MINI SPLIT
REPLACEMENT PARTS GUIDE
BZ33-HP18WALL2-G2-C
ID# .3548004
FACTORY CODE: 22022011018503
Accessory part
Optional part
COMFORT SERIES
| Part # | Replacement Part | Part Name | Qty |
| 1 | 12122000A80323 | Panel assembly | 1 |
| 2 | 12100204000397 | Air filter | 2 |
| 3 | 17222000A07665 | Display box subassembly | 1 |
| 3.1 | 17122000A09452 | Display board subassembly | 1 |
| 4 | 12122000006755 | Cover of electrical equipment | 1 |
| 5 | 12122000A65219 | Panel frame assembly | 1 |
| 5.1 | 12122000008242 | Screw cap | 1 |
| 6 | 12122000004592 | Front cover of chassis (right) | 1 |
| 8 | 12122000006359 | Horizontal louver | 1 |
| 9 | 15822000A16983 | Evaporator assembly | 1 |
| 10 | 12122000005538 | Fan motor cover | 1 |
| 11 | 11002015011867 | Brushless DC motor | 1 |
| 12 | 12122000000350 | Bearing holder | 1 |
| 13 | 12622000000131 | Bearing components | 1 |
| 14 | 12100102000131 | Cross flow fan | 1 |
| 16 | 12122000030321 | Chassis assembly | 1 |
| 16.1 | 11002010000077 | Stepper motor | 1 |
| 16.2 | 12100501000032 | Drain hose | 1 |
| 16.3 | 12122000008961 | Horizontal louver | 3 |
| 16.4 | 12122000004612 | Front cover of chassis (left) | 1 |
| 16.5 | 12122000000344 | Insulated axis | 1 |
| 17 | 12122000012941 | Pipe clamp board | 1 |
| 18 | 12222000003595 | Installation plate | 1 |
| 19 | 17222000037413 | Electronic control box subassembly (Mid & low-end) | 1 |
| 19.1 | 12122000004577 | Electronic control box | 1 |
| 19.2 | 12122000004639 | Left cover of electronic control box | 1 |
| 19.3 | 12122000004632 | Right cover of electronic control box | 1 |
| 19.4 | 17122000055446 | Main control board subassembly | 1 |
| 19.5 | 11201007003424 | Room temperature sensor | 1 |
| 19.6 | 11201007003447 | Pipe temperature sensor | 1 |
| 19.7 | 17400401000006 | Terminal | 1 |
| 20 | 12122000005020 | Cover of electronic control box | 1 |
| 21 | 17317000A64074 | Remote controller | 1 |
| 22 | 12600701000039 | Seal ring | 1 |
| 23 | 12100509000061 | Drain hose | 1 |
| 40 | 12100204000685 | Air freshening filter | 1 |
| 42 | 15500209000001 | Check valve | 1 |
| 45 | 12122000029201 | Bracket of remote controller | 1 |
| 46 | 15500406000012 | Copper nut | 1 |
| 46 | 15500406000016 | Copper nut | 1 |
| 53 | 17222000A07665 | Display box subassembly | 1 |
| 53.1 | 17122000A09452 | Display board subassembly | 1 |
| 53.3 | 17122000A09452 | Display board subassembly | 1 |
Due to continuing product improvements, specifications may change without notice.
Visit breeze33.com for current product information.
Breeze33 – HVAC Products
