (green or bare copper) from the supply circuit to the mounting bracket with the green grounding attachment screw provided. 6. Make electrical connections – SEE BELOW.
ELECTRICAL CONNECTIONS Required Supply Circuit: 120V, 60 Hz First proceed by identifying the wires on your luminary: The POSITIVE wire can be identified by its color (Black Wire), and the NEGATIVE wire can be identified by its color (White Wire). Connect the luminary POSITIVE wire to the BLACK wire of the supply circuit. Next,connect the NEGATIVE wire of your luminary to the WHITE (neutral) wire of the supply circuit. Connect the green (or bare copper) colored wire from the supply circuit to the GREEN GROUND SCREW located on the MOUNTING BRACKET (see figure). Use UL/CSA Listed wire connectors (included) suitable for the size, type and number of conductors. No loose strands or loose connections should be present. Secure wire connectors with UL/CSA Listed electrical tape.
FINAL ASSEMBLY 1. Spread the electrical splices so that the black wires are on one side of the outlet box and the white wires are on the other side. 2. Place the fixture against the mounting surface allowing the machine screws to pass through the cover plate. Secure with the decorative nuts provided. 3. Install bulbs (not provided). 4. If applicable, attach shade to the threaded stem, and then secure with finial. 5. Restore electricity and check the operation of your lighting fixture.
MADE IN CHINA

Note: The above diagram illustrates the installation of your new luminary. This is a representative drawing and is not intended to match the style of your luminary.
