1 P1369-619 Nexpo 9 Light Coal Cluster Chandelier with Clear Glass Shades

P1369-619 Nexpo 9 Light Coal Cluster Chandelier with Clear Glass Shades

Product Information

The product is a light fixture with the item number
P1369-619/66A. It comes with a mounting plate, canopy, hanger ball,
and other hardware for installation. The fixture has a ground wire
and is compatible with a light bulb that meets its maximum wattage
rating. The package includes a user manual that provides
installation instructions and illustrations.

Product Usage Instructions

Remove the fixture from the carton and ensure that all parts
are included as shown in the illustration.
Shut off power at the circuit breaker and remove the old
fixture including the mounting hardware.
Attach the mounting plate to the junction box using the
provided screws.
Attach the hanger ball to the mounting plate using the provided
screw.
Connect the electrical wires as shown in figure 3, making sure
that all wire connectors are secured. If your outlet has a ground
wire, connect the ground wires from the hanger ball and mounting
plate to it. Otherwise, connect the ground wire from the hanger
ball directly to the mounting plate ground wire and secure with the
wire connectors provided. After wires are connected, tuck them
carefully into the ceiling junction box.
Align the canopy over the mounting plate and secure with
screws.
Place the glass shade over the socket and secure with the screw
shell.
Install the light bulb in accordance with the fixture’s
specifications. Do not exceed the maximum wattage rating.
The dendrites of this lamp have the function of rotating a
certain angle, customers can make their own adjustments.
Return power to the junction box and test the fixture.

Note: The illustration in the manual is for installation
purposes only and may not be identical to the fixture purchased.
The fixture should be installed by a qualified electrician to
ensure proper wiring and installation.

View Fullscreen

INSTALLATION INSTRUCTIONS
Item#P1369-619/66A (Rev. 01/26/2022) READ AND SAVE THESE INSTRUCTIONS
W AR NI N G ! S HU T P O WE R O F F AT F U S E O R CI R C UI T B R E AK E R .
AVERTISSEMENT! COUPER LE COURANT AU NIVEAU DES FUSIBLES OU DU DISJONCTEUR.

HANGING THE FIXTURE (Fig. 1)
1. Carefully remove the fixture from the carton and check that all parts are included as shown in the illustration.
2. Shut off power at the circuit breaker and remove the old fixture including the mounting hardware.
SUGGESTED INSTALLATION (Fig. 2) 3. Attach the mounting plate (A) to the junction box using
mounting screws (B) (Size: #8-32N*L0.5″) as shown in Fig. 2. 4. Determine the desired hanging height and thread rods (F1, F2, and F3) to the nipple (I). Pass the wires carefully through each rod as you assemble. 5. Place the canopy (C) over rods (F) and thread the hanger ball (E) to rods (F). Please remove the nipple if installing with one 12″ rod only. 6. Install the fixture body into the mounting plate (A) by tilting at a slight angle so that the hanger ball (E) slips into the mounting plate (A) as shown. Align the notch in the hanger ball (E) to the tab on the mounting plate (A) to prevent the fixture from turning.
CONNECTING THE WIRES (Fig. 3) 7. At this point, connect the electrical wires as shown in
figure 3, making sure that all wire connectors are secured. If your outlet has a ground wire (green or bare copper), connect the ground wires from the hanger ball and mounting plate to it. Otherwise, connect the ground wire from the hanger ball directly to the mounting plate ground wire and secure with the wire connectors provided. After wires are connected, tuck them carefully into the ceiling junction box.
COMPLETING THE INSTALLATION (Fig. 1) 8. Align the canopy (C) over the mounting plate (A) and
secure with screws (D). 9. Place the glass shade (J) over the socket (H) and secure
with the screw shell (G). 10. Install the light bulb (K) in accordance with the fixture’s
specifications. (DO NOT EXCEED THE MAXIMUM WATTAGE RATING!) (NE PAS DEPASSER LA PUISSANCE NOMINALE MAXIMALE!) 11. The dendrites of this lamp have the function of rotating a certain angle, customers can make their own adjustments. Your installation is now complete. Return power to the
junction box and test the fixture.
Note: Illustration (Fig. 1) on this manual is for installation purposes only. It may or may not be identical to the fixture purchased.

Fig. 1

Set# LTG BKT 10

– Mounting plate

– Ground screw

– Mounting Screw*2

C D F2

Rod#W30-1-84/66A*1(F1) W30-1-84/66A *2(F2) W30-H-84/66A *1(F3)

Fig. 3
FIXTURE WIRES Black or Smooth

FIXTURE WIRES White or Ribbed

G K
FIXTURE WIRES Bare Copper (Ground)

HOUSE WIRES Black (Hot)

HOUSE WIRES White (Neutral)
