SD-200 Series 200W Single Output DC DC Converter
Product Information
| Model | SD-200B | SD-200C | SD-200D |
|---|---|---|---|
| Output Voltage | 5V | 12V | 5V, 12V, 24V, 48V |
| Rated Current | 34A | 16.7A | 40A, 16.7A, 8.4A, 4.2A |
| Rated Power | 170W | 200.4W | 200W, 200.4W, 201.6W |
| Ripple & Noise (max.) | 100mVp-p | 120mVp-p | 100mVp-p, 120mVp-p, 150mVp-p, 200mVp-p |
| Voltage Adjustment Range | 4.5 ~ 5.5VDC | N/A | N/A |
| Line Regulation | N/A | N/A | N/A |
| Load Regulation | N/A | N/A | N/A |
| Setup, Rise Time | 300ms, 50ms at full load | N/A | N/A |
| Voltage Range | B:19 ~ 36VDC C:36 ~ 72VDC D:72 ~144VDC | B:19 ~ 36VDC C:45A/48VDC D:45A/96VDC | B:19 ~ 36VDC C:36 ~ 72VDC D:72 ~144VDC |
| Efficiency (Typ.) | 79% | 82%, 85%, 86% | 82%, 84%, 86%, 90% |
| DC Current (Typ.) | N/A | 10.6A/24V, 10.4A/24V, 10.4A/24V | 3.5A/96V, 3.5A/96V, 3.5A/96V, 3.5A/96V |
| Inrush Current (Typ.) | N/A | C:45A/48VDC D:45A/96VDC | 82% 3.5A/96V 84% 3.5A/96V 90% 3.5A/96V |
| Overload Protection | 105 ~ 135% rated output power | N/A | 105 ~ 135% rated output power |
| Over Voltage Protection | 5.75 ~ 6.75V, 16.8 ~ 20V, 31.5 ~ 37.5V, 53 ~ 65V | 5.75 ~ 6.75V, 16.8 ~ 20V, 31.5 ~ 37.5V, 53 ~ 65V | 5.75 ~ 6.75V, 16.8 ~ 20V, 31.5 ~ 37.5V, 53 ~ 65V |
| Over Temperature Protection | Shut down o/p voltage, recovers automatically after temperature goes down | N/A | Shut down o/p voltage, recovers automatically after temperature goes down |
| Working Temperature | -20 ~ +60 (Refer to Derating Curve) | N/A | -20 ~ +60 (Refer to Derating Curve) |
| Working Humidity | N/A | N/A | N/A |
| Storage Temperature, Humidity | N/A | N/A | N/A |
| Temp. Coefficient | N/A | N/A | N/A |
| Vibration | N/A | N/A | N/A |
| Safety Standards | N/A | UL62368-1 approved (for SD-200C-5/12/24 type only), EAC TP TC 004 approved, design refer to AS/NZS 62368.1 | N/A |
| Safety & Withstand Voltage | N/A | I/P-O/P:1.5KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25/ 70% RH | N/A |
| EMC | N/A | Compliance to BS EN/EN55032 (CISPR32) Class B, EAC TP TC 020 | N/A |
| Isolation Resistance | N/A | N/A | N/A |
| EMC Emission | N/A | Compliance to BS EN/EN61000-4-2,3,4,6,8, light industry level, EAC TP TC 020 | N/A |
| EMC Immunity | N/A | Compliance to BS EN/EN61000-4-2,3,4,6,8, light industry level, EAC TP TC 020 | N/A |
| MTBF | N/A | N/A | 1919.7K hrs min. Telcordia SR-332 (Bellcore); 280.6K hrs min. MIL-HDBK-217F (25) |
| Dimension | N/A | N/A | 215*115*50mm (L*W*H) |
| Packing | N/A | N/A | 1.1Kg; 12pcs/14.4Kg/0.9CUFT |
For more information, please refer to the product website.
200W Single Output DC-DC Converter
SD-200 series
User’s Manual
SPECIFICATION
MODEL
SD-200B
SD-200C
OUTPUT
DC VOLTAGE
5V
12V
RATED CURRENT
34A
16.7A
CURRENT RANGE
0 ~ 34A
0 ~ 16.7A
RATED POWER
170W
200.4W
RIPPLE & NOISE (max.) Note.2 100mVp-p 120mVp-p
VOLTAGE ADJ. RANGE
4.5 ~ 5.5VDC
VOLTAGE TOLERANCE Note.3 ±2.0%
LINE REGULATION
±0.5%
LOAD REGULATION
±1.0%
11 ~ 16VDC ±1.0% ±0.5% ±1.0%
SETUP, RISE TIME
300ms, 50ms at full load
24V
8.4A 0 ~ 8.4A
201.6W
150mVp-p
23 ~ 30VDC ±1.0% ±0.5% ±1.0%
48V
4.2A 0 ~ 4.2A
201.6W
200mVp-p
43 ~ 53VDC ±1.0% ±0.5% ±1.0%
5V
40A 0 ~ 40A
200W
100mVp-p
4.5 ~ 5.5VDC ±2.0% ±0.5% ±1.0%
12V
16.7A 0 ~ 16.7A
200.4W
120mVp-p
11 ~ 16VDC ±1.0% ±0.5% ±1.0%
24V
8.4A 0 ~ 8.4A
201.6W
150mVp-p
23 ~ 30VDC ±1.0% ±0.5% ±1.0%
48V
4.2A 0 ~ 4.2A
201.6W
200mVp-p
43 ~ 53VDC ±1.0% ±0.5% ±1.0%
INPUT
VOLTAGE RANGE EFFICIENCY (Typ.) DC CURRENT (Typ.) INRUSH CURRENT (Typ.)
B:19 ~ 36VDC 79% 10.8A/24V C:45A/48VDC
C:36 ~ 72VDC D:72 ~144VDC
82%
85%
86%
10.6A/24V 10.4A/24V 10.4A/24V
D:45A/96VDC
81% 5.4A/48V
84% 5.2A/48V
86% 6.7A/48V
86% 5A/48V
OVERLOAD
105 ~ 135% rated output power Protection type : Shut down o/p voltage, re-power on to recover
PROTECTION OVER VOLTAGE
5.75 ~ 6.75V 16.8 ~ 20V 31.5 ~ 37.5V 53 ~ 65V
5.75 ~ 6.75V 16.8 ~ 20V
Protection type : Shut down o/p voltage, re-power on to recover
31.5 ~ 37.5V 53 ~ 65V
OVER TEMPERATURE
WORKING TEMP.
WORKING HUMIDITY
ENVIRONMENT STORAGE TEMP., HUMIDITY
TEMP. COEFFICIENT
VIBRATION
SAFETY STANDARDS
SAFETY & WITHSTAND VOLTAGE
EMC
ISOLATION RESISTANCE
(Note 4)
EMC EMISSION
Shut down o/p voltage, recovers automatically after temperature goes down -20 ~ +60 (Refer to “Derating Curve”)
20 ~ 90% RH non-condensing -40 ~ +85, 10 ~ 95% RH ±0.03%/ (0 ~ 50) 10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes
UL62368-1approved (for SD-200C-5/12/24 type only), EAC TP TC 004 approved, design refer to AS/NZS 62368.1 I/P-O/P:1.5KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25/ 70% RH Compliance to BS EN/EN55032 (CISPR32) Class B, EAC TP TC 020
OTHERS NOTE
EMC IMMUNITY
Compliance to BS EN/EN61000-4-2,3,4,6,8, light industry level, EAC TP TC 020
MTBF
1919.7K hrs min. Telcordia SR-332 (Bellcore) ; 280.6K hrs min. MIL-HDBK-217F (25)
DIMENSION
215*115*50mm (L*W*H)
PACKING
1.1Kg; 12pcs/14.4Kg/0.9CUFT
(as available on http://www.meanwell.com)
https://www.meanwell.com/serviceDisclaimer.aspx
File Name:SD-200-SPEC 2022-02-28
200W Single Output DC-DC Converter
SD-200 series
SPECIFICATION
User’s Manual
Bauar t gepruft Sicherheit
egelma ge
od o s
be wac g
www. tuv.com ID 2000000000
MODEL
SD-200D
DC VOLTAGE
5V
12V
24V
48V
RATED CURRENT
40A
16.7A
8.4A
4.2A
CURRENT RANGE
0 ~ 40A
0 ~ 16.7A
0 ~ 8.4A
0 ~ 4.2A
RATED POWER
200W
200.4W
201.6W
201.6W
OUTPUT
RIPPLE & NOISE (max.) Note.2 100mVp-p
VOLTAGE ADJ. RANGE
4.5 ~ 5.5VDC
VOLTAGE TOLERANCE Note.3 ±2.0%
LINE REGULATION
±0.5%
LOAD REGULATION
±1.0%
120mVp-p
11 ~ 16VDC ±1.0% ±0.5% ±1.0%
150mVp-p
23 ~ 30VDC ±1.0% ±0.5% ±1.0%
200mVp-p
43 ~ 53VDC ±1.0% ±0.5% ±1.0%
SETUP, RISE TIME
300ms, 50ms at full load
VOLTAGE RANGE
B:19 ~ 36VDC C:36 ~ 72VDC D:72 ~144VDC
INPUT
EFFICIENCY (Typ.) DC CURRENT (Typ.) INRUSH CURRENT (Typ.)
82% 3.5A/96V C:45A/48VDC
82% 3.5A/96V D:45A/96VDC
84% 3.5A/96V
90% 3.5A/96V
OVERLOAD
105 ~ 135% rated output power Protection type : Shut down o/p voltage, re-power on to recover
PROTECTION OVER VOLTAGE
5.75 ~ 6.75V
16.8 ~ 20V
31.5 ~ 37.5V
Protection type : Shut down o/p voltage, re-power on to recover
53 ~ 65V
OVER TEMPERATURE WORKING TEMP. WORKING HUMIDITY ENVIRONMENT STORAGE TEMP., HUMIDITY TEMP. COEFFICIENT VIBRATION
Shut down o/p voltage, recovers automatically after temperature goes down -20 ~ +60 (Refer to “Derating Curve”)
20 ~ 90% RH non-condensing -40 ~ +85, 10 ~ 95% RH ±0.03%/ (0 ~ 50)
10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes
SAFETY &
EMC (Note 4)
SAFETY STANDARDS WITHSTAND VOLTAGE ISOLATION RESISTANCE EMC EMISSION
IEC/BS EN/EN 62368-1, EAC TP TC 004 approved, design refer to AS/NZS 62368.1 I/P-O/P:1.5KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25/ 70% RH Compliance to BS EN/EN55022 (CISPR22) Class B, EAC TP TC 020
EMC IMMUNITY MTBF
Compliance to BS EN/EN61000-4-2,3,4,6,8, light industry level, EAC TP TC 020 1919.7K hrs min. Telcordia SR-332 (Bellcore) ; 280.6K hrs min. MIL-HDBK-217F (25)
OTHERS NOTE
DIMENSION
215*115*50mm (L*W*H)
PACKING
1.1Kg; 12pcs/14.4Kg/0.9CUFT
(as available on http://www.meanwell.com)
https://www.meanwell.com/serviceDisclaimer.aspx
File Name:SD-200-SPEC 2022-02-28
