MU0014-B Full Motion Corner TV Wall Mount
Product Information
This product is a TV wall mount designed for use in wood stud or
solid concrete walls. It should not be installed into drywall
alone. The wall must be capable of supporting five times the weight
of the TV and mount combined to ensure proper installation and
prevent damage or injury.
It is important to note that this product contains small items
that could be a choking hazard if swallowed. Therefore, caution
should be exercised when handling and assembling the product.
The package includes the following items:
- Wall Plate 01 – Quantity: 1
- TV Plate 02 – Quantity: 1
- Extenders 3A – Quantity: 2
- Extenders 3B – Quantity: 2
Product Usage Instructions
- Before starting the installation process, carefully read the
entire instruction manual to ensure a proper understanding of the
installation process and safety precautions. - Verify that all parts included in the package are present and
undamaged. If there are any missing or damaged parts, please
contact us for assistance. - Ensure that the wall where the TV mount will be installed is a
wood stud or solid concrete wall. Installing into drywall alone is
not recommended. - Check that the wall is capable of supporting five times the
weight of the TV and mount combined. If there are any doubts about
the wall’s strength, consult with a professional or contact us for
guidance. - Position the Wall Plate 01 at the desired location on the wall
and mark the mounting holes. - Using appropriate hardware (not included), securely attach the
Wall Plate 01 to the wall, ensuring that it is level and properly
aligned. - Attach the TV Plate 02 to the back of the TV, following the
manufacturer’s instructions. - Attach the Extenders 3A and 3B to the TV Plate 02 as needed,
depending on the size and weight of the TV. - Carefully lift the TV and align the TV Plate 02 with the Wall
Plate 01. Securely attach the TV Plate 02 to the Wall Plate 01
using the provided hardware. - Ensure that the TV is securely mounted and properly aligned.
Make any necessary adjustments to achieve the desired viewing
angle.
Please note that the maximum VESA pattern supported by this
product is 400mm x 400mm (16″ x 16″).
INSTALLATION INSTRUCTION
Safety Caution
Hardware Included
Please read this instruction carefully before installation.
(V7)
If you do not understand these instructions or have doubts about the safety of the installation, assembly
or use of this product, please contact us.
This product is designed for use in wood stud or solid concrete wall. – DO NOT install into drywall alone.
The wall must be capable of supporting five times the weight of the TV and mount combined. Incorrect installation may result in product damage or body injury.
WARNING: This product contains small items that could be a choking hazard if swallowed.
Before starting assembly, verify all parts are included and undamaged. For parts shortage or damage, please contact us.
Wall Plate 01 x1
TV Plate 02 x1
Extenders
3A 3B
x2 x2
Must Check Before Getting Started
MAX:400mm/16″
<16mm(5/8″)
Min. Wood Stud Size: nominal 4″(102mm) actual 3 1/2″(89mm)
Min. 8″ (203mm)
Nuts
Bolts
Allen key
Hardware cWall /Product)
Lag Bolts 5/16 x 2½ in
Open-end wrench
Velcro Cable Ties ×5
Bubble Level ×1
Max: 88LBS (40KG)
Max:400x400mm/16×16″ Min:100x100mm /4×4″
If you have any questions, please feel free to contact us via Amazon.
Warm Tips You could also refer to the Video Guide about installation on our product page.
340-MU-DY
Step 1-1 Select TV screw diameter
Thread screws by hand into the threaded holes on the back of your TV to select which screw diameter fits your TV.
M4 M6 M8
Step 1-2 Select TV screw length
When attaching brackets to the flat screen, be careful not to over tighten screws and be sure that screws do not bottom out in the mounting holes.
Too Short
Too Long
Correct
Correct
Step 2 Mesure your TV pattern
Measure and note the width and the height
of the square or rectangle formed from the
VESA holes pattern .
8
MAX: 400mm/16″
Max: 88LBS (40KG)
Min. Wood Stud Size: nominal 2″(51mm) actual 1 1/2″(38mm)
Drywall with wood studs
Solid concrete wall
CAUTION: DO NOT install into drywall alone.
Installation Tools (Not Included)
Wood Stud Installation Concrete Installation
7/32″ (5.5mm)
Stud Awl Wood
Finder
Drill Bit
3/8″ (10mm)
Masonry Hammer Drill Bit
2M
Band Tape
Pencil
Electrodrill
1/2″ (13mm)
Socket Screwdriver Wrench
1
Step 3-1 Select monitor plate configuration
Select the configuration A , B , C, D, or E to use based on the measurement from STEP 2
VESA Pattern (WxH)
Configuration
VESA Pattern (WxH)
Configuration
200 mm 130 mm 100 mm
100mm x 100mm
A
300mm x 200mm
C
130mm x 130mm
A
300mm x 300mm
E
200mm x 100mm
A
400mm x 200mm
C
200mm x 200mm
A
400mm x 300mm
D
200mm x 300mm
B
400mm x 400mm
E
200mm x 400mm
B
200 mm
A
for VESA hole pattern: 100x100mm, 130x130mm,200x100mm, 200x200mm.
400 mm 300 mm
200 mm
400 mm 300 mm
C
For VESA: 400x200mm, 300x200mm
B
For VESA: 200x300mm, 200x400mm
400 mm
400 mm 300 mm
200 mm 130 mm 100 mm
4A
4B
4C
A
x8
x8
x1
x3
TV Screws / Washers
Philips Screws M4 x 12mm M4 x 30mm
Philips Screws M6 x 15mm M6 x 30mm
Philips Screws M8 x 25mm M8 x 45mm
Spacers L10mm
Washers Ø6mm M4-5-6
B
x1
Spacers L5mm
x4 x4
x4 x4 x4 x4
x8
x4
M-A
M-B
M-C
M-D
M-E
Step 3-2 Assemble TV plate and extenders
x8
M-F
2
If your TV hole pattern is greater than 200x200mm, attach extenders [3AA] and [3B] to TV plate [02] using Nut [44AA] and Bolt [44BB].
3A 3B
3A
Step 3-3 Attach the brackets
B 4A
3B
4B
(a) For Flat Back M-A M-C
M-B
Use the shorter screws
No! M-E
Not for M8 screws
Top of TV
100mm 4in. 130mm 5 1/8in. 200mm 8in. 300mm 11 3/4in 340mm 13 3/4in. 400mm 16in.
)
2M
34
D
For VESA: 400x300mm
300 mm
(b) For Round Back / Extra Space
M-A M-C M-B
Use the longer screws
Top of TV
400 mm 300 mm
M-E
E
Not for M8 screws
For VESA: 300x300mm, 400x400mm
No! M-D M-F
4
5
Step 4A Wall plate installation (wood stud)
A-1
Locate your studs. Verify and mark the center of the stud by finding the stud edges using an awl, a thin nail, or an edge-to-edge stud finder.
A-2
Bubble Level
UP
01
Position the wall plate 01 at your desired height and line up the holes with your stud center line. Level the wall plate and mark the pilot hole locations.
A-4
A UP
01
No!
Install wall plate 01 using lag bolts A with Socket Wrench, NO Electrodrill. Tighten the lag bolts A until they are pulled firmly against the wall plate 01
Step 4B Wall plate installation (concrete or brick)
B-1
Bubble Level
UP
Position the wall plate 01 at your desired height, level the wall plate and mark the pilot hole locations x3.
01
2
2
B-3
Concrete wall anchor 3pcs (NOT INCLUDED)
Ø10*61mm
Contact us to have these additional pieces shipped directly to you.
A UP
No!
01
7/32 in Ø5.5 mm
3/8in Ø 10 mm
A-3
2.75in 70 mm
Drill pilot holes using a 7/32 in. (5.5mm) diameter drill bit.
B-2
IMPORTANT: Pilot holes must be drilled to a depth
of 2 3/4 in (70 mm). Be sure to drill into the center of the stud.
Ø 10 mm 2.75in 70 mm
Install wall plate 01 using lag bolts A
with Socket Wrench, NO Electrodrill. Tighten the lag bolts A until they are pulled firmly against the wall plate 01
Concrete Wall Concrete Wall
Step 5 Lift and hang TV with brackets onto wall bracket
67 Drill pilot holes
Adjustments
78
8
Product dimensions:
Lift and hang TV assembly onto arm and wall plate.
Tilting Adjustment
-15° +5°
(Tilting)
Tilting Angle Adjustment (+5° / -15°) Loosen 2 tilting bolts, pull TV to your desired angle, then fasten tilting nuts with Allen key.
426.5mm/16.8″ 400mm/15.7″ 200mm/7.9″ 100mm/3.9″
100mm 200mm 400mm 427mm /3.9″ /7.9″ /15.7″ /16.8″
100.5mm/4″ 225mm/8.9″
101mm/4″
58mm/2.3″ 31mm/1.2″
Remove 2 preassembled screws and washers, save them for using to next step.
6.9mm/0.3″
4C
8.9mm/0.4″
±3°
9mm/0.4″
Secure the TV plate to the arm and wall plate with the removed screws and washers from the previous step.
No!
Leveling adjustment (-3°/+3°)
If needed, TV can be leveled ±3 degrees via adjusting the 2 screws with the open-end wrench.
± 3°
B
Loosen the screws
9410
Level the TV
B
Tighten the screws
1011
+5°
206mm/8.1″
206mm/8.1″
64mm/2.5″ ~ 479mm/18.9″
-15° 52mm/2″
200mm/7.9″
200mm/7.9″
±90°
11
