2510FG5 Starter Fractional Horsepower
User Manual
NLRV.E42243
Motor Controllers, Manual
ONLINE CERTIFICATIONS DIRECTORY
See General Information for Motor Controllers, Manual
SCHNEIDER ELECTRIC USA, INC.
8001 KNIGHTDALE BLVD
KNIGHTDALE, NC 275459023 USA
Trademark and/or Tradename:
Investigated to ANSI/UL 508
Acrosstheline starters, enclosed type, “Class 2510” Model(s) AEQ4038G1
FG or FGJ, followed by 1 thru 6, with or without suffix P, with or without suffix $1, with or without PB1 Class 2510.
FW1 or FW2, with or without suffix P, PG and/or H.
FW1PHS1
KG or KGJ, followed by 1 thru 6. with or without A, B, C, AG, BG or CG with or without suffixes S1, S100 and/or Y7, , with or without Class 2510 Type PB1.
KW1, KW2, KW5 or KW6, with or without A, B, C, AG, BG, CG and/or H.
PB1
Acrosstheline starters, enclosed type, “Class 2510, Series A” Model(s) MBF, TBF1, 2, MCF, TCF1, 2 or 3, with or without Forms L, L1 or L2, with or without N1, with or without M2, with or without P11, P13 or P14, with or without X1 or X2, with or without Y76.
MBF, TBF4, MCF or TCF5, with or without Forms L, L1 or L2, with or without N1, with or without X1 or X2, with or without Y76.
MBG, MCG, TBG1, 2, TCG1, 2 or 3, with or without Forms L, L1 or L2, with or without N1, with or without M2, with or without P11, P13 or P14, with or without X1 or X2, with or without Y76.
MBG, MCG, TBG4 or TCG5, with or without Forms L, L1 or L2, with or without N1, with or without X1 or X2, with or without Y76.
MBL1* or MBL2 *, with or without Forms L, L1 or L2, with or without N1, with or without X1 or X2; with or without L6 or L7.
MBW1*, 2*, 4, MCW1, 2, 3 or 5, with or without Forms G7 or G9, with or without N1, with or without X1 or X2, with or without Y76;
with or without N1, with or without P11, P13 or P14, with or without L6 or L7.
TBL1* or TBL2*, with or without Forms L, L1 or L2, with or without N1, with or without M2, with or without X1 to X5; with or without L6 or L7.
Acrosstheline starters, enclosed type, “Class 2510, Series B” Model(s) MBF, TBF21, 22, MCF, TCF21, 22 or 23, with or without Forms L, L1 or L2, with or without N10 or N10S, with or without P11, P13 or P14, with or without X1 or X2.
MBG, MCG, TBG21, 22, TCG21, 22 or 23, with or without Forms L, L1 or L2, with or without N1, with or without M2, with or without N10 or N10S, with or without P11, P13 or P14, with or without X1 or X2, with or without Y76.
MBL21* or MBL22*, with or without Forms L, L1 or L2, with or without Forms L, L1 or L2, with or without X1 or X2, with or without L6 or L7, with or without N1 or N10 or N10S, with or without Y76.
MBW21*, 22*, MCW21, 22 or 23, with or without Forms G7 or G9, with or without X1 or X2, with or without P11, P13 or P14, with or without L6 or L7, with or without N10 or N10S, with or without Y76.
TBL21* or TBL22*, with or without Forms L, L1 or L2, with or without M2, with or without N1, or N10 or N10S; with or without X1 or X2, with or without L6 or L7, with or without Y76.
Acrosstheline starters, enclosed type, “Class 2510, Series B or C” Model(s) MBA1*, 2*, 4, MCA1, 2, 3 or 5, with or without Forms L, L1 or L2, with or without N1, with or without X1 or X2, with or without Y76; with or without P11, P13, or P14, with or without L6 or L7, with or without G8.
MBA21*, 22*, MCA21, 22 or 23, with or without Forms L, L1 or L2, with or without X1 or X2, with or without P11, P13 or P14, with or without L6 or L7, with or without N1 or N10 or N10S with or without Y76, with or without G8.
MBW11*, 12*, 14, MCW11, 12, 13 or 15, with or without Forms X1 or X2, with or without Y76; with or without N1, with or without P11, P13 or P14, with or without G7, or G9 with or without L6 or L7, with or without G8.
MBW31*, 32 *, MCW31, 32 or 33, with or without Forms X1 or X2, with or without P11, P13 or P14, with or without G7 or G9, with or without L6 or L7, with or without N1, or N10 or N10S, with or without Y76, with or without G8.
Acrosstheline starters, enclosed type, “Class 2511” Model(s) KG11, KG11A, KG11B, KG22, KG22A, KG22B, KG22C
Acrosstheline starters, enclosed type, “Class 2511, Series A” Model(s) MBG1, MCG1, TBG1 or TCG1, with or without Form M1, with or without Form X01 thru 05, 10 thru 15, 20 thru 25, 30 thru 35, 40 thru 45, or 50 thru 55, with or without L, L2, or L3 with or without P11, P13, or P14.
Acrosstheline starters, enclosed type, “Class 2512” Model(s) FG11, FG11P, FG22, FG22P
Acrosstheline starters, enclosed type, “Class 2512, Series A” Model(s) MBG1, MCG1, TBG1 or TCG1, with or without Form M2, with or without Form X01 thru 05, 10 thru 15, 20 thru 25, 30 thru 35, 40 thru 45, or 50 thru 55, with or without L, L2, or L3 with or without P11, P13, or P14.
Acrosstheline starters, enclosed type, “Class 9991” Model(s) FE1, KE1
Acrosstheline starters, enclosed type Model(s) C1, followed by 1 or 2, followed by K or T, followed by 11 or 21, with or without L, P or S or combination thereof.
Acrosstheline starters, enclosed type , “Class 2510” Model(s) REQ2886G1, REQ2886G2
Acrosstheline starters, enclosed type, “Class 2512” Model(s) KG11, KG11A, KG11B, KG22, KG22B, KG22C
Acrosstheline starters, open type, “Class 2510, Series A” Model(s) MBO, MCO, TBO1, 2, TCO1, 2 or 3, with or without Form M2 and/or M3 or M4, with or without X1 or X2, with or without Y76.
MBO5, 6, 8, MCO6, 7, 8 or 10, with or without Form M3 or M4, with or without X1 or X2, with or without Y76.
Acrosstheline starters, open type, “Class 2510, Series B” Model(s) MBO, MCO, TBO21, 22, TCO21, 22 or 23, with or without Form M2 and/or M3, with or without N10 or N10S, with or without X1 or X2, with or without Y76.
MBO25, 26, MCO26, 27 or 28, with or without Form M2, M3 or M4, with or without N10 or N10S, with or without X1 or X2, with or without Y76.
Acrosstheline starters, open type, “Class 2511, Series A” Model(s) MBO1, 2, MCO1, 2, TBO1 or TCO1, with or without Form M1, with or without Form X01 thru 05, 10 thru 15, 20 thru 25, 30 thru 35, 40 thru 45, or 50 thru 55.
Acrosstheline starters, open type, “Class 2512, Series A” Model(s) MBO1, 2, MCO1, 2, TBO1 or TCO1, with or without Form M2, with or without Form X01 thru 05, 10 thru 15, 20 thru 25, 30 thru 35, 40 thru 45, or 50 thru 55.
Enclosures, “Class 9991” Model(s) KE3
Enclosures, for use with open type devices, “Class 9991, Series A” Model(s) MF1, MF2, MW1
Enclosures, for use with open type devices, “Class 9991, Series A or B” Model(s) MA1, MW11
Manual motor controllers, “Class 9003” Model(s) ZC
Manual motor controllers, enclosed type, “Class 9421” Model(s) AEQ3127G5, AEQ3127G6, AEQ3473 V1A30, V2A30, V1G30, V2G30, V1W30 or V2W30, may be followed by X20 or X11.
Manually operated drumtype reversing switches, enclosed type, “Class 2601” Model(s) AF2, AG1, AG2, AG3, AG1X1, AG1X2, AH2, AW2, BF1, BF1S4, BG1, BG1S4, BW1, BW1S4
* Suitable for use when protected by fuses of ratings greater than four times the full load current of the motors they are designed to control.
Each device is marked with the rating of the maximum fuse with which it may be used. (Group Fusing).
