LRA4P-347V-1 LED Strip Fixture Retrofit

Product Information: LRA4P-347V LED Retrofit Kit Assembly

Mechanical:

The LRA4P-347V LED Retrofit Kit Assembly is a 4 or 8-foot retrofit
kit that can be easily installed in existing fluorescent fixtures.
It comes with a driver and LED strips that can be mounted on the
existing fixture.

Optical:

The LRA4P-347V LED Retrofit Kit Assembly is available in 3500K,
4000K, and 5000K color temperatures with a Color Rendering Index
(CRI) of 82. It has a nominal lumen output ranging from 5100 to
11500 lumens, depending on the model.

Electrical:

The LRA4P-347V LED Retrofit Kit Assembly requires an input voltage
of 347V and comes with a driver set current ranging from 750mA to
1050mA, depending on the model. It has an input power ranging from
24W to 53W and has a power factor of >0.98 at max driver
current.

Certifications:

The LRA4P-347V LED Retrofit Kit Assembly is FCC Title 47 CFR, Part
15, Class A certified.

Kit Includes:

The LRA4P-347V LED Retrofit Kit Assembly includes LED strips, a
driver, and mounting hardware.

Ordering Guide:

The LRA4P-347V LED Retrofit Kit Assembly ordering code ID consists
of:

• LRA4P: Product Identifier
• 14 or 28: Length of the retrofit kit in feet
• HL8xx or ML8xx: LED type
• 347: Input voltage
• xx: Color temperature (35, 40, or 50 for 3500K, 4000K, or
  5000K)
• xxLC: Nominal lumens (30LC, 42LC, 50LC, 60LC, 70LC, or
  85LC)

Product Usage Instructions:

To use the LRA4P-347V LED Retrofit Kit Assembly, follow these
steps:

1. Turn off power to the existing fluorescent fixture.
2. Remove the existing fluorescent tubes and ballast from the
   fixture.
3. Mount the LED strips on the fixture using the included mounting
   hardware.
4. Connect the driver to the fixture’s electrical supply.
5. Attach the LED strips to the driver.
6. Turn on power to the fixture and test the LED retrofit kit
   assembly.

Note: Please consult the factory for photometry information. The
LRA4P-347V LED Retrofit Kit Assembly’s lumen and LPW tolerance is
+/-10%. The application and performance information is subject to
change without notification.

LRA4P-347V
LED Retrofit Kit Assembly

MECHANICAL
· Retrofits 4ft or 8ft fluorescent strip fixtures to LED
· Fast and easy installation · No design or revised layout needed
OPTICAL
· Diffuser provides broad, even light distribution · Three CCT options with CRI of 82
ELECTRICAL
· 347VAC, 60 HZ · Equipped with 0-10V dimmable LED Driver · LED System efficacies exceeding 115 LPW

CERTIFICATIONS
· UL Classified UL1598C (US & Canada) · Suitable for Dry or Damp locations
KIT INCLUDES
· (1) or (2) LED lightbars pre-mounted · (1) LED Driver (0-10V) pre-mounted · (1) or (2) 4′ strip fixture panels · Wiring, mounting hardware, installation
instructions WARRANTY · Five (5) year limited warranty

ORDERING GUIDE

EXAMPLE: LRA4P28-HL840-347-85LC

4-Foot

Ordering Code ID

Catalog Number Nominal Lumens

LRA4P14-HL8xx-347-70LC

7000

LRA4P14-HL8xx-347

LRA4P14-HL8xx-347-60LC

6000

LRA4P14-ML8xx-347-42LC

4200

LRA4P14-ML8xx-347

LRA4P14-ML8xx-347-30LC

3000

Input Power (W)
53 44 34 24

LPW
132 136 124 125

CRI

CCT

3500K, 4000K, 82
5000K 3500K, 4000K, 82
5000K

Input Voltage
347V
347V

Driver Set Current (mA)
900 750 1050 750

8-Foot

LRA4P28-HL8xx-347-12KC LRA4P28-HL8xx-347-10KC
LRA4P28-HL8xx-347 LRA4P28-HL8xx-347-85LC LRA4P28-HL8xx-347-70LC LRA4P28-ML8xx-347-65LC
LRA4P28-HL8xx-347 LRA4P28-ML8xx-347-50LC

11500 10000 8500 7000 6400 5100

85

135

71

141

3500K, 4000K,

82

347V

60

142

5000K

48

146

48

133

3500K, 4000K,

82

347V

38

134

5000K

ORDERING NOTES
– xx = 35, 40, 50 for 3500K, 4000K, 5000K – Consult factory for photometry.

– Application and performance information is subject to change without notification. – Lumen and LPW Tolerance of +/- 10%.

1500 1240 1065 855 1500 1250

OPERATING DATA

L85 Lumen Maintenance: Min. Starting Temp.: Sound Rating: EMI/RFI Power Factor: THD: Input Power Frequency:

>60,000 hrs. at 40°C -30°C (-22°F) Class A
FCC Title 47 CFR, Part 15, Class A >0.98 at max driver current <20% 50/60 Hz

COMPONENTS

Catalog Number

LED Light Bar

Driver

Driver Programmable Output Range

LRA4P14-ML8xx-347 LRL14-50L8xx-900CCL D10CC30347PW-C 1050mA to 750mA

LRA4P28-ML8xx-347 LRL14-50L8xx-900CCL D15CC55347PW-C 1500mA to 1250mA

LRA4P14-HL8xx-347 LRL14-70L8xx-900CCL D15CC55347PW-C 900mA to 625mA

LRA4P28-HL8xx-347 LRL14-70L8xx-900CCL D21CC80347PW-C 1500mA to 500mA

APPLICATION NOTES:
· All LED Lensed Modules must be connected for proper operation. · Not for use with phase cut dimmers. · Suitable for 4′ or 8′ strip light: non-lensed, minimum wiring compartment dimensions 2.5″ depth and 2″ width
| www.universaldouglas.com Rev. 7/22/2022

Universal Lighting Technologies

DIMENSIONS
LRA PANEL ASSEMBLY (1 OR 2 PER KIT)

4.55in 1.85in

20.00in

Adjustable brackets (if needed)

42.46in 47.94in

20.00in

1.80in 1.84in

1.24in Fixture shown for reference only.

End brackets (2 per kit)

Center brackets (1 per kit 8′ kit)

Installation Notes:
Installers can choose to use the existing socket bars if they line up with the LRA4P panel. Adjustable brackets can be used in lieu of the existing socket bars. These wrap around the ends of the strip housing and are attached with screws. The LRA panel mounts to these brackets with a ¼ turn thumb screw.
